1. Pot Operation at Reduced Amperage

2. Given Condition Line Condition at 350A Internal Energy VACD VACD= Vpot-Vext-VAnode-VCathode-VBEMF = 4.2-0.26-0.26-0.36-1.82 = 1.51V Internal Energy = (Vpot-Vext-VAl)x I =(4.2-0.26-2.05)x350 =661.5 kW ACD ACD = (ACD Voltage / (Bath resistivity x Effective current density))-Thickness of bubble ACD= ( VACD / ( x jbath))-0.005= (1.51/(8400x0.00461))-0.005 = 0.034m = 3.4cm

3. Running Pot In New Scenarios Determining the Operating Voltage 300 KA VACD = Vpot-Vext-VAnode-VCathode-VBEMF = 4.478-((0.26x300)/350)-((0.36x300)/350)- ((0.26x300)/350)-1.82 VACD = 1.912 270 KA VACD = Vpot-Vext-VAnode-VCathode-VBEMF = 4.478-((0.26x270)/350)-((0.36x270)/350)- ((0.26x270)/350)-1.82 VACD = 2.209

4. Running Pot In New Scenarios Determining the VACD 300 KA Internal Energy = (Vpot-Vext-VAl)x I 661.5 = (Vpot-((0.26x300)/350)-2.05)x 300 Vpot = 4.478 V 270 KA Internal Energy = (Vpot-Vext-VAl)x I 661.5 = (Vpot-((0.26x270)/350)-2.05)x 270 Vpot = 4.701 V

5. Running Pot In New Scenarios Determining the ACD & Anode immersion 300 KA ACD= ( VACD / ( x jbath))-0.005 = (1.921 / (7200 x 0.00461))-0.005 = 0.053 = 5.3 cm ACD = 5.3 3.4 = 1.9 cm Piston Effect = Change in anode immersion / change in ACD=4.6 Piston effect in this scenario = 4.6 x 1.9 = 8.74 cm Original immersion = Bath height ACD = 18-3.4 = 14.6 cm Immersion after piston effect = 18 - 8.74 = 9.26 cm This scenario we will be able to run the pot.
