Howard Lighting Dusk to Dawn LED Fixtures

Howard Lighting offers a range of dusk to dawn LED fixtures including the DTDC Series for high-power and energy efficiency, the DTDU Series with tool-less entry, and the NO1 Series for LED energy-saving solutions. These fixtures provide excellent security lighting for residential areas, storage facilities, loading areas, and rural roadways.

• LED fixtures
• Dusk to Dawn
• Energy efficient
• Security lighting
• Residential areas

tyer911 Follow

Uploaded on Sep 25, 2024 | 1 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

You are allowed to download the files provided on this website for personal or commercial use, subject to the condition that they are used lawfully. All files are the property of their respective owners.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.

Presentation Transcript

1. Dusk To Dawn 2019

2. DTDC Series Features High-powered, energy efficient chip on board LED Replaces existing HID fixtures up to 100 watts Quiet operation, no audible hum or noise Factory installed 120V photo control Heavy-duty, die-cast aluminum housing Small, lightweight design Install direct to wall or use with mounting arm (optional) 5 year warranty Application: Howard Lighting DTDC LED Dusk To Dawn Fixture provides excellent security lighting for residential areas, storage facilities, loading areas, or rural roadways.

3. DTDC Series

4. DTDU Series Features High-powered LEDs 35W replaces existing 70W HID fixtures 48W replaces existing 100W HID fixtures Tool-less entry Heavy-duty, die-cast aluminum housing Photo control receptacle 5 year warranty Application: Howard Lighting DTDU LED Dusk To Dawn Fixture provides excellent security lighting for residential areas, storage facilities, loading areas, or rural roadways.

5. DTDU Series

6. NO1 Series Description The NO1 Night Owl is an LED energy saving, cost effective solution to replace 100 and 150 watt HID (HPS & MH) NEMA head fixtures. To access the driver compartment, surge suppressor, terminal block, and mounting brackets there is a tool-less entry door that opens from the bottom side of the housing. The optical compartment is IP66 and an optional tool-less refractor is available with or without a glare shield. The casting has integral tilt-adjustment steps + 5 degrees, optional seven (7) pin photo control receptacle, and two bolt mounting that Accepts 1-1/4 to 2 tenon arms.

7. NO1 Series Features 10 year standard warranty 0-10v dimming driver is standard with 7-pin photo control receptacle 3-pin photo control receptacle standard with non-dimming 120-277v driver Available in 50W and 70W Electronic driver has an expected life of 100,000 hours at 25C ambient Standard 4000K (optional 3000K) Standard with 10kV surge protection with 20kV/20kA surge protection optional 10 year warranty

8. NO1 Series
