Coordination Complexes and Transition Metals
Chem. 1B – 11/15 Lecture
Announcements
•
Today’s Lecture
–
Transition Elements (Ch. 24)
•
Coordination Complexes
–
Ligand types (last time)
–
Geometries
–
Naming
–
Isomers
•
Bonding in Coordination Complexes - Theory
Chapter 24 Transition Metals
•
Coordination Complex
–
Covered previously (to some degree as
complex ions) in Chapter 16, but focus now
is on molecular scale view
–
Coordination complexes consist of:
•
metal ion (typically same charge as will exist in
water although stability of different oxidation
states – such as Fe
2+
vs. Fe
3+
can change)
•
ligand(s)
•
counter ions (not part of complex, but associated
with complex ion)
Chapter 24 Transition Metals
•
Coordination Complex – cont.
–
Both the metal (covered more later in the
chapter) and ligand affect the type of
coordination complex formed
–
Types of ligands:
•
monodentate (one metal – ligand bond per
ligand)
•
bidentate (two metal – ligand bonds per ligand –
so requires to parts of ligand capable of acting as
Lewis bases)
Chapter 24 Transition Metals
•
Coordination Complex – cont.
–
Examples: Ag(NH
3
)
2
+
= [Ag(NH
3
)
2
]
+
–
Ni(C
2
O
4
)
2-
H
3
N-Ag-NH
3
linear structure –
uncharged monodentate ligand
oxalate is a bidentate
ligand and forms a
“square planar” complex
(view from above)
Chapter 24 Transition Metals
•
Coordination Complex - Geometries and
numbers of ligands
–
Most Common Geometries:
•
Linear (with two ligands)
–
example:
H
3
N-Ag-NH
3
•
Square Planar (4 ligand bonds)
–
example: [PtCl
4
]
2-
•
Tetrahedral (4 ligand bonds)
–
example: [Zn(OH)
4
]
2-
Chapter 24 Transition Metals
•
Coordination Complex - Geometries and
numbers of ligands
–
Most Common Geometries:
•
Octahedral (with six ligand bonds – note
octahedral refers to 8 sides, even though 6
corners)
–
example: [Co(H
2
O)
6
]
2+
Chapter 24 Transition Metals
•
Coordination Complex - Geometries and
numbers of ligands – Example Questions
–
Cobalt(II) forms a complex with three
bidentate oxalate ligands. What is the
geometry?
–
Mercury reacts with 4 I
-
ligands. What
geometries are possible?
–
1 EDTA ligand forms an octahedral complex
with Ni
2+
. EDTA is a _____ dentate ligand
Chapter 24 Transition Metals
•
Coordination Complex - Geometries and
numbers of ligands – More Questions
–
What is the metal oxidation state and
number of ligands + ligand bonds for the
following compounds:
1. Mg[HgCl
4
]
2. [Co(NH
3
)
5
Cl]NO
3
3. Na
2
[Cu(ox)
2
] (ox = C
2
O
4
2-
)
Chapter 24 Transition Metals
•
Coordination Complex – Naming
Compounds
–
Naming ligands:
•
Neutral ligands are given molecule names (e.g.
ethylenediamine) except for:
–
H
2
O = aqua
–
NH
3
= ammine
–
CO = carbonyl
•
Anionic ligands are changed from anion:
–
-ide becomes -o
–
-ate becomes -ato
–
-ite becomes -ito
Chapter 24 Transition Metals
•
Coordination Complex – Naming
Compounds
–
Naming ligands:
•
List names of ligands in alphabetical order before
cation name
•
Prefixes used to indicate number of ligands (di-,
tri-, tetra-, penta-, hexa-) or bis- , tris- if ligand
name already has prefix or for polydentate
•
Metal names (Depends on complex charge):
–
Cations (metal name same as in ionic compounds)
–
Anions (metal – or Latin root – ending in ate)
Chapter 24 Transition Metals
•
Coordination Complex – Naming
Compounds
–
Naming ligands – information for exam:
•
Too much to expect you to know all naming rules
listed
•
Should know all 4
th
row elements plus d8 to d10
5
th
and 6
th
row elements
•
Focus on main rules: ligands names plus 3
exceptions at top of guidelines, di- to hexa-
prefixes, will give table of Latin roots (e.g.
ferrate) if needed
Chapter 24 Transition Metals
•
Coordination Complex – Naming
Compounds – Examples:
–
[Ag(NH
3
)
2
]
+
=
–
[Pt(ox)
2
]
2-
=
–
[Fe(NH
3
)
4
Br
2
]Cl =
–
Tetracyanozincate =
–
Pentaaquabromonickel(II) =
–
Sodium diaquatetrachlorovanadate(III) =
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
What are isomers?
•
Have same formula but are somehow different
–
Structural isomers
•
Have different connections between atoms
•
Examples:
- [Fe(NH
3
)
5
Br]Cl vs. [Fe(NH
3
)
5
Cl]Br (switch of counter
ion with binding ion)
- :C
Ξ
N: ligands can bind at C (cyano) or N (isocyano)
side
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Stereoisomers
•
Due to different neighboring ligands
•
Examples: [Pt(Cl)
2
(Br)
2
]
2-
(square planar)
Pt
Br
Cl
Cl
Br
Trans
isomer – like
ligands apart
Pt
Br
Cl
Cl
Br
Cis
isomer – like
ligands together
These will have slight differences in properties
(
cis
has slight net dipole moment while
trans
does not)
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Stereoisomers – cont.
•
For tetrahedral compounds, MX
2
Y
2
have only one
isomer (X is same distance to other X and other
Ys)
•
For octahedral compounds, MX
4
Y
2
, also has cis-
trans- isomers (guess which is trans)
M
X
X
X
X
Y
Y
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Stereoisomers – cont.
•
For octahedral compounds, MX
3
Y
3
, also has fac-
(for face) and mer- isomers (for meridinal)
M
Y
X
X
X
Y
Y
M
X
X
Y
X
Y
Y
fac
mer
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Stereoisomers – cont.
•
The stereoisomers mentioned so are geometric
isomers that will have different properties (even if
only slight differences)
•
Another class is optical isomers, which have
(mostly) identical properties; except that each
isomer will rotate light differently (and can
interact differently with other “chiral” molecules)
•
A test for an optical isomer is if its mirror image is
non-superimposeable (unique)
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Optical Isomers (examples)
•
MX
2
Y
2
– two or one optical isomer?
•
MABCD – two or one optical isomer?
mirror
120 rotation about Z axis
gives back original
structure
mirror
Not the same – if we
line up A-M-D, B and C
are reversed
Chapter 24 Transition Metals
•
Coordination Complex – Isomers
–
Questions
1.
Which of the following ligands will have
linkage isomers?
a)
NH
3
b) CN
-
c) H
2
O
d) SCN
-
e) C
2
O
4
2-
2.
In what way is [Cr(NH
3
)
5
Br]Cl
2
different from
[Cr(NH
3
)
5
Cl]BrCl?
3.
How many different isomers are present for
the square planar compound [Pt(NH
3
)
2
ClBr]?
Chapter 24 Transition Metals
•
Coordination Complex – Bonding Theory
–
Valence Bond Theory and Crystal Field
Theory
–
For covalent bonds (valence bond theory)
overlap occurs between atomic orbitals from
each atom (e.g. 1s in H and sp
3
hybrid
orbitals in C in CH
4
)
–
For coordination compounds, however,
electrons come fully from ligands
Chapter 24 Transition Metals
•
Coordination Complex – Bonding Theory
– cont.
–
For example, in [Zn(OH)
4
]
2-
, bonding orbitals
can come from empty 4sp
3
on Zn
2+
and filled
2p orbitals on O. (All electrons from O)
–
However, for square planar and octahedral
complexes, non empty d orbitals play a role
(hybrid orbitals must have d character)
Chapter 24 Transition Metals
•
Coordination Complex – Bonding Theory
– cont.
–
To understand how electrons in the d shells
influence bonding, we must understand the
shapes of d orbitals
–
Two different classes of d orbitals occurs
•
Off axes orbitals
d
xy
– lies
in xy
plane
d
xz
d
yz
Chapter 24 Transition Metals
•
Coordination Complex – Bonding Theory
– cont.
–
Two different classes of d orbitals occurs
•
On axes orbitals
d
x^2 – y^2
d
z^2
