How the Open Compute hardware community gets rid of all the traditional overkill in Enterprise Datacenters John Laban
John Laban Reset Catalyst OCP Foundation Who am I john.laban@opencompute.org +44 7710 124487 @rumperedis
What is OCP Resetting intuitive mindsets Traditional Data Centre Traditional server rack Software eats hardware OCP optimised Data Centre Thought for the day Agenda
The Open Compute Project Foundation is a non profit open source hardware community which since its formation in 2011 has been positively disrupting the 20thCentury Data Century Industry What is OCP www.opencompute.org
Nine OCP Projects & Technologies Incubation Committee Project Leads HPC Storage Open Rack Data Centre Server HW Mgmt. Networking Telco Interoperability
Technology Contribution Process What is OCP Reviewed by community Member makes a contribution Posted on opencompute.org Voted by incubation committee Including technical documents Available to the public
OCP Technology Principles Efficiency - performance, cost, conversion & cooling What is OCP Scale out - Tool-less design, OCP compliant management tools and documentation Openness - Open Source, Open Interface, OCP Compatible Impact - Efficiency gains, new technology, leverage/empower prior contributions and enhance supply chain
RESETTING INTUITIVE MINDSETS Open source collaboration is a better way Construct Data Centre facilities at half the cost of traditional Servers that use 30% less energy Software that eats 80% of the physical server nodes Data Centre PUE s better than 1.1 99% reduction in server support technicians
Traditional Enterprise Datacenter Enterprise data centre located in UK Uptime Institute Tier III Centralised UPS with 15min VRLA batt autonomy Split DX down flow CRACs into access floor 144 racks totalling 6,480 EIA rack Units 70% of U s filled with servers = 4,536 nodes Average 5 kW load per rack PUE = 1.8 IT Load = 720 kW Total facility load = 1,296 kW Annual kW hrs = 11,352,960 Annual electricity cost @10p kW hr = 1,135,296 Annual UK CO2e = _________ kg (see slide notes) 24 racks 24 racks 24 racks 24 racks 24 racks 24 racks
20thCentury Gear removed by OCP : 2 x TOR Switches 4 x Pluggable optics 86 x PSU s 208 x 40mm Fans 4 x AC Power Strips 86 x IEC rear power cords 120 x RJ45 rear patch cords N+1 CRAC units Access Floor Cables in floor
5,500 per year for 38 million cars in France (10% of French GDP) 96% time stopped 0.5% in traffic jams 0.8% looking for parking 2.7% travelling from A to B (its Function) 3 out of 4 journeys have one person in car Asset efficiency is very low! Software eats hardware Radio 4 In Business interview Frederic Mazzella CEO & Founder Bla Bla Car 18
Software eats hardware What is the ICT asset efficiency in traditional enterprise data centre ?
Virtual Machines Software eats hardware 33% less 66% less No VMs Heavy weight VMs 2008 Light weight VMs 2018
Hack & Hip Hop Virtual Machines Software eats hardware 80% less web server nodes No HHVMs With HHVMs
OCP optimised datacenter Some of the over kill removed from a traditional enterprise data centre
Traditional OCP OCP optimised datacenter Mechanical Cooling yes no Access Floors yes no Centralised UPS yes no Intelligent PDU s 450 0 Racks 144 110 Server nodes 4,536 2,994 Server AC/DC PSU s 9,072 110 rack rectifier shelves PUE 1.8 Better than 1.3 DC Facility construction cost $10,000,000 Reduces by > 50% Annual Electricity Cost 1,135,296 Reduces by > 500,000
Colo space in Europe expanded by 20% whilst global server market shrinks 5% Thought for the day
John Laban Reset Catalyst OCP Foundation European Region + 44 7710 124487 john.laban@opencompute.org Contactgegevens
