LCDR Ryan McCrillis LT CJ Files LT Ashley Wright
Background Naval Architecture and Shipbuilding is an ancient art and science that has evolved over the course of history.
Who Has Ships? John Paul Jones Admiral Nelson Admiral Nimitz CAP N Crunch Donald Trump Jay-Z and Beyonce
But How Are They Designed? Ship s curves are drawn using splines and French Curves to fair a curve between points
Computers Make Life Easier Cubic spline functions shorten process down to a few minutes Conceptually identical to hand drawings
Raw Data 5 4 Z values 0 3 0.196 0.392 0.588 0.784 0.98 1.176 1.373 1.569 1.756 2 1 0 -1 -2 -3 0 2 4 6 8 10 12
Matlab Spline Sample Code Data for Waterplane1_176 11.6922 0.2708 1.7647 11.7189 0.2560 1.7647 11.8082 0.2053 1.7647 11.8879 0.1590 1.7647 11.9599 0.1162 1.7647 12.0259 0.0760 1.7647 12.0540 0.0586 1.7647 12.0880 0.0375 1.7647 12.1479 0.0000 1.7647 1 5 4 3 2 0 Code x176=Waterplane1_176(:,1); y176=Waterplane1_176(:,2); xx176=linspace(-0.26,12,1000); y176s=spline(x176,y176,xx176); plot(x176,y176,'k') -1 -2 -3 0 2 4 6 8 10 12
