1. Dye-Sensitized Solar cells DYES

2. Photoanodes DYES types of dyes additives in dyes state-of-the-art what has to be improved

3. Types of dyes Two classes of dyes: Metal-complexes and organic dyes METAL COMPLEXES ORGANIC DYES Donor-Pi-Acceptor N3 N719 N749 or black dye Porphyrin Phthalocyanine

4. Types of dyes- Metal complexes Changing the functional group change the absorption spectrum

5. Types of dyes- Metal complexes Changing the functional group change the absorption spectrum

6. Types of dyes- Metal complexes Advantages of Ru-Complexes -Panchromatic absorption -Moderately easy to synthesize -Very stable on the surface of titanium dioxide - Absorption spectrum can be tuned easily Cobalt electrolyte species Disadvantages -Ligand exchange with ligands from electrolyte species -Expensive Ru-metal Ru Dye

7. Some dyes worth remembering Types of dyes- Metal complexes N749 or black dye DX1 is the most red absorbing dye

8. Some dyes worth remembering Types of dyes- Metal complexes Red Shifted Absorption spectrum, IPCE, JSC DX1 > Black Dye > N719

9. Types of dyes- Organic dyes

10. Types of dyes- Organic dyes Y123 dye - Donor-Pi-Acceptor

11. Types of dyes- Organic dyes porphyrin dyes Porphyrin core PUSH-PULL PORPHYRINS YD2-O-C8

12. Types of dyes- Organic dyes porphyrin dyes Absorption spectra of porphyrin

13. Types of dyes- Organic dyes phthalocyanine dyes Porphyrin core Phthalocyanine

14. Types of dyes- Organic dyes phthalocyanine dyes Absorption spectra

15. Typical PV values Jsc (mA cm-2) Dye type Voc (mV) PV efficiency Ruthenium 17 to 20 700 to 800 9 to 11 Organic dyes (D-Pi-A) 15 to 18 700 to 900 7 to 10 With iodide/triiodide electrolyte Organic dyes Porphyrin 15 to 17 700 to 800 7 to 10 Organic dyes Phthalocyanine Varies a lot Varies a lot 3 to 7 With Co2+/Co3+ electrolyte Organic dyes Porphyrin 17 to 19 800 to 950 11 to 13

16. All about dye research 1. Shifting the absorption spectrum to red 2. Inexpensive materials and simple synthetic procedure 3. Stable dye on surface by the varying the functional groups
