DArT-2 tests

Luciano Romero, Ludovico Luzzi, José Manuel Cela
DArT Collaboration meeting
27-July-2022

DArT-2 tests

DArT-2 and DArT-Test are twin experiments.
DArT-Test to give information about the operation and problems of DArT-2
DArT-2 to operate in ArDM to study the underground argon
The main objective of the tests described here is to guarantee the
performance of DArT-2
During construction and operation
Types of tests
Electronic test of the PDMs
Vacuum test to check leaks.
Physic test
39Ar measurement
Alphas measurement

Electronic tests of the PDM

IV curve of the SiPM at room temperature (RT)
IV curve of the SiPM at cryogenic temperature (CT)
Dark current rate (CT) (noise)
Finger plot of dark current (CT) (gain)
Finger plot of LED driven light pulses (CT) (gain)

This set of measurements guarantee the correct operation of the
PDMs and of the DAQ

Electronic tests of the PDM

First test already done on PDM reception
One PDM rejected (#70)
9 working properly
Presented on 6 of July of 2022
Second test to be done with the PDM mounted in DArT-2
To mininize connection/disconnection of PDM (risky)
Light tight enclosure.
No need of vacuum tightness.
Vessel cooled with liquid nitrogen at atmospheric pressure
Using a provisional small cryostat
DArT-2 vessel filled with gaseous nitrogen or dry air.
Test noise with definitive power supplies
Any problem can be easily fix.
Subsecuent tests to be done with DArT-2 inserted in ArDM
ArDM and DArT-2 filled with cold gaseous argon
ArDM and DArT-2 filled with cold liquid argon


Vacuum test of the vessel

First test to be done at RT with a provisional teflon seal.
At room temperature
To assure the quality of the soft copper weldings
Second test to be done after DArT-2 assembly.
At room temperature
Once the PDMs have been validated
With definitive vessel seal made of 3 mm indium wire.
Subsecuent cryogenic tests with DArT-2 mounted within ArDM
Do not flash cool the vessel (See next slide)


Vacuum problems in DArT-Test

We poured LN2 into the cryostat containing DArT-Test
The entire copper vessel is cooled very fast by the LN2
Due to the high heat conductivity of the copper: 385 W/(mK)
The top flange is not cooled so fast
It is cooled by the vessel through the indium seal
Let assume a momentary difference of temperature of 100K between
flange and vessel.
The maximum displacement between flange and vessel is:
17 10
-6
 K
-1
 x 100 K x 0.12 m = 0.2 mm
Enough to weak the indium seal
Use conical springs to assure the sealing of the indium wire

Physic test

Vacuum and PDM tests done before.
Need liquid argon inside DArT-2
Physics test are to be done within cold ArDM
Not possible to do it in the current test cryostat (See next slide)
Let ArDM be filled with cold argon gas
To avoid time consuming filling of LAr
1 option: Condensate the liquid argon inside DArT-2
Increasing the argon pressure in DArT-2
Its no clear if the heat dissipation by gas convection allow the filling in a reasonable
time.
2 option: Fill DArT-2 directly from a LAr commercial range
Through the thin (CF16) gas connection

Why is not possible to use the current
cryostat to do physics test

The original design use SAGANA D22
ferrules to join DArT to the gas system
The use of ferrules was discarded
because of vacuum leaks.
In current design DArT is welded directly
to a CF40 flange
Old design allows the coupling of DArT to
the cryostat flange
The ferrule goes through the 40 mm pipe of
the flange.
This is no longer possible with the new
design

3-April-2019
