1. Software Pedestal Subtraction and FIR

2. Pedestal Subtraction We work on ADC counts from a single channel only Only update when not in a hit (stop updating when sample 5 (configurable) ticks ahead is >10 (configurable-will change to actual threshold we want to use) ADC above current pedestal) Begin updating pedestal again when an ADC value below the pedestal is found (which for our hit-finder must be when a hit has ended (and potentially a little way after that if there was an upward drift in ped during hit) If we are updating pedestal then we increase or decrease pedestal by 1 ADC value each tick (frugal streaming) What issues might arise? How will FPGA implementation be different?

3. FIR We work on (pedestal subtracted) ADC counts from a single channel only Currently get the *value* for each tap from np.round(scipy.signal.firwin()*100) 7 taps (should update to 32?) Cutoff =0.1 Nyquist freq How many taps do we want implemented?

4. FIR We find each new ADC value after filtering by: For each tap find if the ADC sample index ,i, is larger than the tap index, j, (tap index loop nested within sample index loop) If it is: add old ADC value with index i-j to new ADC value If it isn t: add old ADC value with index 0 to new ADC value We will then need to divide the ADC statistics collected for each hit by 100 (the number we multiplied the tap *values* in order to make them int) How will FPGA implementation differ?

5. FIR 0 1,2,3,4,5,6, ,4490 4492 Input[0]*tap[0] Input[4491]*tap[0] Input[0]*tap[1] Input[4490]*tap[1] Input[0]*tap[6] Input[4485]*tap[6] For 7 taps
