AspectJ Assignment
2
The simple language
•
Tiny program
y=2;
x=2+y*3;
z=x+y*2;
–
A program is a sequence of assignments;
–
Expressions on the right hand side of assignment statements are arithmetic
expressions;
–
Assume variables are always of integer types;
–
Arithmatic operators include +, -, *, and /. There are no other operators.
–
Assume input is always correct.
3
Parsing
•
The parser creates an abstract syntax tree represented in Program class
public class UseParser {public static void main(String[] args) {try {File inputFile = new File("calc.tiny");Calc2Parser parser = new Calc2Parser(new Calc2Scanner(
new FileReader(inputFile)));
Program pm = (Program) parser.parse().value;
System.out.println(pm.toString());
} catch (Exception e) {e.printStackTrace();
}
}
}
4
Parsing result for z=x+y*2
<?xml version="1.0" encoding="UTF-8" ?>
-
<
program
>
-
<
assignment
>
<
lhs
>
z
</
lhs
>
-
<
rhs
>
-
<
expr
>
<
op
>
+
</
op
>
-
<
left
>
-
<
expr
>
<
primitive
>
x
</
primitive
>
</
expr
>
</
left
>
-
<
right
>
-
<
expr
>
<
op
>
*
</
op
>
-
<
left
>
-
<
expr
>
<
primitive
>
y
</
primitive
>
</
expr
>
</
left
>
-
<
right
>
-
<
expr
>
<
primitive
>
2
</
primitive
>
</
expr
>
</
right
>
</
expr
>
</
right
>
</
expr
>
</
rhs
>
</
assignment
>
… …
Program.java
Assignment.java
Expr.java
5
Program class consists of a vector of statements
public class Program {private Vector <Statement> statements;
public static Hashtable<String, Expr> varTable=new Hashtable<String, Expr>();
public Program(Statement s) {statements = new Vector <Statement>();
statements.add(s);
}
public Program(Statement s, Program p) {statements = p.getStatements();
statements.add(s);
}
public String toString(){ …}
}
6
Assignment class
public class Assignment extends Statement{private String lhs; private Expr rhs;
public Assignment(String l, Expr r){lhs=l;
rhs=r;
Program.varTable.put(l, r);
}
public String getLHS(){ return lhs;}public Expr getRHS() {return rhs; }}
7
Your output
Assignment 0 is: y=2
2==> ?
2==>2
Assignment 1 is: x=(2+(y*3))
(2+(y*3))==> ?
2==> ?
2==>2
(y*3)==> ?
y==> ?
2==> ?
2==>2
2==>2
3==> ?
3==>3
(2*3)==>6
(2+(2*3))==>8
Assignment 2 is: z=(x+(y*2))
(x+(y*2))==> ?
x==> ?
(2+(2*3))==> ?
2==> ?
2==>2
(2*3)==> ?
2==> ?
2==>2
3==> ?
3==>3
(2*3)==>6
(2+(2*3))==>8
8==>8
(y*2)==> ?
y==> ?
2==> ?
2==>2
2==>2
2==> ?
2==>2
(2*2)==>4
(8+(2*2))==>12
Number of Expressions:11
8
Print out the program
•
Print out the parsed program
y = 2;
x = (2+(y*3));
z = (x+(y*2));
•
Suppress printout in the parser by
skipping calls to
System.out.println(..) in UseParser
void around() : call(* *..print*(..))
&& !within(A2) { }Note that
call(* System.out.println(..))
Won’t work
public class UseParser {public static void main(String[] args) throws Exception{File inputFile = new File("calc.tiny");Calc2Parser parser = new Calc2Parser
(new Calc2Scanner(
new FileReader(inputFile)));
Program pm = (Program) parser.parse().value;
System.out.println(pm.toString());
}
}
9
Print out the parsed program
•
Define your own print method in classes such as
Expr, Assignment.
•
Note that the method will be added inside the
Expr class.
public String
Expr.print(){String result="";
if (this.isPrimitive() && this.getValue() != null) {return this.getValue().toString();
} else if (this.isPrimitive() && this.getID() != null) {result=this.getID();
} else {String op = this.getOp();
Expr left = this.getLeft();
Expr right = this.getRight();
result= "("+left.print()+op+right.print()+")";}
return result;
}
public class Expr {private Integer value;
private boolean primitive = false;
private String id;
private Expr left;
private Expr right;
private String op;
public Expr() {super();
}
public Expr(Expr l, Expr r, String o) {left = l;
right = r;
op = o;
}
public Expr(Integer i) {value = i;
primitive = true;
}
… …
}
10
Print out the total number of expressions in this program
•
count calls to constructors
static int Expr.exprCount=0;
after(Expr e): execution( Expr.new(..)) && this(e) {e.exprCount++;
}
11
Evaluate the program
y===>2
x===>8
z===>12
•
add evaluation method into Expr class
public Integer Expr.evaluate() {Integer val;
if (this.isPrimitive() && this.getValue() != null) {return this.getValue();
} else if (this.isPrimitive() && this.getID() != null) {val = Program.varTable.get(this.getID()).evaluate();
} else {String op = this.getOp();
Expr left = this.getLeft();
Expr right = this.getRight();
if (op.equals("+")) {val = left.evaluate() + right.evaluate();
} else if (op.equals("*")) {val = left.evaluate() * right.evaluate();
…
public class Expr {private Integer value;
private boolean primitive = false;
private String id;
private Expr left;
private Expr right;
private String op;
public Expr() { super(); }public Expr(Expr l, Expr r, String o) {left = l;
right = r;
op = o;
}
public Expr(Integer i) {value = i;
primitive = true;
} …
}
12
Print indented trace of the evaluation process
–
check JoinPointTraceAspect in account example
–
Count the nested level
before(): call(* *.evaluate()){indentLevel++;
Expr exp = (Expr) thisJoinPoint.getTarget();
for (int i = 0, sp = indentLevel * 3; i < sp; i++)
System.out.print(" ");System.out.println(exp.print() + "==> ?");
}
