Timing Models in Cell Design Environments
Submitted by
HARSHITHA G H
Provide accurate timing for various instances of the
cell in design environment.
The timing models are specified for each timing arc
of the cell.
Define the delay arcs between nodes
Since it is an inverter, a rising (falling) transition at the input
causes a falling (rising) transition at the output. The two kinds of delay
characterized for the cell are:
•
Tr
: Output rise delay
•
Tf
: Output fall delay
Delay for timing arc through inverter cell is dependent
on two factors:
1.
the output load, that is, the capacitance load at the
output pin of the inverter
2.
the transition time of the signal at the input.
Delay increases with load capacitance, input
transition time.
Two types of Timing models
Linear Timing Models
Non-Linear Delay model
The delay and output transition time of cell are the
linear functions of the two parameters.
Input transition time and Output load capacitance.
Example
D=D0+D1*S+D2*C
Where
D is delay of Linear model
D0,D1,D2 – Constants S – Input transition time
C – Output load capacitance
cell libraries include table models to specify the
delays and timing checks for various timing
arcs of the cell.
The table models are referred to as NLDM
(Non-Linear Delay Model) and are used for
delay, output slew, or other timing checks.
In this example
Delay of the output pin
OUT are described.
Rising and falling delay
models for the timing arc
from pin INP1 to pin
OUT and max_transition
at pin OUT.
Separate models for the
rise and fall delays,
labeled as cell_rise and
cell_fall respectively.
Can also be used for
transition time at the
output of a cell.
In general, the timing arcs can
be from each input to each
output of the block
logic path from input to output
is non-inverting(positive unate),
then the output has the same
polarity as the input
If it is an inverting logic path or
negative unate, the output has
an opposite polarity to input
General combinational block
For synchronous inputs – timing
arcs:
Setup check arc (rising and
falling)
Hold check arc (rising and
falling)
For asynchronous inputs – timing
arcs
Recovery check arc
Removal check arc
