Fortran Templates and Compiler-Driven Design Goals
A Primer
Fortran Templates
J3 Generics Subgroup
Template Design Goals
•
Compiler ensures the template is:
–
Self consistent
–
Specifies what makes a valid combination of parameters
•
Work with derived and intrinsic types
•
Template doesn’t dictate spelling
Some Example Syntax
REQUIREMENT fizz(T, buzz)
TYPE, DEFERRED :: T
FUNCTION buzz(…)
…
END FUNCTION
END REQUIREMENT
TEMPLATE foo(bar, baz, …)
REQUIRES fizz(bar, baz)
…
END TEMPLATE
INSTANTIATE foo(integer, operator(+), …), ONLY: a, b => c, …
A Motivating Example: AXPY
subroutine axpy(a, x, y)
real, intent(in) :: a
real, intent(in) :: x(:)
real, intent(inout) :: y(:)
y = a * x + y
end subroutine
A Motivating Example: AXPY (cont)
template axpy_tmpl(k)
private
public :: axpy
integer, constant :: k
interface axpy
procedure axpy_
end interface
contains
subroutine axpy_(a, x, y)
real(k), intent(in) :: a
real(k), intent(in) :: x(:)
real(k), intent(inout) :: y(:)
y = a * x + y
end subroutine
end template
integer, parameter :: sp = kind(1.0), dp = kind(1.d0)
instantiate axpy_tmpl(sp)
instantiate axpy_tmpl(dp)
real(sp) :: a, x(10), y(10)
real(dp) :: da, dx(10), dy(10)
…
call axpy(a, x, y)
call axpy(da, dx, dy)
A Motivating Example: AXPY (cont)
template axpy_tmpl(T, plus, times)
private
public :: axpy
requires bin_op(T, plus)
requires bin_op(T, times)
interface axpy
procedure axpy_
end interface
contains
subroutine axpy_(a, x, y)
type(T), intent(in) :: a
type(T), intent(in) :: x(:)
type(T), intent(inout) :: y(:)
y = plus(times(a, x), y)
end subroutine
end template
integer, parameter :: sp = kind(1.0), dp = kind(1.d0)
instantiate axpy_tmpl(real(sp), operator(+), operator(*))
instantiate axpy_tmpl(real(dp), operator(+), operator(*))
instantiate axpy_tmpl(integer, operator(+), operator(*))
real(sp) :: a, x(10), y(10)
real(dp) :: da, dx(10), dy(10)
integer :: ia, ix(10), iy(10)
…
call axpy(a, x, y)
call axpy(da, dx, dy)
call axpy(ia, ix, iy)
requirement bin_op(T, op)
type, deferred :: T
elemental function op(a, b)
type(T), intent(in) :: a, b
type(T) :: op
end function
end requirement
A Motivating Example: AXPY
subroutine axpy(a, x, y)
real, intent(in) :: a
real, intent(in) :: x(:)
real, intent(inout) :: y(:)
y = a * x + y
end subroutine
A Motivating Example: AXPY (cont)
template axpy_tmpl(T, U, V, plus, times)
private
public :: axpy
requires bin_op(T, U, U, times)
requires bin_op(U, V, V, plus)
interface axpy
procedure axpy_
end interface
contains
subroutine axpy_(a, x, y)
type(T), intent(in) :: a
type(U), intent(in) :: x(:)
type(V), intent(inout) :: y(:)
y = plus(times(a, x), y)
end subroutine
end template
integer, parameter :: sp = kind(1.0), dp = kind(1.d0)
instantiate axpy_tmpl( &
real(sp), integer, real(dp), operator(+), operator(*))
real(sp) :: a
integer :: x(10)
real(dp) :: y(10)
…
call axpy(a, x, y)
requirement bin_op(T, U, V, op)
type, deferred :: T, U, V
elemental function op(a, b)
type(T), intent(in) :: a
type(U), intent(in) :: b
type(V) :: op
end function
end requirement
Delve into the world of Fortran templates through a primer on generics, showcasing design goals set by the compiler. Explore syntax examples and motivating examples such as the AXPY subroutine, offering insight into the self-consistent nature of templates and their flexibility in parameter combinations.
