1. AAMP Adaptive Bitrate Algorithms Overview of AAMP ABR Behavior

2. ABR Design - Throughput Retry download on timeout Default Settings: abr-cache-length = 3 abr-cache-life = 5 sec abr-cache-outlier = 5 Mbps aamp-abr-threshold-size= 6000 Segment Downloader Video/Audio/Iframe Segments Video Segment Size (bytes) > aamp-abr- threshold-size Successful Download Update Persisted Recent Download Statistics Downloaded bytes / time GetNetworkThroughput Bitrate Data Store of size = abrCacheLength (history cache size) Downloaded bytes / time Read download info < abr-cache-life Downloaded bytes / time Network throughput estimation; smoothing heuristic: Ignore outliers bps ( > abr-cache-outlier) Comcast Confidential & Proprietary Comcast Confidential & Proprietary 2

3. ABR Design - Throughput ABR check - after each segment download GetNetworkThroughput Default Settings: abr-skip-duration = 6 (2sec * 3 segs) abr-nw-consistency = 2 Read throughput Nw Total Dnld duration > abr- skip-duration* throughput < Profile BW No Yes Yes New Profile Selection based on NW BW Is new profile consistent (abrNwConsistency thrashing avoidance when on edge) Apply New Profile Note: *abr-skip-duration interval prevents profile switching immediately after 1st segment download during tune. * consistency count set to 1 during first profile switch after tune to reduce additional segment download time for profile change . Comcast Confidential & Proprietary Comcast Confidential & Proprietary 3

4. Hybrid ABR ( Throughput + Buffer) Default Settings: max-buffer-rampup= 15sec Minimum buffer = 1 fragment duration + NetworkDownload Timeout(10sec) Profile Selection based on NW BW No Profile Changed ? ABR Valley escape heuristic Yes No change in profile for some duration . New Profile > Current Profile ? Yes Check for enough buffer before rampup (max-buffer-rampup) .If not switch to previous profile If one profile download and if *minimum buffer available ,then not to switch profile. Buffer < min buffer ? Buffer > max buffer ? Select Next Lower profile Select Next Higher profile Apply New Profile Comcast Confidential & Proprietary Comcast Confidential & Proprietary 4

5. Hybrid ABR ( Throughput + Buffer) Variable Timeouts Download timeouts are configured for a fixed/App configured timeout value ( Default of 10sec) With Hybrid ABR , timeout interval will be changed based on the buffer value available If video playback buffer > MaxBuffer Configured , then increase the timeout value . If video playback buffer < MaxBuffer Configured , then set the timeout to Fixed/App configured timeout interval Increased download timeout interval prevents frequent ABR rampdown , due to download delays . If download bps < profile bps && download time < fragment duration , then download bps = profile bps . This also keeps ABR steady . Comcast Confidential & Proprietary Comcast Confidential & Proprietary 5
