1. MATLAB (MATrix LABoratory) Un lenguaje de programaci n orientado a resolver problemas matem ticos, cient ficos y de ingenier a

2. Matrices y Vectores Matriz tabla de n meros (valores) organizada en filas y columnas ejemplo: [ 1, 2, 3 ; 4, 5, 6] 2 filas de 3 columnas c/u separadores: , o espacio para columnas y ; para filas Vector fila o columna de n meros ejemplo de fila: [1, 2, 3 ,4, 5, 6] ejemplo de columna: [1; 2; 3; 4; 5; 6]

3. Ej: vector con alturas de personas

4. Vector con secuencia de nmeros >> numeros=1:12 numeros = 1 2 3 4 5 6 7 8 9 10 11 12 >> impares=1:2:12 impares = 1 3 5 7 9 11 >> pares=2:2:12 pares = 2 4 6 8 10 12 >>

5. >> plot(numeros,h)

6. >> plot(numeros,h,'r.')

7. >>help plot PLOT Linear plot. PLOT(X,Y) plots vector Y versus vector X. If X or Y is a matrix, then the vector is plotted versus the rows or columns of the matrix, whichever line up. If X is a scalar and Y is a vector, disconnected line objects are created and plotted as discrete points vertically at X. PLOT(Y) plots the columns of Y versus their index. If Y is complex, PLOT(Y) is equivalent to PLOT(real(Y),imag(Y)). In all other uses of PLOT, the imaginary part is ignored. Various line types, plot symbols and colors may be obtained with PLOT(X,Y,S) where S is a character string made from one element from any or all the following 3 columns: b blue g green r red c cyan m magenta y yellow k black w white . point - o circle : dotted x x-mark -. dashdot + plus -- * star (none) no line s square d diamond v triangle (down) ^ triangle (up) < triangle (left) > triangle (right) p pentagram h hexagram solid dashed For example, PLOT(X,Y,'c+:') plots a cyan dotted line with a plus at each data point; PLOT(X,Y,'bd') plots blue diamond at each data point but does not draw any line.

8. Funciones que devuelven un escalar (n) >>n=length(h) n = 12 >>suma=sum(h) suma = 20.3400 >>promedio=mean(h) %sum(h)/length(h) promedio = 1.6950 >> hmin=min(h) >> hmax=max(h) hmin = hmax= 1.5200 1.8700 >> mediana=median(h) %valor central (la mitad son >s y la otra <s) mediana = 1.6900 >> moda=mode(h) %valor que m s se repite moda = 1.6500

9. Funciones que devuelven un vector >> h1=sort(h) %entrega vector ordenado h1 = 1.5200 1.5700 1.6000 1.6500 1.6500 1.6800 1.7000 1.7200 1.7800 1.7800 1.8200 1.8700 >> h2=sort(h,'descend') h2 = 1.8700 1.8200 1.7800 1.7800 1.7200 1.7000 1.6800 1.6500 1.6500 1.6000 1.5700 1.5200 >> ceros=zeros(1,12) %1 fila de 12 columnas ceros = 0 0 0 0 0 0 0 0 0 0 0 0 >> unos=ones(1,n) %1 fila de n columnas unos = 1 1 1 1 1 1 1 1 1 1 1 1 >> azar=rand(1,5) % n meros al azar entre 0 y 1 (0.x) azar = 0.8147 0.9058 0.1270 0.9134 0.6324

10. Operaciones entre vector y escalar (n) >> v=ceros+promedio v = 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 >> w=unos*promedio w = 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 1.6950 >> numeros=rand(1,3)*6 %numeros entre 0 y 5.9.... numeros = 1.1869 0.1832 4.4644 >> dados=floor(numeros)+1 % dados=ceil(numeros) dados = 2 1 5

11. >> plot(numeros,h,'*',numeros,v) >> ylabel('altura') >> xlabel('persona') >> title('alturas y promedio')

12. Operaciones entre vectores >> a=[1,2,3,4]; % ; suprime el eco (no muestra resultado) >> b=[5,6,7,8]; >> sumas=a+b >> restas=a-b sumas = restas = 6 8 10 12 -4 -4 -4 -4 >> productos=a.*b >>cuocientes=a./b productos = cuocientes = 5 12 21 32 0.2000 0.3333 0.4286 0.5000 >> potencias=a.^b potencias = 1 64 2187 65536 OJO >> productos=a*b ??? Error using ==> mtimes Inner matrix dimensions must agree.
