1. Structs COMP 11

2. Example: Celebrity Heights #name feet inches Task: Write a program that reads in a list of celebrity heights from a file and outputs ***insert generic statistic here***. Danny_Devito 5 0 Oprah_Winfrey 5 7 Q: How should we store the data? A: 3 arrays of same length Tom_Cruise 5 7 Nicole_Kidman 5 10.5 A: 1 array of packaged data Bernie_Mac 6 2.5

3. Structs A struct is a package used to hold different types of data. - can be passed around like any other variable - we can access members of a struct individually - need to define the struct s type first Components of a struct definition: 1. struct keyword struct Celeb { string name; int feet; float inches; }; } 2. Name (typically capitalized) 3. Member declarations (in { }) 4. Semicolon after { }

4. Working with struct variables struct Celeb { string name; int feet; float inches; }; Nicole_Kidman one_celeb 5 int main() { Celeb one_celeb; 10.5 *bookkeeping* one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; return value return address argv cout << "Name: " << one_celeb.name << endl; cout << "Height: " << one_celeb.feet << " feet, "; cout << one_celeb.inches << " inches" << endl; argc }

5. Different structs, same members? struct Celeb { string name; int feet; float inches; }; struct Professor { string name; string courses[10]; int age; }; Totally fine! Member names are local to a given struct. int main() { Celeb one_celeb; Professor richard; one_celeb.name = "Nicole_Kidman"; richard.name = "Richard"; richard.courses[0] = "COMP 11"; }

6. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; }

7. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } This modifies a copy of the struct passed as an argument, not the original. one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; }

8. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } Nicole_Kidman c 5 10.5 one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; Nicole_Kidman one_celeb 5 10.5 }

9. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } Nicole_Kidman 5 10.5 one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; Nicole_Kidman 5 10.5 }

10. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } Nicole_Kidman 105 10.5 one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; Nicole_Kidman 5 10.5 }

11. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } Nicole_Kidman 105 10.5 one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; Nicole_Kidman 5 10.5 }

12. Structs, Functions struct Celeb { string name; int feet; float inches; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; one_celeb.name = "Nicole_Kidman"; one_celeb.feet = 5; one_celeb.inches = 10.5; Celeb grow(Celeb c) { c.feet += 100; return c; } one_celeb = grow(one_celeb); cout << one_celeb.name << " is now "; cout << one_celeb.feet << " feet tall!"; cout << endl; return 0; Nicole_Kidman 105 10.5 }

13. Exercise: Structs, Functions struct Bulb { int watts; int lumens; }; 1. Which part of this code defines a struct type? Bulb dim(Bulb b) { Bulb c = b; c.watts += 10; return b; } 1. How many members does the Bulb type have? 1. What does this code print? int main() { Bulb lightA; lightA.watts = 20; Bulb lightB = dim(lightA) cout << lightB.watts << " " << lightB.lumens; return 0; }

14. Exercise: Structs, Functions struct Bulb { int watts; int lumens; }; Two members 1. Which part of this code defines a struct type? Bulb dim(Bulb b) { Bulb c = b; c.watts += 10; return b; } 1. How many members does the Bulb type have? 1. What does this code print? int main() { Bulb lightA; lightA.watts = 20; Bulb lightB = dim(lightA) cout << lightB.watts << " " << lightB.lumens; return 0; } 20 <???>

15. So many more copies of array elements... Structs, Functions struct Celeb { string name; int feet; float inches; string every_movie[100]; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; //Initialize one_celeb Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 5 10.5 movies[0] movies[1] Lots of array elements... one_celeb = grow(one_celeb); Q: What happens on the stack when we pass this struct as an argument? //Do stuff with one_celeb return 0; } A: Every array element is copied! movies[99]

16. Structs, Functions struct Celeb { string name; int feet; float inches; string every_movie[100]; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; //Initialize one_celeb Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 5 10.5 movies[0] movies[1] Lots of array elements... one_celeb = grow(one_celeb); //Do stuff with one_celeb return 0; } movies[99]

17. Structs, Functions, Pointers struct Celeb { string name; int feet; float inches; string every_movie[100]; }; Celeb grow(Celeb c); int main() { Celeb one_celeb; //Initialize one_celeb Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 5 10.5 movies[0] Pass a struct pointer to avoid excessive copying! movies[1] Lots of array elements... one_celeb = grow(one_celeb); //Do stuff with one_celeb return 0; } movies[99]

18. Structs, Functions, Pointers c celeb_p struct Celeb { string name; int feet; float inches; string every_movie[100]; }; void grow(Celeb *c); int main() { Celeb one_celeb; //Initialize one_celeb Celeb *celeb_p = &one_celeb; grow(celeb_p); Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 5 10.5 movies[0] Pass a struct pointer to avoid excessive copying! movies[1] Lots of array elements... void grow(Celeb *c) { (*c).feet += 100; } //Do stuff with one_celeb return 0; } movies[99]

19. Structs, Functions, Pointers c celeb_p struct Celeb { string name; int feet; float inches; string every_movie[100]; }; void grow(Celeb *c); int main() { Celeb one_celeb; //Initialize one_celeb Celeb *celeb_p = &one_celeb; grow(celeb_p); Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 105 10.5 movies[0] Pass a struct pointer to avoid excessive copying! movies[1] Lots of array elements... void grow(Celeb *c) { (*c).feet += 100; } //Do stuff with one_celeb return 0; } movies[99]

20. Structs, Functions, Pointers celeb_p struct Celeb { string name; int feet; float inches; string every_movie[100]; }; void grow(Celeb *c); int main() { Celeb one_celeb; //Initialize one_celeb Celeb *celeb_p = &one_celeb; grow(celeb_p); Nicole_Kidman Structs are passed-by-value: every member is copied when passed to/returned from a function. 105 10.5 movies[0] Pass a struct pointer to avoid excessive copying! movies[1] Lots of array elements... void grow(Celeb *c) { c->feet += 100; } //Do stuff with one_celeb return 0; } Access member mem of struct pointer p with either (*p).mem OR p->mem. movies[99]

21. Demo: structs, functions, and pointers Task: Write a program that reads in a list of celebrity heights from a file and outputs ***insert generic statistic here***. The file will start with some integer n, then the following n lines will each have the height info for one celebrity.
