Error Handling Techniques in VBA Programming


Error Handling

We already have seen type of errors and how to debug
our programs.
Especially the run time errors and logical errors are hard
to be found and estimated on design time.
No matter how carefully you design and code for all
conditions, there is always a user who does something
that you never thought of and effectively breaks the set
of rules that you have written.
So, in order to develop more reliable application, we
have to use error handling in our code.

2

Error Handling

Any run time error
 will stop execution of your

program.
The user will be very unhappy and will lose a great deal
of faith in your application.
The error needs to be trapped, and an appropriate
action needs to be taken from within the

VBA code
(Debugging)
.
Error handling
 techniques
may are
 also
be
used
for
capturing runtime errors that can halt the running
program.

3

Error Handling

On Error GoTo

statement
This command is used like exception handling command
of C, C++, C#, Java, JavaScrip (try … catch …)
Try this simple example without a disk in drive D.
Sub Test_Error()

temp = Dir("d:\*.*")
End Sub
This will produce an error message saying that the D drive is
not ready.
In normal terms, your

program has crashed and will not
work any further until this error is resolved.

4

Error Handling

On Error GoTo

statement
You can place a simple error-trapping routine as follows:
Sub Test_Error()
On Error GoTo err_handler
temp = Dir("d:\*.*")
Exit Sub
err_handler:
MsgBox "The D drive is not ready" & " " & Err.Description
End Sub
The first line sets up a routine to jump to when an error occurs
using the On Error statement.

5

Error Handling

It points to
err_handler
, which is a label just below the
Exit Sub
line further down that will

deal with any error condition.
The purpose of a label is to define a section of your code you
can jump to by using a
GoTo
 statement.
The line to read the D: drive is the same as before, and then
there is an Exit Sub line,

because if all is well you do not want
the code continuing into the
err_handler
 routine.
If an error happens at any point after the
On Error
 line, the
code execution jumps to

err_handler
 and displays a message
box that says drive D is not ready.

6

Error Handling

However, you may

have noticed that the code execution
jumps to
err_handler
 when any error occurs, not just

the drive
not ready error.
An error could occur because you made a mistake in typing
this

code in.
This could have unfortunate consequences in your code.
Fortunately, you can interrogate the error to find out what
went wrong
.
You can also use

the
Err
 object to give the description of the error
and to concatenate it into your message so

that it also says “Drive
not ready.”

7

Error Handling

You do this using the
Err
 function.
This will return the

number associated with the runtime error
that happened.
Sub Test_Error()
On Error GoTo err_handler
    temp = Dir("d:\*.*")
    Exit Sub
err_handler:
    If Err.Number = 71 Then
        MsgBox "The D drive is not ready"
    Else
        MsgBox "An error occurred"
    End If
   Resume
End Sub

8

Error Handling

You can also add the statement
Next
 to
Resume
.
This will skip over the statement that

created the error
and therefore ignore the error.
Sub Test_Error()

On Error Resume Next

temp = Dir("d:\*.*")
End Sub
If there is no disk in drive D, the code will still run perfectly
because of
On Error Resume

Next
I
t skips over the line of code creating the error.
Resume Next can be useful for dealing with errors as they
occur, but it can make

debugging code very difficult.

9

Error Handling

In a later stage of your program, you may have incorrect
or

nonexistent data being produced due to the fact that
an error condition earlier was ignored.
You can end up with a program that appears to run
okay, but in fact does nothing because it

has some
hidden bugs or incomplete data.
This is because every time an error is encountered,

the
execution just skips over it.
This can give a false impression of what is actually
happening
.

10

Error Handling

S
o if you do use On Error Resume Next, make sure that
you check all inputs and outputs to

the code to ensure
that everything is working as it should be.
Make sure that your
On Error

Resume Next
statement
cannot cover up an error
 in a read from a spreadsheet
cell or from

a file.
This could cause disaster in your program because the
On Error Resume Next

statement would make it appear
to work perfectly.

11

Implications of Error Trapping

When you use an On Error statement in your code, that
error trap remains throughout the

procedure unless it is
disabled.
As you just saw, you can set up a routine to check
whether the

D: drive has a disk in it and take action
accordingly.
However, it is important to turn this off

once the possibility
of the error has taken place.
If you do not do this, then all subsequent

errors within
that procedure will use the same error-handling routine.

12

Implications of Error Trapping

This gives extremely

confusing results to the user, as the
error message is likely to be totally meaningless in
relation to the error generated.
A subsequent error could relate to division by zero, but
the

error message will come up saying “Drive D not
ready.”
If On Error Resume Next has been used and not switched
off, all sorts of errors could be

taking place without the
user being aware of them. You disable the error-trapping
routine as

follows:
On Error Resume Next
On Error GoTo 0

13

Implications of Error Trapping

On Error Resume Next
On Error GoTo 0
The On Error Resume Next statement that you saw
previously ignores all errors.
The On

Error GoTo 0 cancels any error handling and
allows all errors to be displayed as they

normally would.
This cancels out the On Error Resume Next and puts
everything back to

normal error handling.

14

Generating Your Own Errors

In order to detect and recover logical errors
;
 at the
beginning you may define your
rules
 and anything else
as errors.
Then you can handle these
with
 the same

way
in the
error handling systems.
Example: if the legal working age should be anything
between 18 to 65, you may define any age less them 18
and greater then 65 is a user defined error.
To generate a run-time error you can use the Raise
method
 Err Object
Err.Raise(Number [, Source] [, Description])

15

Generating Your Own Errors

Err.Raise(Number [, Source] [, Description])
Number
Long, identifying the type of the error. Visual Basic errors range from 0 to
65535
The range 0 - 512 is reserved for system errors
The range 513 - 65535 is available for user defined errors
If (w_age<18) Or (w_age>65)
Err.Raise
1500, ,«Working age have to be (18-65)»
Source
String
If this is not specified then the programming ID of the current project is used.
Description
This the string that describes the error.
If the error can be mapped to a Visual Basic run-time error the string
corresponding to the Number is
u
sed.
If there is no Visual Basic error corresponding to the number then
"Application-defined or object-defined error" message is used.

16

Generating Your Own Errors

Sometimes it is useful when you are testing your own applications or
when you want to treat a particular condition as being equivalent to a
runtime error.
You can generate an error in your code with the Error statement:
Sub Test_Error()
     Error 71
End Sub
This simulates the “Drive not ready” error. You could also use
Err.Raise(71) to do this.
In addition, you can regenerate the current error by using the following:
Error Err
The purpose of this is to raise the “Drive not ready” error message as if
the drive really was not ready because this is the current error found.
If another error message is then created, this becomes the current error.

17
