Speed logs
Introduction
•
The speed log is a device used to measure the
speed of a moving vessel.
•
Unit used for expressing the speed of a vessel is
knots (Nautical miles/hour).Logs are used on
vessels to record the speed and also the number
of nautical miles the vessel has travelled through
the water in a given time.
•
Speed log are generally classified in to two types
•
i) Conventional logs
•
ii) Modern logs
Chip log or Ship log
•
The chip log or ship log - a crude speedometer invented
in 16
th
century to determine a vessels speed.
–
It was considered important first navigational tool for dead
reckoning.
–
Before the chip log was invented, a ship’s speed was
measured by dropping a small wooden piece in water just
ahead of the ship’s forward.
•
The time taken by the ship to move away from the
wooden piece was then noted with the help of
sandglass and on that basis an approximate speed was
calculated. This log was known as
Dutchman's Log.
•
The ship log was made with a quadrant
(quarter circle) shaped wooden board
attached to a log line.
•
Log line was knotted at regular intervals
and attached to the board with a bridle of
three lines connected to the holes made at
uniform spacing on the board
•
the lower side of the board was made of lead or
piece of lead at the centre of the circular side.
•
The log line was wound on a free turning reel.
•
The log chip was thrown overboard where it
floated vertically due to its ballasting.
•
A considerable length of log line was let out to
get the log chip into undisturbed water astern,
where its resistance to forward motion keeps it
essentially stationary in water (the wooded plank
stay at the same place in water).
•
As the ship moved forward, the line was pulled
off the reel.
•
This was usually a 30 second timer and gave
far more accurate results. Markings were
made on the log line which represented the
distance travelled by the ship.
•
A sand glass was also used to measure the
time taken by the ship to move away from
the chip log.
•
According to the length of the log line
released over the stern and the markings on
the line, the speed of the ship was calculated.
•
The name of the unit
knot
, for nautical mile
per hour, was derived from this method of
measurement.
RPM Counters
•
The engine revolution counters provide a
convenient means of determining speed
and distance. They automatically count
the revolutions of the propellers, and
show the total count continuously on
their dials. By means of a master counter,
average revolutions made by the
propellers can be obtained.
The Piometer Log
or
Pressure Log
or
Pilot Tube
•
The piometer log is similar to that of a pilot tube of
an aircraft.
•
A long tube called Rodmeter, is the main part of this
log that protrudes from the hull of the ship.
•
Rodmeter has two faces, one facing the direction of
the sea water flow and the other is perpendicular to
the flow.
•
The face of the opening in the direction of sea
water flow measures the dynamic seawater
pressure where as the perpendicular face measures
the static seawater pressure.
•
A difference of both these pressures is used to
measure the ship’s speed.
Principle
•
Two tubes with same diameter are immersed
in to the water below the vessel hull.
•
The first one is closed to one end and opens
at the other, is immersed in water with
opening facing down.
•
In this tube, static pressure develops, which
is proportional to the depth of the orifice or
opening below the water.
•
Another tube is similar to the first one, but
with an orifice opening sideways facing to
the direction of ship’s forward movement.
•
It is also immersed to the same depth and in
this tubes both static and dynamic pressures
are developed during vessel’s motion.
Components of Pilot log
•
1. Two openings outside the hull of the
ship, static tube that provides static
pressure and impact or Pilot tube that
measures dynamic pressure or the
water flow of pressure (Rodmeter)
•
2. Controller unit (pressure
differentiator)
•
3. Speed and distance transmitter
•
4. Speed and distance recorder
Operations
•
Pilot tube faces forward so that when the
vessel moves forward, the water causes a
pressure at the tube this dynamic pressure
is proportional to the speed at which the
vessel moves. The pressure differentiator
measures the differential pressure.
Impeller logs
•
An impeller or small propeller that projects outside the
vessel’s hull below the bottom of the boat.
•
The movement of the vessel’s hull through the water
causes the impeller to rotate.
•
The rotation of impeller produces the electric impulse
that is proportional to the counts or revolutions of
impeller and the is translated into distance and speed.
•
The problem with this log is that the projection below
the boat is liable to be damaged by fishing gear and
debris floating in water.
•
The Impeller Log is fitted in small sized vessels
including fishing vessels. A typical impeller log contains
the following components,
•
1. The log tube sensor assembly
•
2. The amplifier
•
3. Speed indicator and distance counter
Induction log or Electromagnetic
speed log or Em log
•
The electromagnetic speed log also called as
induction log or EM log measures the
electromagnetic induction generated in sea
water by its movement relative to magnetic
field by the electrodes fitted in the hull of a
vessel.
•
The sea water acts as the conductor and
generates an emf..
Electromagnetic Speed
Log
is highly accurate in indication of speed
though the water even at low speeds.
Principle
•
The flow of a conducting seawater past a
sensor causes electromagnetic induction in
the sensor which can be measured and
which is proportional to the speed of the
flow of the water.
•
A typical EM log consists the following parts
•
1. Master Indicator
•
2. Preamplifier
•
3. Sensor
Operation
•
EM log consists of two electrodes placed
beneath the hull.
•
Magnetic field is produced by an
electromagnet. In the electromagnetic log,
the potential difference generated in water
by its movement relative to the magnetic
filed is sensed by the electrodes.
•
The current induced in these electrodes by
the water flowing past is a function of speed.
•
The measurement of speed of a ships by this
log has been found to be accurately
economic and simple.
Advantages of EM Log
•
i) The sensor device doesn’t project
beyond the bottom of the ship.
•
ii) EM log operates with greater
accuracy and can measure smaller ship
speeds.
•
iii) Receiving device does not require
regular maintenance.
•
vi) Small in size.
Disadvantage
•
It cannot be used in freshwater.
Doppler log
•
Doppler Log
works with the principle of
Doppler Effect
.
•
When a sound beam is transmitted from a
moving vessel, difference (shift) in the
frequencies is observed between
transmitted sound and its reflected echo
from a target.
•
This frequency shift is known as the
“Doppler Shift”.
•
The degree of shift in the frequency is
proportional to the speed of the vessel
.
