1. IFPS Error Messages in Flight Plan Rejections Status report Tihomir Todorov Head of Section Airspace Design 29 JAN 2018

2. Problem Statement Today, in case a flight plan is on a correct (lateral) routing, but does not respect a certain type of vertical constraint (normally coming from LoA restrictions), an error message generated by IFPS sometimes wrongfully contains the phrase: "on forbidden route". This is misleading and may be perceived as a request for lateral rerouting, potentially causing unnecessary costs due to increased fuel burn and delay, instead of correctly, indicating the infringement of a vertical constraint. PROPOSED SOLUTION In order to improve IFPS error messaging and also RAD efficiency, a distinction needs to be made in error messages between infringements of a restricted flight level (or level band) and infringements of a restricted route (e.g. for selected destinations). Document Confidentiality Classification: Green

3. Example Invalid FPL in IFPS that reports the error IS ON FORBIDDEN ROUTE . (FPL-TEST-IN -GALX/M-SDFGHM3RWXY/H -LEPA1130 -N0467F360 MEROS UN853 KINES -LSGG0118 LFLL -PBN/A1B2B3B4D2D3) PROF204: RS: TRAFFIC VIA IRMAR IS ON FORBIDDEN ROUTE REF:[LSLF1113K] IRMAR Document Confidentiality Classification: Green 3

4. Example LSLF1113K requires the flight below FL305 at IRMAR IRMAR Not available for traffic 7. ARR BERN_GROUP, GENEVA_GROUP,GENE VA_AREA a. Above FL305 LUSOL IRMAR KINES Document Confidentiality Classification: Green 4

5. Example The insertion of a flight level change makes the FPL valid: (FPL-TEST-IN -GALX/M-SDFGHM3RWXY/H -LEPA1130 -N0467F360 MEROS UN853 LUSOL/N0470F300 UN853 KINES -LSGG0118 LFLL -PBN/A1B2B3B4D2D3) Document Confidentiality Classification: Green 5

6. Current Status The request for system change has been made (CR_035910). The initial assessment of the change resulted in an estimate of a high cost to implement. The change is in the queue for implementation in a future NM release with no concrete release identified. Document Confidentiality Classification: Green 6

7. QUESTIONS and COMMENTS Document Confidentiality Classification: Green
