Toolpaths and Slicing in 3D Printing


TOOLPATHS

3D Printing with Plastic Filament
+X
-X
+Z
+E
CC BY-NC-ND – sylvain.lefebvre@inria.fr

Slicing

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Uniform slicing

•
Fixed thickness (typically from 0,1 to 0,3 mm)

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Slice plane

[Cute Octopus Says Hello (
MakerBot
) /
CC BY 3.0
]

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Upon printing

extruder

Slice slab

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Volume error

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Minimizing volume error

•
Optimization
–
Minimize volume error?

•
Variables:
–
Object orientation!
–
Slice thicknesses


CC BY-NC-ND – sylvain.lefebvre@inria.fr

Adaptive slicing

Same number of slices

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Adaptive slicing

[Cute Octopus Says Hello (
MakerBot
) /
CC BY 3.0
]

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Adaptive slicing

[Cute Octopus Says Hello (
MakerBot
) /
CC BY 3.0
]

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Adaptive slicing

•
Faster for same precision
•
Do not waste time in ‘simple’ regions

•
Not so easy to determine best strategy
–
See survey by
[P.M. Pandey et. al. 2003]
–
Recent work:
[
Wang et. al. 2015
]
“Saliency preserving slicing”

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Locally adaptive slicing

Slic3r : micro-layering
IceSL  : nested slices

CC BY-NC-ND – sylvain.lefebvre@inria.fr
Toolpaths

[Cute Octopus Says Hello (
MakerBot
) /
CC BY 3.0
]

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Perimeter

Shells

Infill

Cover

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Erosion (morphological)

Structuring element
(nozzle exit hole)

Slice

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Erosion (morphological)

Erosion: All points where
structuring element is
entirely
 included

Structuring element
(nozzle exit hole)

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Perimeter

•
Visible part of the filament
•
Object contouring

Erosion!

(top view)

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Plastic flow

•
How much plastic to push?
–
Millimeters of filament (E axis)

Nozzle diameter

Layer height

E axis

FA

Filament diameter

Layer height x Nozzle diameter x L

L

FA

Length to push =

CC BY-NC-ND – sylvain.lefebvre@inria.fr

‘Thin features’

Disappears!!!

CC BY-NC-ND – sylvain.lefebvre@inria.fr

‘Thin features’

????

CC BY-NC-ND – sylvain.lefebvre@inria.fr

A possible approach

Skeleton

CC BY-NC-ND – sylvain.lefebvre@inria.fr

A possible approach

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Arbitrary decision (user?)

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Shells

•
More of the same

Note the gaps

Might become thin

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Infills

•
Top / bottom covers




•
Inside
–
Full infill (very robust, slow, lots of plastic)
–
Sparse infill (save plastic and time, less strong)

CC BY-NC-ND – sylvain.lefebvre@inria.fr

100% Infill

CC BY-NC-ND – sylvain.lefebvre@inria.fr

100% Infill

???

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Flow control

•
Limited change of thickness

Might not adhere

100%

50%

25%

CC BY-NC-ND – sylvain.lefebvre@inria.fr

100% Infill

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Speed

Faster!

Both axis work together: better acceleration

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Sparse Infill

•
Simple approach

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Sparse Infill

Squish!

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Sparse Infill

An improved variant:

Could be slow to print
Resonance

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Sparse Infill

An improved variant:

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Many other variants

CC BY-NC-ND – sylvain.lefebvre@inria.fr

Improving sparse infill ?

Tradeoff between:
–
Strength vs Plastic consumption
–
Time and printability (favor straight, diagonal lines)

Recent works:
–

[Wang et al. 2013]
“Cost effective printing”
–

[Lu et al. 2014]
“Build to last”
–
 Slic3r 3D honeycomb

Generates a 3D cellular pattern

CC BY-NC-ND – sylvain.lefebvre@inria.fr

New 3D infills

•
Just released :-)







•
See
http://sylefeb.blogspot.fr/

[3D infills, Sylvain Lefebvre,
CC BY 4.0
]

CC BY-NC-ND – sylvain.lefebvre@inria.fr









Slide Note





















Embed



Share
























Explore toolpaths, slicing techniques, and optimization methods in 3D printing with plastic filament. Learn about uniform slicing, volume error minimization, adaptive slicing, and locally adaptive slicing for efficient and high-quality printing results. Discover how advanced strategies can enhance printing precision and speed.





  •   Toolpaths
    •

  •    Slicing
    •

  •    3D printing
    •

  •    Plastic filament
    •

  •    Optimization
    •








										aren677


											 aren677 Follow







Uploaded on Sep 27, 2024 | 0 Views









Download Presentation





Please find below an Image/Link to download the presentation.


The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.
									Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.






















 E N D





Presentation Transcript




  1. TOOLPATHS 3D Printing with Plastic Filament
    2.



  2. +E -X +X +Z CC BY-NC-ND     sylvain.lefebvre@inria.fr
    3.



  3. Slicing CC BY-NC-ND     sylvain.lefebvre@inria.fr
    4.



  4. Uniform slicing     Fixed thickness (typically from 0,1 to 0,3 mm) Z (up) axis CC BY-NC-ND     sylvain.lefebvre@inria.fr
    5.



  5. Slice plane [Cute Octopus Says Hello (MakerBot) / CC BY 3.0] CC BY-NC-ND     sylvain.lefebvre@inria.fr
    6.



  6. Upon printing extruder Slice slab Z (up) axis CC BY-NC-ND     sylvain.lefebvre@inria.fr
    7.



  7. Volume error Z (up) axis CC BY-NC-ND     sylvain.lefebvre@inria.fr
    8.



  8. Minimizing volume error     Optimization     Minimize volume error?     Variables:     Object orientation!     Slice thicknesses CC BY-NC-ND     sylvain.lefebvre@inria.fr
    9.



  9. Adaptive slicing Same number of slices CC BY-NC-ND     sylvain.lefebvre@inria.fr
    10.



  10. Adaptive slicing [Cute Octopus Says Hello (MakerBot) / CC BY 3.0] CC BY-NC-ND     sylvain.lefebvre@inria.fr
    11.



  11. Adaptive slicing [Cute Octopus Says Hello (MakerBot) / CC BY 3.0] CC BY-NC-ND     sylvain.lefebvre@inria.fr
    12.



  12. Adaptive slicing     Faster for same precision     Do not waste time in    simple    regions     Not so easy to determine best strategy     See survey by [P.M. Pandey et. al. 2003]     Recent work: [Wang et. al. 2015]    Saliency preserving slicing    CC BY-NC-ND     sylvain.lefebvre@inria.fr
    13.



  13. Locally adaptive slicing Slic3r : micro-layering IceSL  : nested slices CC BY-NC-ND     sylvain.lefebvre@inria.fr
    14.



  14. Toolpaths [Cute Octopus Says Hello (MakerBot) / CC BY 3.0] CC BY-NC-ND     sylvain.lefebvre@inria.fr
    15.



  15. Shells Infill Perimeter Cover CC BY-NC-ND     sylvain.lefebvre@inria.fr
    16.



  16. Erosion (morphological) Structuring element (nozzle exit hole) Slice CC BY-NC-ND     sylvain.lefebvre@inria.fr
    17.



  17. Erosion (morphological) Structuring element (nozzle exit hole) Erosion: All points where  structuring element is entirely included CC BY-NC-ND     sylvain.lefebvre@inria.fr
    18.



  18. Perimeter     Visible part of the filament     Object contouring Erosion! (top view) CC BY-NC-ND     sylvain.lefebvre@inria.fr
    19.



  19. Plastic flow     How much plastic to push?     Millimeters of filament (E axis) E axis FA Nozzle diameter L Layer height Filament diameter Layer height x Nozzle diameter x L  Length to push = FA CC BY-NC-ND     sylvain.lefebvre@inria.fr
    20.



  20. Thin features Disappears!!! CC BY-NC-ND     sylvain.lefebvre@inria.fr
    21.



  21. Thin features ???? CC BY-NC-ND     sylvain.lefebvre@inria.fr
    22.



  22. A possible approach Skeleton CC BY-NC-ND     sylvain.lefebvre@inria.fr
    23.



  23. A possible approach CC BY-NC-ND     sylvain.lefebvre@inria.fr
    24.



  24. Arbitrary decision (user?) CC BY-NC-ND     sylvain.lefebvre@inria.fr
    25.



  25. Shells Note the gaps     More of the same Might become thin CC BY-NC-ND     sylvain.lefebvre@inria.fr
    26.



  26. Infills     Top / bottom covers     Inside     Full infill (very robust, slow, lots of plastic)     Sparse infill (save plastic and time, less strong) CC BY-NC-ND     sylvain.lefebvre@inria.fr
    27.



  27. 100% Infill CC BY-NC-ND     sylvain.lefebvre@inria.fr
    28.



  28. 100% Infill ??? CC BY-NC-ND     sylvain.lefebvre@inria.fr
    29.



  29. Flow control     Limited change of thickness Might not adhere 25% 100% 50% CC BY-NC-ND     sylvain.lefebvre@inria.fr
    30.



  30. 100% Infill CC BY-NC-ND     sylvain.lefebvre@inria.fr
    31.



  31. Speed Faster! Both axis work together: better acceleration CC BY-NC-ND     sylvain.lefebvre@inria.fr
    32.



  32. Sparse Infill     Simple approach CC BY-NC-ND     sylvain.lefebvre@inria.fr
    33.



  33. Sparse Infill Squish! CC BY-NC-ND     sylvain.lefebvre@inria.fr
    34.



  34. Sparse Infill An improved variant: Could be slow to print Resonance CC BY-NC-ND     sylvain.lefebvre@inria.fr
    35.



  35. Sparse Infill An improved variant: CC BY-NC-ND     sylvain.lefebvre@inria.fr
    36.



  36. Many other variants CC BY-NC-ND     sylvain.lefebvre@inria.fr
    37.



  37. Improving sparse infill ? Tradeoff between:     Strength vs Plastic consumption     Time and printability (favor straight, diagonal lines) Recent works:      [Wang et al. 2013]    Cost effective printing         [Lu et al. 2014]    Build to last         Slic3r 3D honeycomb Generates a 3D cellular pattern CC BY-NC-ND     sylvain.lefebvre@inria.fr
    38.



  38. New 3D infills     Just released :-) [3D infills, Sylvain Lefebvre, CC BY 4.0]     See http://sylefeb.blogspot.fr/ CC BY-NC-ND     sylvain.lefebvre@inria.fr
    39.
