Fundamentals of Microscopy in Microbiology: An Insightful Journey
B. Sc. First Year Semester I
Paper I – Fundamentals of Microbiology
Dr. Jadhav P. N.
Professor and Head,
Microbiology Department,
Deogiri College, Aurangabad
Unit 4: MICROSCOPY
Introduction
•
A microscope (Greek: mikron = small and
scopeos = to look).
•
MICROSCOPE: Is an instrument for viewing
objects that are too small to be seen by the
naked or unaided eye.
•
MICROSCOPY: The science of investigating
small objects using such an instrument is
called microscopy.
History
•
1590 - Hans Janssen and his son Zacharias
Janssen, developed first microscope.
•
1609 - Galileo Galilei - occhiolino or
compound microscope.
•
1620 - Christian Huygens, another Dutchman,
developed a simple 2-lens ocular system that
was chromatically corrected.
Magnification
•
Degree of enlargement.
•
No of times the length, breadth or diameter,
of an object is multiplied.
•
It depends upon – Optical tube length Focal
length of objective Magnifying power of eye
piece
•
TOTAL MAGNIFICATION: magnification of the
eyepiece x magnification of the objective
Resolution
•
Ability to reveal closely adjacent structural
details as separate and distinct.
•
LIMIT OF RESOLUTION (LR): The minimum
distance between two visible bodies at which
they can be seen as separate and not in
contact with each other.
•
LR = (0.61 x W)/NA
W = Wavelength; NA = Numerical aperature
Numerical Aperture
•
Ratio of diameter of lens to its focal length
•
NA = n Sin θ/2
n = refractive index, θ = angle of aperture
Definition: Capacity of an objective to render
outline of the image of an object clear and
distinct.
Focal length
•
The term focal length refers to the amount of distance required between the
objective lens and the top of your object, in order to be able to view an image
through the microscope that is in-focus.
•
When using a biological microscope the higher your objective magnification,
the shorter the focal length generally is.
•
With the 4x objective there may be some space between the objective lens
and your
cover slip
on your prepared slide. However, when using the 100x
objective lens the objective will be almost touching the cover slip, due to a
smaller focal length.
Objective lens
Low Power Objective (10x)
•
This objective lens is the next lowest powered and is often the most helpful when it comes to
analyzing glass slide samples. The total magnification for this lens is equal to 100x
magnification (10x eyepiece lens x the 10x objective equals 100).
•
Since it still provides a good amount of magnification at a good distance from the slide, there is
a limited risk of it breaking the glass and potentially ruining the sample. Hence, why it is often
preferred before going for a high powered lens.
High Power Objective Lens (40x)
This is referred to as the high powered objective lens since it is ideal for observing the small details
within a specimen sample. The total magnification for this lens is equal to 400x magnification (10x
eyepiece lens x the 40x objective equals 400).
Oil Immersion Objective (100x)
This objective lens will achieve the greatest magnification and has a total magnification of 1000x
(10x eyepiece lens x the 100x objective equals 1000). However, since the refractive index of air and
the glass slide are slightly different, a special oil must be used to help fill the gap between the two.
Without a drop of oil, the objective lens will not work properly and you will not achieve the desired
magnification and resolution.
Oculars
•
At the top of the body tube, a lens is planted which is
known as the eyepiece. On the rim of the eyepiece, there
are certain markings such as 5X, 10X, 15X, etc. Which
indicates the magnification power. The object’s magnified
image can be observed with the help of an eyepiece.
•
The simplest negative eyepiece design, often termed
the
Huygenian
eye-piece,
is found on most teaching and laboratory
microscopes fitted with achromatic
objectives.
•
Ramsden eyepiece has an eye lens and
field lens that are also plano-convex, but
the field lens is mounted with the curved
surface facing towards the eye lens.
Condensers
•
The condenser or sub-stage condenser is located between
the light source and the stage. It has a series of lenses to
converge on the object, light rays coming from the light
source. After passing through the object, the light rays
enter into the objective.
•
The ‘light condensing’, ‘light converging’ or ‘light gathering’
capacity of a condenser is called ‘numerical aperture of the
condenser’. Similarly, the ‘light gathering’ capacity of an
objective is called ‘numerical aperture of the objective’.
•
If the condenser converges light in a wide angle, its
numerical aperture is greater and vice versa.
•
Most common condensers have numerical aperture 1.25.
There are three types of condensers as follows:
(a) Abbe condenser (Numerical aperture=1.25):
It is extensively used.
(b) Variable focus condenser (Numerical
aperture =1.25)
(c) Achromatic condenser (Numerical aperture
=1.40): It has been corrected for both spherical
and chromatic aberration and is used in research
microscopes and photomicrographs.
Iris diaphragm
•
If light coming from the light source is brilliant
and all the light is allowed to pass to the
object through the condenser, the object gets
brilliantly illuminated and cannot be visualized
properly.
•
Therefore, an iris diaphragm is fixed below the
condenser to control the amount of light
entering into the condenser.
