BMC IPMI LED Control Commands
RS700A-E11-RS12U
•
BMC IPMI LED Control
A : BP MG9098 slave address
Bay 1~8
0xc0
Bay9~12
0xc2
B : Write Drive Control Status
0x3c
SGPIO/SHP Override Register
C: Bit 0~7 =Bay1~8
1 = SMBUS (BMC) controlled LED blinking.
0 = SGPIO/SHP controlled LED blinking.
0x42
Locate Bitmask
0x44
Fail Bitmask
0x46
Rebuild Bitmask
C : Bit 0~7 – Drive 0~7
0:off ; 1=on
LED Command
# Disable BMC Sensor Scan
ipmitool -I ms raw 0x30 0x02 0x00
# Setting BMC GPIOX6 to Low
ipmitool -I ms raw 0x30 0x23 0xbe 0x01 0x00
# Switch 9546-E2 switch to channel 3
ipmitool - I ms raw 0x06 0x52 0x03 0xe2 0x00 0x08 0x08
# Enable BMC Sensor Scan
ipmitool -I ms raw 0x30 0x02 0x01
LED Command
Bay 1-8
A : BP MG9098 slave address
Bay 1~8
0xc0
B : Write Drive Control Status
0x3c
SGPIO/SHP Override Register
C: Bit 0~7 =Bay1~8
1 = SMBUS (BMC) controlled LED blinking.
0 = SGPIO/SHP controlled LED blinking.
0x42
Locate Bitmask
0x44
Fail Bitmask
0x46
Rebuild Bitmask
C : Bit 0~7 – Drive 0~7
0:off ; 1=on
Command :
Bay 9-12
A : BP MG9100 slave address
Bay 9~12
0xc2
B : Write Drive Control Status
0x3c
SGPIO/SHP Override Register
C: Bit 0~3 =Bay9~12
C: Bit 4~7 =Bay21~24
0x42
Locate Bitmask
0x44
Fail Bitmask
0x46
Rebuild Bitmask
C : Bit 0~7 – Drive 0~7
0:off ; 1=on
1 = SMBUS (BMC) controlled LED blinking.
0 = SGPIO/SHP controlled LED blinking.
This content provides detailed commands for controlling LEDs using BMC IPMI for RS700A-E11-RS12U server systems. It includes instructions for LED commands, disabling sensor scans, setting GPIO status, and more, along with specific configurations for drive control status and LED blinking patterns for Bay 1-8 and Bay 9-12.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
RS700A-E11-RS12U BMC IPMI LED Control
LED Command ipmitool I ms raw 0x06 0x52 0x03 0xc0 0x00 0x3c 0xff C B A A : BP MG9098 slave address Bay 1~8 0xc0 Bay9~12 0xc2 B : Write Drive Control Status 0x3c SGPIO/SHP Override Register C: Bit 0~7 =Bay1~8 1 = SMBUS (BMC) controlled LED blinking. 0 = SGPIO/SHP controlled LED blinking. 0x42 Locate Bitmask 0x44 Fail Bitmask 0x46 Rebuild Bitmask C : Bit 0~7 Drive 0~7 0:off ; 1=on
# Disable BMC Sensor Scan ipmitool -I ms raw 0x30 0x02 0x00 # Setting BMC GPIOX6 to Low ipmitool -I ms raw 0x30 0x23 0xbe 0x01 0x00 # Switch 9546-E2 switch to channel 3 ipmitool - I ms raw 0x06 0x52 0x03 0xe2 0x00 0x08 0x08 LED Command # Enable BMC Sensor Scan ipmitool -I ms raw 0x30 0x02 0x01
Bay 1-8 ipmitool I ms raw 0x06 0x52 0x03 0xc0 0x00 0x3c 0xff C B A Command : A : BP MG9098 slave address Bay 1~8 0xc0 B : Write Drive Control Status 0x3c SGPIO/SHP Override Register C: Bit 0~7 =Bay1~8 1 = SMBUS (BMC) controlled LED blinking. 0 = SGPIO/SHP controlled LED blinking. 0x42 Locate Bitmask 0x44 Fail Bitmask 0x46 Rebuild Bitmask C : Bit 0~7 Drive 0~7 0:off ; 1=on
Bay 9-12 ipmitool I ms raw 0x06 0x52 0x03 0xc2 0x00 0x3c 0xff C B A A : BP MG9100 slave address Bay 9~12 0xc2 B : Write Drive Control Status 0x3c SGPIO/SHP Override Register C: Bit 0~3 =Bay9~12 C: Bit 4~7 =Bay21~24 1 = SMBUS (BMC) controlled LED blinking. 0 = SGPIO/SHP controlled LED blinking. 0x42 Locate Bitmask 0x44 Fail Bitmask 0x46 Rebuild Bitmask C : Bit 0~7 Drive 0~7 0:off ; 1=on
