FRANC3D Training Workshop: Part X Overview


F
R
A
N
C
3
D

T
r
a
i
n
i
n
g

W
o
r
k
s
h
o
p
:
P
a
r
t

X

Drs. Paul “Wash” Wawrzynek, Bruce Carter,
Tony Ingraffea and Omar Ibrahim

April - 2018

2


W
o
r
k
s
h
o
p

A
g
e
n
d
a

Part I:  Introduction to Fracture Mechanics Analysis
Part II:  Introduction to FRANC3D
Part III: Finite Element (FE) Model Import
Part IV:  Crack Insertion
Part V:  Static Crack Analysis & SIF Computation
Part VI:  SIFs from FE
Part VII:  Crack Growth
Part VIII:  Multiple/Variable DOF Approach to Fatigue Life
Part IX:  SIF History & Fatigue Life
Part X: FRANC3D Files, Session Log, Command Line and Python Interface
Part XI:  Miscellaneous

Part X

3

Restart from FRANC3D .fdb file:
From FRANC3D menu, select
File
 -
Open
.
Choose
.fdb*
 file and select
Accept
.
FRANC3D automatically reads the results file** along
with the initial uncracked FE*** and the cracked FE
model files

FRANC3D Files and Restarts

*The .fdb file is a plain text file with references to other files, the flaw geometry, mesh
template and crack growth parameters, and the crack growth history.

**The analysis provides nodal displacement and possibly nodal temperature and crack face
contact pressure results. These will be saved in the .dtp file (.pch file for NASTRAN).

***Cracks, whether initial or subsequent steps of growth, are always inserted into the
original uncracked (local) FE model.

Part X

Reading Analysis Results

4

Results are read
automatically by
FRANC3D if the
results file exists.

Part X

5

FRANC3D Files

Part X

6

FRANC3D Files

.fdb – FRANC3D restart file

stores crack geometry, growth model, SIF history,

reference to other files described below

.cdb/.inp/.bdf  – original uncracked FE model and cracked FE model files

.dtp – results file with displacements, temperatures, contact pressures

.crk – crack geometry

.log – GUI session log file contains FRANC3D commands

.fcg – fatigue crack growth data (SIF history and crack growth model)

_STEP_###.* – automatically named and numbered crack growth step files

FE analysis code files:
i.e.
  .db & .rst for ANSYS, .odb for ABAQUS

Part X

Analysis Results

Read Results
 menu item allows a user to choose the analysis results file
For ANSYS, FRANC3D reads
*.dtp file (contains displacements, temperatures, contact pressure) that is
created using the ANSYS macros generated by FRANC3D
*.dsp file (contains nodal listing of displacements).
For ABAQUS, FRANC3D reads
*.dtp file (contains displacements, temperatures, contact pressure) that is
created using the FRANC3D generated ABAQUS Python script
*.fil file (created by ABAQUS, but has incorrect contact pressure)
ABAQUS CAE report file format (use with models without *parts)
For NASTRAN, FRANC3D reads
*.pch file (contains displacements and temperatures)

7

Part X

8

FRANC3D Session Log

Part X

9

FRANC3D Session Log and Playback

A session##.log file is saved for each FRANC3D GUI
session. As GUI commands are executed, the command is
written to the session log.  An example session:

OpenMeshModel(
    model_type=ANSYS,
    file_name='cube_orig.cdb',
    extra_files=['cube_orig.s01','cube_orig.s02'],
    retained_nodes_file='cube_orig_RETAINED.txt')

InsertFileFlaw(
    file_name='test.crk',
    radius=0.0081)

RunAnalysis(
    model_type=ANSYS,
    file_name='test.fdb',
    flags=[OUTPUT_MAT,OUTPUT_CS,NO_WRITE_TEMP,TRANSFER_BC,NO_CFACE_TRACT,NO_CFACE_CNTCT],
    connection_type=MERGE,
    element_series_type=SOLID_185_187,
    executable='ANSYS150.exe',
    command='"ANSYS150.exe" -b -p struct -m 4000 -db 1000 -i "test.macro" -o "test.out"',
    offset_mat=0,
    offset_csys=0,
    license=struct,
    crack_face_contact=false)

ComputeSif(
    do_therm_terms=true,
    ref_temp=71.6)

Part X

10

FRANC3D Session Log and Playback

The session can be played back in the GUI:
from FRANC3D menu, choose
File
Playback

The file can also be
played back from a
Command/Terminal
window:
> franc3d -batch ses.log

Part X

11

FRANC3D PyF3D

Part X

12

FRANC3D Python Programming Interface

The FRANC3D program has a programming interface that is an
extension to the Python programming language.
Python is an open source, object oriented, scripting language,
which is popular in engineering and scientific computing
community (
e.g
., it is used to drive the ABAQUS GUI).
The Python interface allows one to automate repetitive and
possibly error prone tasks.
It also provides a possible strategy for coupling FRANC3D with
other computational applications
.

Part X

13

A simple PyF3D Program

import PyF3D

f3d = PyF3D.F3DApp()

f3d.OpenMeshModel(
    model_type="ANSYS",
    file_name='cube_orig.cdb',
    extra_files='cube_orig.s01','cube_orig.s02',
    retained_nodes_file='cube_orig_RETAINED.txt')

f3d.InsertFileFlaw(
    file_name='test.crk',
    radius=0.0081)

f3d.RunAnalysis(
    model_type="ANSYS",
    file_name='test.fdb',
    flags=["OUTPUT_MAT","OUTPUT_CS","NO_WRITE_TEMP","TRANSFER_BC","NO_CFACE_TRACT","NO_CFACE_CNTCT"],
    connection_type="MERGE",
    element_series_type="SOLID_185_187",
    executable='ANSYS150.exe',
    command='"ANSYS150.exe" -b -p struct -m 4000 -db 1000 -i "test.macro" -o "test.out"',
    offset_mat=0,
    offset_csys=0,
    license="struct",
    crack_face_contact=False)

f3d.ComputeSif(
    do_therm_terms=True,
    ref_temp=71.6)
The session log easily converted to Python.
Modify this to insert many cracks:

# lists of crack size parameters to
a_sizes = [0.0160, 0.0320, 0.0480,0.0640, 0.0787, 0.2362, 0.3937]
b_sizes = [0.0160, 0.0787, 0.2362, 0.3937]
# loop through the crack size matrix

for a in a_sizes:
    for b in b_sizes:
        # create flaw, insert it, and run analysis……

Part X
