Adhesives which harden without chemical reaction
Adhesives which harden without
chemical reaction
Water soluble
•
There is now much pressure from environmental, and health
and safety regulators to reduce or eliminate the use of solvents in
adhesives, and the industry is responding by developing water-
based systems to replace them.
•
There are, however, fundamental problems, one being the low rate
at which water evaporates because of its high enthalpy of
vaporization, which is compared with values for some common
solvents in Table 5.1.
•
A second is that water-soluble materials are essential to stabilize
emulsions, and these remain in the adhesive after drying, so
increasing water absorption and the sensitivity of joints to water.
•
The water soluble materials can be ionic or non-ionic surfactants,
or water soluble polymers.
ADHESIVES WHICH HARDEN BY LOSS
OF SOLVENT
•
Contact adhesives are probably the best known
solvent-based adhesives.
•
These are solutions of a polymer in organic
solvents, which are applied to both surfaces to be
bonded.
•
Some time is allowed for the solvents to
evaporate and the surfaces are then pressed
together, at which point some interdiffusion of
polymer chains will occur.
•
The surfaces can also be heated to increase tack.
•
Clear solvent-based adhesives, which are sold to the public in tubes,
are often solutions of
nitrile
rubber (a copolymer or butadiene
and acrylonitrile) in organic solvents.
•
Prominent contact adhesives are based on neoprene
(polychloro-prene, poly-2-chlorobutadiene).
•
The diene units can be incorporated into polymer chains as four
different isomers, which are shown in structural formulae 5.1.
•
The ratios of these isomers affect the ability to crystallize.
•
The trans-1,4 unit is the most common and AC and AD grades
are made up of about 90% of them. The W grade is composed of
85% of such units and crystallizes more slowly.
•
Neoprene adhesives have good tack, rapid development of bond
strength and are resistant to oils and chemicals.
•
The formulation of a typical neoprene contact adhesive is shown
in Table 5.2.
•
Without stabilization, polychloroprene degrades to liberate HCl,
which attacks the adhesive and is obviously a threat to
metallic adherends. The metal oxides act as acid acceptors; they
are more effective in combination than singly.
•
They can also act as crosslinking agents.
•
Oxygen initiates the dehydrochlorination of polychloroprene,
which is a free-radical process, and the purpose of butylated
hydroxytoluene (BHT) is to scavenge radicals.
•
Uses
of polychloroprene adhesives include “Do-it-Yourself”
contact adhesive, shoe soling, rubber dinghies and rubber-to-
metal bonding.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Water Solutions and Pastes
–
Starch is cheap and plentiful, maize and corn being the
main sources for adhesive use. It consists of glucose units
and has linear and crosslinked components, which are
termed amylose and amylopectin, respectively (structures
5.2 and 5.3).
–
For use in adhesives it is modified by lowering the
molecular weight by the following processes:
•
hydrolysis in dilute acid;
•
alkaline chlorination to give an anionic product;
•
dry heat in the presence of an acid to produce dextrin;
•
alkaline treatment in the presence of tertiary or quaternary
ammonium salts, or epoxides, gives a cationic starch.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Additives:
–
Additives can include up to 10% borax (sodium
tetraborate) to increase viscosity and tack, urea as a
plasticizer, and urea-formaldehyde, melamine-
formaldehyde or resorcinol-formaldehyde
condensates to improve water-resistance. Clay (e.g.
bentonite) can be used as a filler.
•
Applications:
–
The main uses are for bonding paper, board and
textiles. Applications include corrugated board,
paper bags, tube winding, wallpaper paste and
remoistenable adhesives.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Water-moistenable adhesives include
poly(vinyl alcohol) (PVOH), which is used on
postage
stamps, natural gums (e.g. acacia
and dextrins), and poly(vinyl acetate) (PVA)
latices with a large amount of PVOH stabilizer
(e.g. 15%).
•
PVOH is the only common polymer that is
not made from its monomer.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Aqueous Emulsions
–
The ingredients for an emulsion polymerization are water,
monomer(s), stabilizer and initiator. The stabilizer can be a
surfactant or water- soluble polymer, the use of these being
referred to as surfactant and colloid stabilization.
–
Anioinic surfactants include sodium and potassium salts of
long chain fatty acids (stearate, laurate and palmitate) and
sulfates and sulfonates with a long alkyl chain (e.g. sodium
dodecyl sulfate and sodium dodecylbenzene sulfonate).
–
Colloid stabilizers include polyethylene oxide, PVOH and
hydroxyethylcellulose. Amounts used are 0.2-3.0 wt% based
on water for ionic surfactants and 2-10% for water soluble
polymers.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Aqueous Emulsions
–
The product of emulsion polymerization is a
latex
of polymer particles
with adsorbed stabilizer.
–
The
particle
diameters are of the order of 1
m and the water
content is normally 50-55%.
–
Polymer latices are best known as emulsion
paints
that are based on
PVA
.
–
Whether used as surface coatings or adhesives, they are spread on
surfaces and a continuous film is formed as the water evaporates.
–
The lowest temperature at which a continuous film can be formed
is the minimum film-forming temperature (MFT), which is close to
the glass transition temperature.
–
Latex adhesives can be plasticized internally by incorporating a
suitable comonomer or externally by adding conventional liquid
plasticizers (e.g. phthalates) to the hot latex.
ADHESIVES WHICH HARDEN BY LOSS
OF WATER
•
Aqueous Emulsions
–
Vinyl acetate is a major constituent of adhesives for
bonding
wood
and paper.
–
The
cost
of this monomer is low, but because the glass transition
temperature of the homopolymer is
low
(32 "C but it may be
lowered by co-monomers, plasticizers or water), there is a tendency
to
creep
, which is the major disadvantage.
–
Such adhesives are usually
stabilized
with PVOH with about 20%
residual acetate groups. Particle sizes are in the range 0.5-2.0
μ
.
–
The use of surfactants is
minimized
, because the consequent
lowering of surface tension permits
excessive
penetration
of the
adhesive into the substrate.
–
If the substrate is
porous
(e.g. ceramic tiles) a filler such as china
clay
or
calcium
carbonate
can be added to retain the adhesive in the
bond-line.
ADHESIVES WHICH HARDEN BY
COOLING
•
Hot melt adhesives
are one-part systems that
are applied to substrates as a hot liquid, and
rapidly form an adhesive bond on cooling.
•
Their application is readily automated. They
can be used to
bond paper and board
, many
plastics and wood
but a
problem
with
bonding
metals
is that the substrate conducts
heat
too
rapidly, restricting the extent of
wetting.
ADHESIVES WHICH HARDEN BY
COOLING
•
Ethylene Vinyl Acetate (EVA) Hot Melts
–
EVA random copolymers containing up to 30% vinyl acetate are
used, and the effect of adding VA to polyethylene is to reduce
crystallinity
and increase polarity. Melt viscosity is very
dependent on molecular weight.
–
Tackifiers
are added to
reduce
viscosity and improve
wetting, and include hydrocarbon (C,-C,) resins, polyterpenes
and rosin esters of pentaerythritol and glycerol.
–
Waxes
can be added to lower cost and
reduce
viscosity.
–
Fillers
such as
calcium
carbonate
lower cost and increase
viscosity.
–
Antioxidants
are needed to protect the adhesive during
application and service life.
ADHESIVES WHICH HARDEN BY
COOLING
•
Ethylene Vinyl Acetate (EVA) Hot Melts
–
Uses include:
•
cardboard boxes, bookbinding, iron-on patches and
edge-tapes on chipboard.
•
Because of
creep
, books develop a
memory
and tend
to open at the same place each time. This can be
prevented by
crosslinking
brought about by adding a
peroxide and heating, or by electron beam irradiation.
ADHESIVES WHICH HARDEN BY
COOLING
•
Polyamide Hot Melts
–
Polyamide hot melt adhesives have
lower
melting points than
poly-amide plastics, and tend to employ a mixture of
monomers.
–
They have
better
heat
resistance
than
EVAs
but
cost
more;
however, they give good tack
without
needing
additives
.
–
One
or
two
numbers, which indicate the numbers of carbon
atoms in repeat units, are used to specify the structures of
polyamides.
–
If there is single number there is just one sequence of carbon
atoms in the repeat unit, as in
polyamide
6 (
nylon
6) which is
shown in structure 5.4, but here there are two numbers the
first is for the diacid repeat unit and the second for the
diamine. Polyamide 6-10 is the example shown in sructure 5.5.
ADHESIVES WHICH HARDEN BY
COOLING
•
Polyester Hot Melts
–
Polyester hot melt adhesives are based on
terephthalic acid (benzene-1,4-dicarboxylic acid), but
other diacids such as isophthalic (benzene-1,3-
dicarboxylic acid), adipic (hexane- 1,6-dioic acid),
and azelaic (nonane-1,9-dioic acid) are used.
–
The range of diols includes ethane diol, butane- 1,4-
diol, hexane- 1,6-diol, diethylene glycol and
propane- 1,2-diol.
–
Crystallinity falls as the number of diol carbon atoms
increases.
END OF THIS CHAPTER
