Gravitational Energy and Its Limitations
GRAVITATIONAL ENERGY
Let’s Remove Some Limitations
E
G
= MGH
What are the limits of this equation?
Height – we need a reference point that can’t vary
g – Must be constant so it only works for a few hundred
km
IN A GRAVITATIONAL FIELD…
Work needs to be done to raise an object in a
gravitational field
This work is equivalent to the amount of gravitational
energy gained
Remember: Work against gravity required a force
equivalent to the force of gravity to be applied
W=F
g
∆d = mg ∆y
DERIVE
GEOMETRIC AVERAGES
We are going to use a geometric average as
opposed to a regular average to achieve a more
accurate average value for our inverse parabola
Let’s take a look at what these values looks like
DERIVATION EXTENSION
WHAT HAPPENS WHEN R INCREASES?
GRAVITY WELLS AND WARPING OF SPACE TIME
https://www.youtube.com/watch?v=MTY1Kje0yLg
ESCAPE ENERGY
ESCAPE SPEED
Minimum speed
required to project mass (m)
from surface of mass (M) to just escape
gravitational force of M
BINDING ENERGY
- Additional kinetic energy required
by mass (m) to escape gravitational
attraction of mass (M)
- If you have binding energy, there is
no escape from the gravity well
MECHANICAL ENERGY STILL HOLDS
E
M
= E
g
+ E
k
EXAMPLE
A) How much energy do you need to escape Earth’s
gravitational field?
B) How about to just a distance 4r
e
away?
C) If an object was orbiting 4r
e
away from the Earth,
what additional energy would it need to escape?
WHAT ABOUT AN OBJECT IN ORBIT?
What do we know about an object in orbit?
WARPING OF SPACE TIME
https://www.youtube.com/watch?v=jlTVIMOix3I
CONCEPT: BLACK HOLES
WHAT IS A BLACK HOLE?
We call it a singularity, an extremely
dense, extremely heavy, extremely small
bit of mass
Since it is so heavy, the force of gravity is
MASSIVE
COMMON BLACK HOLES
Primordial Black Hole
- Size of an atom, mass of a mountain
- Formed in the early universe
COMMON BLACK HOLES
Stellar Black Hole
- 20 times the mass of the sun, diameter of 10
miles
- May be dozens of these black holes in the
milky way
- Formed during a super nova
COMMON BLACK HOLES
Super Massive Black Holes
Typically, a million times the mass of the
sun, radius about the size of the solar
system
SUPER MASSIVE BLACK HOLE
In the Milky Way,
- Called Sagittarius A
- Mass equal to 4.3 million suns and would
fit inside a ball the size of the sun
WHAT WOULD HAPPEN IF YOU WERE ON THE SURFACE
OF THE SINGULARITY AND YOU TURNED ON A LIGHT?
THE GRAVITY WOULD BE SO STRONG, IT WOULD
PULL LIGHT BACK IN!
Event Horizon
THE EVENT HORIZON
The line at which no light can escape from a black
hole
No event can be seen within because no light
escapes!
Since no light escapes, everything inside looks black
(no light), therefore, a black hole
CONCEPT: DEATH BY BLACK HOLE
WHEN YOU FALL INTO THE BLACK HOLE
Due to a difference in gravity between your head
and feet, your feet fall faster than your head
This is true on Earth but the force doesn’t differ
much
At a point, you’ll snap into two pieces as you fall
YOU WILL SURVIVE THE SNAP!
(Until you bleed to death)
The remaining halves with continue to snap
in half
This will continue until you are a stream of
atoms that is travelling downwards
NOT THE WORST!
As you stretch, you will also be squeezed (consider it spaghettification)
As space clouds (dust and gas) move towards
the centre of the black hole, they tend to spiral
inwards (like a toilet)
As they do, the parts closer to the BH, spiral
quicker than the parts furthur away
This creates friction and heats the clouds to
millions of degrees and they become a source
for x-rays and ultraviolet
X RAY PICTURE OF BLACK HOLE
BLACK HOLES AND ESCAPE SPEED
- A black hole is black because light cannot escape
it’s gravitational pull
- It’s very small and very dense with an immense
gravitational field
- Since light cannot escape, the speed of light is less
than the escape speed
EVENT HORIZON
The radius of black hole from which no event can be seen
inside due to light’s inability to escape the gravitational
field of the singularity
The Schwartzchild radius is the radius of the event horizon
Let’s calculate the Schwartzchild radius!!!!
EXAMPLE
Let’s say a star 100 x the mass of the Sun dies
and forms a black hole. What would the
Schwartzchild radius be?
6.3 Pg 293 Q7-11
Pg 294 Q1-9
Review Pg 298 Q1-3, 6-10, 20-26
Pg 300 Q3, 6, 7, 11-14, 16, 19
