1. Self-built Moodle Docker testing environments Alexander Dominicus #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

2. Why Docker containers? Make Software portable and self-contained Encapsulations of applications dependencies configurations Local running identically regardless of the host system isolated instances of an OS Whole class of bugs and errors solved #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

3. Pre-built or self-built? Pre-built easy configuration can be use instantly custom modification maybe difficult Self-built perfectly adapted to your needs perfectly known add, modify and remove services make data persistent you have to learn Docker beforehand Examples moodle-docker (moodlehq) bitnami moodle #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

4. Self-built! How to start? Install Docker and Compose See Moodle system requirements Think about your needs Create a compose file #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

5. Self-built! How to start? Install Docker and Compose See Moodle system requirements Think about your needs Create a compose file +web server! #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

6. Create a compose file #docker-compose.yml version: "2" services: #DB service docker_moodle-db: #PHP service docker_moodle-app: #web server docker_moodle-web: networks: docker_moodle: external: false docker_moodle-db: image: wodby/mariadb:10.4 restart: always container_name: docker_moodle-db environment: - MYSQL_USER=moodleuser - MYSQL_PASSWORD=mysecretpassword - MYSQL_DATABASE=moodle - MYSQL_ALLOW_EMPTY_PASSWORD=true volumes: - ./dbdata:/var/lib/mysql - ./conf/mycustom.cnf:/etc/mysql/conf.d/custom.cnf expose: - "3306" networks: - docker_moodle [....] [....] [....] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

7. Create a compose file #docker-compose.yml version: "2" services: #DB service docker_moodle-db: #PHP service docker_moodle-app: #web server docker_moodle-web: networks: docker_moodle: external: false docker_moodle-app: build: context: PHP/ dockerfile: PHP.Dockerfile restart: always container_name: docker_moodle-app volumes: - ./moodle:/var/www/html - ./moodledata:/var/www/moodledata - ./conf/local.ini:/usr/local/etc/php/php.ini networks: - docker_moodle depends_on: - docker_moodle-db [....] [....] [....] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

8. Environment #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

9. Environment #PHP.Dockerfile FROM php:7.4-fpm RUN apt-get update && apt-get\ install -y zip [...] RUN docker-php-ext-install zip [...] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

10. Create a compose file #docker-compose.yml version: "2" services: #DB service docker_moodle-db: #PHP service docker_moodle-app: #web server docker_moodle-web: networks: docker_moodle: external: false docker_moodle-web: image: nginx restart: always container_name: docker_moodle-web volumes: - ./nginx.conf:/etc/nginx/nginx.conf:ro volumes_from: - docker_moodle-app ports: - "8088:8088" networks: - docker_moodle [....] [....] [....] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

11. #Start Container docker-compose up -d Network docker_moodle Container docker_moodle-db Container docker_moodle-app Container docker_moodle-web Created Startet Startet Startet #Check if http://localhost:8088 is available #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

12. Moodle at http://localhost:8088 #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

13. Next Step: Customisation phpMyAdmin Cron Setup a reverse-proxy (traefik) #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

14. phpMyAdmin 1. Shutdown containers if running 2. Modify docker-compose.yml 3. Start containers docker_moodle-pma: container_name: docker_moodle-pma image: phpmyadmin/phpmyadmin restart: always ports: - "8089:80" environment: PMA_HOST: docker_moodle-db networks: - docker_moodle depends_on: - docker_moodle-db #docker-compose.yml version: "2" services: docker_moodle-app: docker_moodle-web: docker_moodle-db: #phpMyAdmin docker_moodle-pma: networks: docker_moodle: external: false [....] [....] [....] [....] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

15. phpMyAdmin at http://localhost:8089 #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

16. Cron 1.) shutdown containers 2.) modify docker-compose.yml #cron service docker_moodle-cron: container_name: docker_moodle-cron build: context: . dockerfile: Cron.Dockerfile volumes_from: - docker_moodle-app restart: always volumes: - ./log/cron:/var/log/cron networks: - docker_moodlefault depends_on: - docker_moodle-db #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

17. Cron 1.) shutdown containers 2.) modify docker-compose.yml #Cron.Dockerfile FROM php:7.4-fpm RUN apt-get update && apt-get install y\ cron [...] #cron service docker_moodle-cron: container_name: docker_moodle-cron build: context: . dockerfile: Cron.Dockerfile volumes_from: - docker_moodle-app restart: always volumes: - ./log/cron:/var/log/cron networks: - docker_moodlefault depends_on: - docker_moodle-db # Copy cron file to the cron.d directory COPY crontab /etc/cron.d/cron # Apply cron job RUN crontab /etc/cron.d/cron # Run the command on container startup CMD cron [...] #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

18. #Start Container docker-compose up -d Network docker_moodle Container docker_moodle-db Container docker_moodle-app Container docker_moodle-web Container docker_moodle-pma Container docker_moodle-cron Created Startet Startet Startet Startet Startet #Check if Cron is running docker logs docker_moodle-cron #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

19. #cron logs Execute scheduled task: task1 (path/to/task1) ... started 07:06:04. Current memory use 33.4MB. some information... ... used 1 dbqueries ... used 0.039605140686035 seconds Scheduled task complete: task1 (path/to/task1) Execute scheduled task: task2 (path/to/task2) ... started 07:06:04. Current memory use 33.4MB. ... used 0 dbqueries ... used 0.00094699859619141 seconds Scheduled task complete: task2 (path/to/task2) ... #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

20. Reverse-Proxy Make docker apps accessible via URL Only necessary ports exposed Simplify SSL implementation (if needed) After moodle.example.com: moodle pma.example.com: phpMyAdmin Before port 8088: moodle port 8089: phpMyAdmin #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

21. Reverse-Proxy Make docker apps accessible via URL Only necessary ports exposed Simplify SSL implementation (if needed) Docker moodle moodle.localhost pma.localhost Traefik Docker pma moodle.example.com Docker moodle 2 #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

22. Reverse-Proxy 1.) shutdown containers 2.) setup Traefik 3.) modify docker-compose.yml #Webserver docker_moodle-web: image: nginx restart: always container_name: docker_moodle-web: volumes: - ./nginx.conf:/etc/nginx/nginx.conf:ro volumes_from: - docker_moodle-app # ports: labels: - "traefik.enable=true" # enables the service - "traefik.http.routers.moodle.rule=Host(`moodle.localhost`)" #exposed domain networks: - reverse-proxy-network - docker_moodle #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

23. Moodle available at http://moodle.localhost #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.

24. Thank you for your attention! Any questions? alexander.dominicus@hs-bochum.de https://github.com/Dmfama20/docker_moodle_minimal https://github.com/Dmfama20/docker_moodle_full #mootglobal22 | Alexander Dominicus - Self-built M. Docker testing env.
