Urban Design Techniques for City Improvement
undefined
Some urban theorists have developed concepts and techniques for urban improvement
that attempt to employ the more tenable tools of city building.
Some of these urban design techniques include the following :
1.
The Open Space Technique
2.
The Transportation System Technique
3.
The Capital Network Technique
4.
The Public Policies Technique
5.
The Physical Design Technique
6.
The Plug-in Technique
7.
The Individual Building
Architect-Planner S.B Zisman said that the essential question of planning is not where
to build but where not to build. The essential question to the planner is where to create
open space reserves. In an open space plan he would include every conceivable use
and type of open space – open space for parks, watersheds, public transit lines,
airports, community buildings, urban plazas, green belts, green wedges, avenues,
sidewalks, etc.
An open space would be the framework that would relate land development to
transportation allowing a wide latitude of decisions. Corridors of open space radiating
from a city’s center could be used for expressways or rail rapid-transit rights of way.
Open space reserves in developing suburbs would become community centers with
schools, churches and shopping. Large open spaces would be reserved for airports and
airlane glide and take-off paths.
In other words, open space itself would be recognized as the essential classification of
public landuse. Clear distinction can be made between open spaces for active uses and
for more passive uses.
In the 1950s Louis Kahn, FAIA, made a plan of patterns of movement in central
Philadelphia. The plan instead of showing fixed buildings and static urban spaces as a
composition, it showed motion – circulation. He wrote about motion as design in an
Article and wrote the following at the head of the article:
o
Expressways are like Rivers.
o
These Rivers frame the area to be served.
o
Rivers have Harbors.
o
Harbors are the municipal parking towers.
o
From the Harbors branch a system of Canals that serve the interior.
o
The Canals are the Go streets.
o
From the Canals branch cul-de-sac Docks.
o
The Docks serve as entrance halls to the buildings.
A city’s expressways would be tied to its network of slower-speed arterials. These in
turn would tie into a still slower-speed network of stop-and-go streets. Related to
these would be garages or “harbors”.
This concept can be varied in many ways to include a broader category of street types.
Le Corbusier, for example, proposed it as a series of seven types of routes, from high
speed interurban connectors down progressively to pedestrian pathways.
The premise of this concept is that circulation can be controlled because it is the prime
effort in public works projects, from urban to national scale. As such it is the chief
determinant of urban form. Once a reasonable urban form is laid out, a circulation
network can be planned to fit it, and the urban form itself with all its parts, can be left
to develop as an inevitable result.
A public transportation system is obviously not the only thing the public can
determine. Any urban development of any consequence requires considerable
coordination, only between private parties but also public agencies.
Further, the public itself builds civic centers, transport terminals, and public utility
systems. When these controllable elements are added together, the result is a
functional framework of urban circulation, service lines, and urban centers or nodes.
The circulation and utility lines are the lifeblood arteries of the city. The nodes are its
vital organs. Having established these in plan, it remains to build them under a
coordinated schedule. Such scheduling can be in the form of the city’s annual capital
budget program.
An advantage of a capital program is its flexibility. With changing emphasis the
program can be refocused. It is a principal technique to create a network of capital
improvements as well as for reshaping the city and clarifying its form.
In 1964, a report for planning Central Chicago was published entitled Basic Policies
for the Comprehensive Plan of Chicago. The idea of this plan was that the city
operates as a net of interlocking systems. The “Policies Plan” proposed that public
policies be based on the logic of these vital relationships.
A series of twelve diagrams showed how a rundown area would be subjected to a
policy for improving its streets; improving its public transit lines; locating industry in
relation to rail and arterial roads; density changes; public facilities; business location;
recreational areas; and lakefront development. The policies were based on
determ9ining logical locations for related facilities.
The technique of public policies can effectively guide the city’s many decision-making
departments. The policies are in fact a plan, but a plan of action and responsibility
geared realistically to a complex city’s management to produce functional and
amenable physical results.
About forty years ago, H.P Berlage, architect of the extension of Amsterdam, prepared
plans for new housing areas which were to be designed and built in stages. Berlage’s
study included a physical design in which buildings were shown as blocks in relation
to open spaces, transportation, and other building blocks representing schools,
churches, and community faculties.
The physical design studies were an assurance that the concentration of people could
be accommodated in the space shown. The designs were then translated into maps
showing density, open spaces, community faculties, and transport lines.
This was a legal statement of requirements to the developer and architect of the
individual sectors. If they wished they could subscribe exactly to Beralge’s design.
Otherwise they could make their own design while fulfilling the requirements of the
plan. There are after all several ways to slice a cake. Berlage’s technique assured that
the slices were reasonable. The uise of space, mass, activity areas, etc, as a modus
operandi is obvious here
In a recent competition for a master plan for the University of Berlin, the french
architects Josic, Candilis, and Woods proposed a design that resembles a panel for
electronic components.
Evenly spaced and parallel corridors, perhaps a hundred or two hundred feet apart, act
as circulation corridors and contain utility trunk lines. Between these parallel corridors
can be inserted or “plugged in”, a classroom block, auditorium, dormitory, laboratory,
library or whatever else might be needed as the university grows.
Of course, the initial units would be built according to the university’s needs, but later
buildings could be added as needed, with a maximum of choice and convenience.
Courts of varying sizes are formed between the inserted buildings.
Every building in a urban setting is an element of urban design. A tower building may
accent a prominence. A curvilinear building may emphasize a terrain contour. A
special building can act as a focus. Plain buildings can act as modest background
architecture. A plain building can also be a visual link, filling a gap between a row of
existing structures.
All the techniques of urban design have definite implications for individual building
which require careful examinations otherwise raise great difficulties for the design of
later buildings.
Good work of architecture in urban design calls for good manners. One or two works
may stand out as special pieces, the others acting as background setting for them, but
for most buildings architectural humility is the basis of urban design distinction.
There are variations on all of these techniques which might be classified separately.
All of these techniques, new or old, and despite the names, can be applied to any scale
of design.
It is possible today to shape the urban form. If our problems are complex, the
techniques can be tailored to respond. Certainly the need for shaping the city is made
ever more urgent simply because the city is more complex. Through the application of
the principles and techniques of urban design, the energetic urban buildings can be
made to result in wholesome and visually harmonious cities.
