Smart Virtual Store Software Graduation Project Overview
Smart Virtual Store
Prepared by
Yaman A. Salman
Eman M. Masarweh
2012
Software graduation project
Outline
•
What is Virtual store.
•
What is QR code
•
QR Generator .
•
QR Reader .
•
Mobile application .
•
Communication Between Customer and
Server.
•
Server of Smart Virtual Store
.
•
Smart Virtual Store Website
Motivation
Today, we live in a world of fast paced. People
do not have time to spare. Thus, we yearn for
comfort. Most of us are too busy, and we do
not have enough time even to go to the
grocery store. For this reasons, we created a
Smart Virtual Store to make shopping easier
and faster.
Achievements
•
QR Generator.
•
Mobile application scan a QR code and
form orders of products.
•
Server with desktop application that
receive orders .
•
Website .
We mean by Virtual Store , there is no physical products on
shelves just images of it on boards.
Virtual Stores can be Found in Subways, Streets and Garages
Overview
C
u
s
t
o
m
r
V
i
s
t
o
r
1
2
What is QR code ?!
•
Qrcode (Quick Response ) is two
dimensional barcode .
•
A QR Code stores data in both vertical
and horizontal directions and hence has
more storage capacity per unit area.
What is QR code
•
QR codes are readable from any direction and
that data stored inside QR codes can be
restored even if the corresponding image is
partially damaged.
QR Features
QR Generator
•
We generate the QR Code that encode a
string entered text .
Features of QR Generator :
•
Encode mode.
•
Version .
•
Error correction .
•
Structure of QR code symbol.
How to encode
1.
Capacity :Capacity of a QR code is determined by
version ,error correcting level and encoding mode .
2.
Encode to data code words.
3.
Calculating error correcting code words : this blocks
of redundant data ensure that the QR code can still
be read even if a portion of it is unreadable.
4.
After step 1 , 2 , 3 : data and Ec code words converted
to Binary in order to put them in the QR code.
How to encode
5.
Data allocation
:
we allocate encoded data , fixed pattern
,timing pattern .
6.
Mask pattern .
7.
Format information :Format information includes error
correcting level and mask pattern .
QR generator in our project
•
In our project build a C# desktop
application that can take a text data as
input and output QR code image of that
input after make all previous operations on
data to produce QR code .
•
Using generator in our project to produce
QRcode image for each product in store .
QR Reader
•
The QR Code reader used to decode a
QRCode image generated via the generator
we made , or any generated image by other
QR generators .
Bitmap image
1010111
0110011
1100011
0010101
Get finder pattern,
alignment pattern
0’s & 1’s Grid
Get rest of img
as data matrix
Get decoded
Bytes
Get data blocks
only
Using Reed
Solomon Algo.
ASCCI String
Mobile Application
•
With our mobile application customer can
capture image of product’s QRcode he want to
purchase ,select the quantity needed and time
of delivery , determine his address and send
order to server ,then reply message from
server arrived .
Using the Mobile Application to purchase from Virtual Store
Implementation
•
We implement this part by creating a j2me
application using net beans program it
contains :
•
Forms , Displays , Controls , lists ,radio
buttons .
Implementation
•
Capture image with specified Resolution ,
using video control and player .
Some Details:
1- Getting a Video Capture Player:
The first step in taking pictures (officially called video capture)
in a MIDlet is obtaining a Player from the Manager. A special
locator(capture://video), indicates that pictures will be
captured from the camera using a default image size.
mPlayer = Manager.createPlayer("capture://video");Implementation
The Player needs to be
realized
to obtain the resources that are
needed to take pictures
.
mPlayer.realize();
2- Showing the Camera Video
The video coming from the camera can be displayed on the
screen either as an Item in a Form or as part of a Canvas. A
VideoControl makes this possible. To get a VideoControl, just ask
the Player for it:
mVideoControl = (VideoControl)
mPlayer.getControl("VideoControl");Implementation
To show the video coming from the camera in a Canvas, we
initialize the VideoControl, then set the size and location of the
video in the Canvas, then make the video visible.
canvas = new CameraCanvas(this); // initialize video control
videoControl.initDisplayMode(VideoControl.USE_DIRECT_VIDEO,
canvas);
videoControl.setDisplayFullScreen(true);
videoControl.setVisible(true);
Implementation
3- Capturing an Image
•
Once the camera video is shown on the device, capturing an
image is easy. All you need to do is call VideoControl's
getSnapshot() method. You'll need to pass an image type, or
null for the default type.
•
The getSnapshot() method returns an array of bytes, which is
the image data in the format you requested. What you do at
this point is up to you
•
byte[] raw = mVideoControl.getSnapshot(encodingBest);
•
Image image = Image.createImage(raw, 0, raw.length);
Implementation
•
using QR Decoder decode image and
return the result ,QR Decoder is java class
in the app
QRCodeDecoder decoder = new
QRCodeDecoder();
result = new String(decoder.decode(new
J2MEImage(image)));
•
Code to send SMS to the server mobile .
•
Sending URL with parameters to the web
site
Problems & Solutions
•
P:
QRcode reader in mobile application
faced some problems in scanning the
image taken by mobile, so some times it
can’t return a correct result for reading.
•
S:
In order to avoid this problem we try
capture the image in a better elimination
environment.
Problems & Solutions
•
also we deal with the resolution of
captured image in the code
•
String encodingString =
System.getProperty("video.snapshot.encodings");•
String encodingBest= findBestEncoding(encodingString);
findBestEncoding
: is a user function that
read the encoding type , width and
height of the images that the mobile can
capture, and pass this encoding to
capture image method. This will improve
the resolution of captured image .
•
We use sandbox PayPal account (virtual)
so buyer and customer can pay the total
price of the order , money is cashed into
server PayPal account .
Communication Between
Customer and Server.
•
We use short messages service ( SMS)
as a communication tool from the
customer mobile (using our j2me app)
to
the server mobile
and vice versa.
•
in communication we use:
1.
Server mobile.
2.
AT commands
AT Command
•
For send message, write this code:
•
For read messages stored on the mobile, write
this code:
Server of Virtual Store
Sto.
•
It is C# application placed in the market machine to
serve requests from customers when they send their
orders via their phones.
•
After a message reach to the server ,this message
contains the items the customer order and basic info
about customer ,server will store this info in its data
base and after make sure that customer ‘s order is
stored .
•
server will send an acknowledgment
message to customer mobile that tell
him to wait the items.
Smart Virtual Store Website
•
Customers can sign up for a personal accounts, put their
information needed by the application, so they be able to
skip some of the data entry steps in the application. Just
by sign in to the account from the mobile application
then start purchasing items .
•
website receive order and stored it ,then continue the
payment process automatically based on paypal account
of user stored in his Smart Virtual Store account .
Cont
•
Customer can sign in to his profile , view
his Purchases during a specified period
of time , or since he register in the Store
and edit his Information .
•
Anyone can register the
site, website send email to this
person on the membership
confirmation.
Thanks For Attention
