1. LIGHTING CALCULATIONS LIGHTING CALCULATIONS

2. Lighting Calculations Lumen Method determines average light levels in large open areas Point Calculations determines light levels at a specific point on an object or surface

3. Lumen Method Calculations 1 foot candle (FC) = 1 Lumen (Lms) divided by 1 square foot (area / A) 1 FC = 1 LM A Illuminance (E) (amount of light falling onto an object measured in foot candles) = Lumens divided by Area (in sq. ft.) E = Lms A (sq. ft.)

4. Lumen Method Example 1 Solving for Illuminance(E) Level Room 10 x 15 5 down lights 1000 Lumens each down light E = Lms A Illuminance = Lumens divided by Area A = 10 x 15 = 150 sq. ft. 1000 Lumens x 5 down lights = 5000 lumens E = 5000 Lms 150 sq. ft. E = 37.5 Lms per sq. ft. E = 37.% foot candles (FC)

5. Lumen Method Example 2 Solving for Lumens or Luminaires needed Room 10 x 15 (A = 150 sq. ft.) Illuminance level (E) = 60 foot-candles Need Lumens / Luminaires E = Lms A - original equation Lumens needed = Illuminance x Area Lms = E x A Lms = 60 E x 150 sq. ft. Lms = 9000 Lumens

6. Lumen Method Example 2 Solving for Lumens or Luminaires needed Lumens needed = Illuminance x Area Lms = E x A Lms = 60 E x 150 sq. ft. Lms = 9000 Lumens 550 lumens = per luminaire Luminaires needed = Lumens needed divided by Lumens per luminaire Luminaires (X) = 9000 (lumens) 550 Lumens per Luminaire 9000 550 = 16.36 Always round up with any point. Luminaires needed = 17

7. Lumen Method Safety Factors Light loss factor (LLF) light loss due to deteriorating lamps Industry standard of .85 for a light loss factor Coefficient of Utilization (CU) effectiveness of luminaires working on surfaces of the space to deliver light to the target surface. Direct fixture or downlight CU = 85% (0.85) Indirect fixture CU = 50% (0.50) Spot or Accent CU = 95 (0.95) Wash or ambient CU = 75% (0.75)

8. Lumen Method Calculations with Safety Factors Illuminance = Lumens Area Illuminance = (Lumens x LLF x CU) Area Lumens needed = Illuminance target x Area Lumens needed = (Illuminance target x Area) (LLF x CU)

9. The Point Calculation Method Estimate location of lighting equipment Light density = Candle power = Candela Candela information given by Manufacturer Center Bean Candle Power CBCP center of a directional light Illuminance = Candela value Distance (squared)(in feet) E = CD D2

10. Point Calculation Example 1 10 -0 ceiling Accent Fixture Above a plate on a table 3; above the finished floor (A.F.F.) Illuminance = Candela value Distance2 E = CD D2 CD = 10,000 Candelas D2 = 7 ft 2 = 49 square feet (units get squared too) E = 10,000 CD 49 sq.ft. E = 204 Foot-candles

11. Point Calculation Example 2 10 -0 ceiling Accent Fixture Above a plate on a table 3; above the finished floor (A.F.F.) Candela value needed = Illuminance level desired x distance squared CD = E x D2 E = 150 Foot-candles D2 = 7 ft2= 49 sq. ft. CD = 150FC x 49 sq. ft. Candela value needed = 7350 Candelas

12. Luminaire and Lamp Type Candela represented in form of a distribution diagram Provided by manufacturers When sources is not perpendicular (90 degree angle to surface) Candela value needed = (Illuminance level desired x distance squared) cosine of the angle CD = (E x D2) cosine of angle E = (CD x cosine of angle) x D2

13. Point Calculation Example 3 10 -0 ceiling Accent Fixture Above a plate on a table 3; above the finished floor (A.F.F.) 30 degree angle for fixture 100 foot-candles Candela value needed = (Illuminance level desired x distance squared) cosine of angle CD = (E x D2) cosine of angle E = 100 FC (foot-candles) D2= 8.1 feet = 65 sq. ft. Cosine of angle = cosine of 30 degrees = 0.87 CD = (100 FC x 65 sq. ft.) 0.87 Candela value needed = 7471 Candelas.
