Database Design Examples with ER Diagrams


ERD example



Problem 1
A company database needs to store
information about employees (identified by
ssn, with salary and phone as attributes),
departments (identified by dno,
with
dname
and budget as attributes), and children of
employees (with name and age
as attributes).


Problem
Employees
work in departments; each
department is managed by an
employee; a child
must be identified uniquely by
name when the
parent (who is an
employee; assume that only
one parent works for the company) is known. We
are not interested in information about a child
once the parent leaves the company.
Draw an ER diagram that captures this
information.


Solution
First, we shall design the entities and
relationships.
“Employees
work in departments…”
“…each department is managed by an
employee…”
“…a child must be identified uniquely by
name
when the parent (who is an
employee; assume
that only one parent works for the company) is
known.”

Solution
Departments
Child
Employees
name
age
phone
ssn
salary
Dependent
budget
dno
dname
Manages
Works_In

Exercise 2

Consider a university database for the scheduling of classrooms
for ‑final exams. This database could be modeled as the single
entity set exam, with attributes course-name, section-number,
room-number, and time. Alternatively, one or more additional
entity sets could be defined, along with relationship sets to
replace some of the attributes of the exam entity set, as
[1] course with attributes name, department, and c-number
[2] section with attributes s-number and enrollment, and
dependent as a weak entity set on course
[3] room with attributes r-number, capacity, and building
Show an E-R diagram illustrating the use of all three additional
entity sets listed.


Problem: 2

The craft trading website Itsy! Bitsy! is setting up a
database to record sellers and their products. This requires
recording the following information:
 For each seller, their name, contact email, and postal
address.
 For each product, its name, price, and number available.
 Which product is from which seller.
 A unique id number for each product.
Draw an entity-relationship (ER) diagram that represents this
information. Make sure to capture the constraints on the
relationships involved, and designate appropriate primary
keysfor the entities.


Exercise 3

Construct an ER Diagram for Company having following details :
Company organized into DEPARTMENT. Each department has
unique name and a particular employee who  manages the
department. Start date for the manager is recorded. Department
may have several locations.
A department controls a number of PROJECT. Projects have a
unique name, number and a single location.
Company's EMPLOYEE name, ssno, address, salary, and birth date
are recorded. An employee is assigned to one department, but may
work for several projects (not necessarily controlled by her dept).
Number of hours/week an employee works on each project is
recorded; The immediate supervisor for the employee.
Employee's DEPENDENT are tracked for health insurance
purposes (dependent name, birthdate, relationship to employee).

Slide Note
Embed
Share

Explore various database design scenarios including storing information about employees, departments, children, scheduling final exams for a university, and setting up a database for a craft trading website. ER diagrams are provided for each scenario to visually represent the entities, relationships, and attributes involved.

  • Database Design
  • ER Diagrams
  • Employees
  • Departments
  • University Database

Uploaded on Jul 19, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript


  1. ERD example

  2. Problem 1 A company database needs to store information about employees (identified by ssn, with salary and phone as attributes), departments (identified by dno, with dname and budget as attributes), and children of employees (with name and age as attributes).

  3. Problem Employees work in departments; each department is managed by an employee; a child must be identified uniquely by name when the parent (who is an employee; assume that only one parent works for the company) is known. We are not interested in information about a child once the parent leaves the company. Draw an ER diagram that captures this information.

  4. Solution First, we shall design the entities and relationships. Employees work in departments each department is managed by an employee a child must be identified uniquely by name when the parent (who is an employee; assume that only one parent works for the company) is known.

  5. Solution dname salary phone dno ssn budget Employees Departments Manages Dependent Works_In Child name age

  6. Exercise 2 Consider a university database for the scheduling of classrooms for -final exams. This database could be modeled as the single entity set exam, with attributes course-name, section-number, room-number, and time. Alternatively, one or more additional entity sets could be defined, along with relationship sets to replace some of the attributes of the exam entity set, as [1] course with attributes name, department, and c-number [2] section with attributes s-number and enrollment, and dependent as a weak entity set on course [3] room with attributes r-number, capacity, and building Show an E-R diagram illustrating the use of all three additional entity sets listed.

  7. Problem: 2 The craft trading website Itsy! Bitsy! is setting up a database to record sellers and their products. This requires recording the following information: For each seller, their name, contact email, and postal address. For each product, its name, price, and number available. Which product is from which seller. A unique id number for each product. Draw an entity-relationship (ER) diagram that represents this information. Make sure to capture the constraints on the relationships involved, and designate appropriate primary keysfor the entities.

  8. Exercise 3 Construct an ER Diagram for Company having following details : Company organized into DEPARTMENT. Each department has unique name and a particular employee who manages the department. Start date for the manager is recorded. Department may have several locations. A department controls a number of PROJECT. Projects have a unique name, number and a single location. Company's EMPLOYEE name, ssno, address, salary, and birth date are recorded. An employee is assigned to one department, but may work for several projects (not necessarily controlled by her dept). Number of hours/week an employee works on each project is recorded; The immediate supervisor for the employee. Employee's DEPENDENT are tracked for health insurance purposes (dependent name, birthdate, relationship to employee).
