Non-Weighted Codes and Excess-3 Code in Binary Systems
Non-weighted code
Non-Weighted Codes
•
type of binary codes, the positional weights are
not assigned.
The examples of non-weighted codes are
•
Excess-3 code
•
Gray code.
Excess -3 Code
Excess-3 code
•
The Excess-3 code is also called as XS-3 code.
•
It is non-weighted code used to express
decimal numbers.
•
The Excess-3 code words are derived from the
8421 BCD code words adding (0011)
2
or (3)
10
to each code word in 8421.
How to find XS-3 code of decimal
number
steps:
•
find the BCD code number of each digit of
decimal number.
•
Then we add 3 in each BCD code.
Example 1
Example 2
Binary to Excess-3 code
Binary to Excess-3 code
The Excess-3 code for the decimal
number
•
Advantages of BCD Codes
•
It is very similar to decimal system.
•
We need to remember binary equivalent of decimal
numbers 0 to 9 only.
•
Disadvantages of BCD Codes
•
The addition and subtraction of BCD have different
rules.
•
The BCD arithmetic is little more complicated.
•
BCD needs more number of bits than binary to
represent the decimal number. So BCD is less efficient
than binary.
Excess-3 codes
The excess-3 codes are obtained as follows −
Excess-3 code into binary
steps to convert the Excess-3 code into binary
:
1.make the group of 4 bits and write the equivalent decimal
number from the Excess-3 table.
2.Find the binary number of the decimal number using a
decimal to binary conversion.
Example 1: (01100011)
Excess-3
1) Making groups of four bits and write their equivalent
decimal number.
(01100011)
Excess-3
= (0110 0011)
Excess-3
From the Excess-3 table:
(0110)
Excess-3
= (3)
10
(0011)
Excess-3
= (0)
10
So, the decimal number of excess-3 code 01100011 is:
(30)
10
Excess-3 to binary
2) Find the binary number.
Now, find the binary number of the decimal
number (30)
10
using a decimal to binary
conversion as: Divide the number 30 and its
successive quotients with base 2.
(30)
10
=(11110)
2
So, the binary number of excess-3 code
01100011 is:
(11110)
2
BCD to Ex-3 conversion
Ex-3 to BCD conversion
Gray Code
Gray Code
•
It is the non-weighted code and it is not arithmetic codes.
•
That means there are no specific weights assigned to the bit
position.
•
It has a very special feature that, only one bit will change each
time the decimal number is incremented
•
As only one bit changes at a time, the gray code is called as a
unit distance code.
•
The gray code is a cyclic code as the transition of one value to its
successive value carries a change of one bit only
.
•
Gray code cannot be used for arithmetic operation.
Ex. 0110
G
=4
0111
G
=5
Gray Code
0
1
Example:
For a 2-bit Gray code, n=1.
1-bit Gray code
0
1
1
0
0
0
1
1
00
01
11
10
2-bit Gray code
Gray Code
1
1
1
1
Example:
For a 3-bit Gray code, n=2.
00
01
11
10
2-bit Gray code
3-bit Gray code
00
01
11
10
10
11
01
00
0
0
0
0
000
001
011
010
110
111
101
100
2.4 Gray Code
THE GRAY CODE
THE GRAY CODE
BINARY TO
GRAY CODE
CONVERSION
Binary to gray conversion:-
a)
The MSB in the Gray code is same as the
corresponding bit in the binary number.
b)
Going from left to right, add each adjacent
pair of binary bit to get next gray code bit
and discard carry
Binary-to-Gray code
Binary-to-Gray code
conversion
conversion
i.
The MSB in the Gray code is the same as
corresponding MSB in the binary number.
ii.
Going from left to right, add each adjacent pair of
binary code bits to get the next Gray code bit.
Discard
carries
.
ex:
convert 10110
2
to Gray code
1+0
+
1
+
1
+
0 binary
1 1 1 0 1 Gray
Binary to gray conversion
•
Lets take a input string & we have to convert it into gray
code
MSB
WILL
BE
SAME
GRAY TO Binary
CODE
CONVERSION
Gray to binary conversion:-
a)
The MSB is the binary code is same as
corresponding digit in the gray code.
b)
Add each binary digit generated to the gray
digit in the next adjacent position and discard
carry.
G
r
a
y
t
o
b
i
n
a
r
y
c
o
n
v
e
r
s
i
o
n
•
Taking a random input string and converting it.
MSB
WILL
BE
SAME
The Gray Code - Application
http://www.mipraso.de/enzyklopae
die/g/gray-code-scheibe.gif
http://www.engr.colostate.edu/
~dga/mechatronics/figures/9-
Bit 0
Bit 1
Bit 2
Bit 3
Application of Gray code
•
Gray code is popularly used in the shaft
position encoders. A shaft position encoder
produces a code word which represents the
angular position of the shaft.
Alphanumeric Codes
Alphanumeric code
•
Coding is the process of altering the
characteristics of information to make it more
suitable for intended application.
•
The code which are used to encode the
characters of alphabet and decimal digits in
addition to special symbols is alphanumeric
code.
Necessity of alphanumeric code
•
In many situation, digital systems are required
to handle the data that may consists of
numerals, alphabets and special symbols.
•
So in digital computers for transmitting data
between computers and its input/output
devices alphanumeric codes are required.
How should we select a code
•
Ease of coding
•
To increase the efficiency of transmission
•
Ease in arithmetic operations
•
Minimum use of hardware
•
Error detection property
•
Ability to prevent wrong output during
transmission
Alphanumeric Codes
•
Represent numbers and alphabetic characters.
–
Also represent other characters such as symbols
and various instructions necessary for conveying
information.
•
The ASCII is the most common alphanumeric
code.
–
ASCII = American Standard Code for Information
Interchange
ASCII
•
ASCII is a type of binary code
•
has 128 characters and symbols represented by a
7-bit binary code.
–
It can be considered an 8-bit code with the MSB
always 0. (00h-7Fh)
–
95 graphic code
–
52 alphabetic code
–
29 punctuation
•
00h-1Fh (the first 32) – control characters
•
20h-7Fh – graphics symbols (can be printed or displayed)
95 graphic codes
Alphabetic codes
Punctuation etc
Example of ASCII conversion
Extended ASCII
ASCII
Table
http://ascii-table.com/img/table.gif
Extended ASCII
•
There are an additional 128 characters that
were adopted by IBM for use in their PCs. It’s
popular and is used in applications other than
PCs
unofficial standard.
–
The extended ASCII characters are represented by
an 8-bit code series from 80h-FFh
Extended ASCII
Table
http://ascii-table.com/img/table-pc.gif
