Distillation
Definition , Principle , Uses , Types
Practical Organic Chemistry
Lab No. 1
Distillation
: (Purification technique) is a process of separating
the component or substances from a liquid mixture by
evaporation and condensation or to purify an impure liquid.
To separate a mixture of liquids, the liquid can be heated
to force components, which have
different boiling points
.
Although the term is most commonly applied to liquids, the
reverse process can be used to separate gases by liquefying
components using changes in temperature and/or pressure.
Principle of Distillation
?
Distillation involves the conversion of a liquid to its vapor
upon heating, then cooling the vapor by (Liebig Condenser)
to condense and collecting it into the flask.
Uses Distillation
The general use of Distillation is
to purify the liquids which boils without decomposition and have non-volatile
impurities
Scientific Uses
One practical use of distillation is in the laboratory, the process is used regularly in chemical and
pharmaceutical research, quality assurance testing for many consumer products and law enforcement forensics.
1. Water Purification
Water from natural sources contains a variety of minerals and other impurities,
many of which can be removed upon heating to lose the basic (anion) or acidic
(cation) part of the water, this process is done easily by distillation. Distilled
water is commonly used in situations where the presence of minerals might
reduce the effectiveness of certain equipment.
2
.
P
e
r
f
u
m
e
The aroma from various plants is contained (essential oils), which can be
extracted through distillation.
3. Petroleum Products
4
.
F
o
o
d
F
l
a
v
o
r
i
n
g
Several products can be produced from crude oil. Because each of these
products has a unique boiling point, a process known as fractional
distillation is used to refine oil into separate materials.
Steam distillation is also used to create natural food flavorings.
The most common are citrus oils and liquid extracts of various herbs and
spices.
Types of Distillation
Simple Distillation
Fractional Distillation
Steam Distillation
Vacuum Distillation
Simple
Distillation
Simple distillation is a distillation process used when the boiling points
of two liquids are significantly different from each other or to separate liquids
from solids or nonvolatile components.
Simple uses for two main purposes:
1.
Purification of samples
2.
Separation of samples
Example:-
Separation diethyl ether
(B.P=34
°
C)
, from dioxane
(B.P=101°C)
. (Liquid – Liquid)
Separation chloroform
(B.P=60°C)
,
from an oil
(B.P=220°C)
.
(Liquid – Liquid )
Separation H
2
O
(B.P=100
°
C)
, KMnO
4
(B.P ≥ 240°C).
( Liquid – Solid )
Simple distillation can be used effectively to separate liquids that have at least 25C
o
degrees difference in their boiling points.
PROCEDURE:
•
As the liquid being distilled is heated, the vapors that form will be richest in the component of the
mixture that boils at the lowest temperature.
•
Purified compounds will boil, and thus turn into vapors, over a relatively small temperature range (2 or
3°C); by carefully watching the temperature in the distillation flask, it is possible to affect a reasonably
good separation
•
As distillation progresses, the concentration of the lowest boiling component will steadily decrease.
•
Eventually the temperature within the apparatus will begin to change; a pure compound is no longer
being distilled.
•
The temperature will continue to increase until the boiling point of the next-lowest-boiling compound is
approached.
•
When the temperature again stabilizes, another pure fraction of the distillate can be collected.
•
This fraction of distillate will be primarily the compound that boils at the second lowest temperature.
•
This process can be repeated until all the fractions of the original mixture have been separated.
Distillation is a purification technique to separate components from liquid mixtures. It involves converting liquid to vapor, then condensing and collecting it. Uses include water purification, perfume extraction, refining petroleum products, and creating food flavorings. Types of distillation include simple, fractional, steam, and vacuum distillation.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
Practical Organic Chemistry Lab No. 1 Distillation Definition , Principle , Uses , Types
Distillation: (Purification technique) is a process of separating the component or substances from a liquid mixture by evaporation and condensation or to purify an impure liquid. To separate a mixture of liquids, the liquid can be heated to force components, which have different boiling points . Although the term is most commonly applied to liquids, the reverse process can be used to separate gases by liquefying components using changes in temperature and/or pressure.
Principle of Distillation ? Distillation involves the conversion of a liquid to its vapor upon heating, then cooling the vapor by (Liebig Condenser) to condense and collecting it into the flask.
Uses Distillation The general use of Distillation is to purify the liquids which boils without decomposition and have non-volatile impurities Scientific Uses pharmaceutical research, quality assurance testing for many consumer products and law enforcement forensics. One practical use of distillation is in the laboratory, the process is used regularly in chemical and
1. Water Purification Water from natural sources contains a variety of minerals and other impurities, many of which can be removed upon heating to lose the basic (anion) or acidic (cation) part of the water, this process is done easily by distillation. Distilled water is commonly used in situations where the presence of minerals might reduce the effectiveness of certain equipment. 2. Perfume The aroma from various plants is contained (essential oils), which can be extracted through distillation.
3. Petroleum Products Several products can be produced from crude oil. Because each of these products has a unique boiling point, a process known as fractional distillation is used to refine oil into separate materials. 4. Food Flavoring Steam distillation is also used to create natural food flavorings. The most common are citrus oils and liquid extracts of various herbs and spices.
Types of Distillation Simple Distillation Fractional Distillation Steam Distillation Vacuum Distillation
Simple Distillation Simple distillation is a distillation process used when the boiling points of two liquids are significantly different from each other or to separate liquids from solids or nonvolatile components. Simple uses for two main purposes: 1. Purification of samples 2. Separation of samples Example:- Separation diethyl ether (B.P=34 C), from dioxane (B.P=101 C). (Liquid Liquid) Separation chloroform (B.P=60 C), from an oil (B.P=220 C). (Liquid Liquid ) Separation H2O (B.P=100 C), KMnO4 (B.P 240 C). ( Liquid Solid )
Simple distillation can be used effectively to separate liquids that have at least 25Co degrees difference in their boiling points. PROCEDURE: As the liquid being distilled is heated, the vapors that form will be richest in the component of the mixture that boils at the lowest temperature. Purified compounds will boil, and thus turn into vapors, over a relatively small temperature range (2 or 3 C); by carefully watching the temperature in the distillation flask, it is possible to affect a reasonably good separation As distillation progresses, the concentration of the lowest boiling component will steadily decrease. Eventually the temperature within the apparatus will begin to change; a pure compound is no longer being distilled. The temperature will continue to increase until the boiling point of the next-lowest-boiling compound is approached. When the temperature again stabilizes, another pure fraction of the distillate can be collected. This fraction of distillate will be primarily the compound that boils at the second lowest temperature. This process can be repeated until all the fractions of the original mixture have been separated.
