March 7, 2017 -- Agenda

•

HelpDesk #98 – Alternative Oauth Flow for ESPI to align with Oauth 2.0

Specification

–

California CPUC requires OAuth 2.0 authorization_code flow meet Oauth 2.0 RFC 6749

specifications

•

Current Data Custodian Connect My Data Certification test harness currently meets this requirement

•

At question is should the current Data Custodian Connect My Data Certification test harness make

Third Party/Data Custodian Scope negotiation optional and thus require changes to the test case

requirements and test steps

•

The Task Force decided that the Data Custodian Connect My Data certification test harness MUST

provide the ability to be certified using the current Scope Selection Screen flow and the Oauth 2.0

authorization_code flow without accessing the Scope Selection Screen endpoint

•

HelpDesk #98 – Is the current definition of  authorizedPeriod sufficient?

–

The current definition of authorizedPeriod (found in the ESPI authorization structure) is

UINT32, which supports 4,294,967,295 seconds. Some Data Custodians are setting "infinite"

expiration periods that exceed this maximum value.

•

The Task Force decided to enforce the current UINT32 definition and ensure Data Custodians use an

end date that does not exceed the UINT32 capacity

•

How should a Data Custodian indicate an “infinite” period?

–

The Task Force decided to indicate a value of “0” in the authorizedPeriod represents an infinite authorization

period as part of the ESPI Redline revision.

<ns1:entry>

<ns1:id

 xsi:type

"ns1:idType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

bed0b17a-6712-40f4-96a1-

487ca6a75244

</ns1:id>

<ns1:link

 href

https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization

rel

"up"

xsi:type

"ns1:linkType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

/>

<ns1:link

 href

https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization/420091

rel

"self"

xsi:type

"ns1:linkType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

/>

<ns1:published

 xsi:type

"ns1:dateTimeType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

2017-02-

08T16:37:40.701Z

</ns1:published>

<ns1:updated

 xsi:type

"ns1:dateTimeType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

2017-02-

08T16:37:40.702Z

</ns1:updated>

<ns1:content

 xsi:type

"ns1:contentType"

xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance

<ns0:Authorization

xmlns:ns0

http://naesb.org/espi

<ns0:authorizedPeriod>

<ns0:duration>

251,915,702,400

</ns0:duration>

 4,294,967,295

<ns0:start>

1486540800

</ns0:start>

</ns0:authorizedPeriod>

<ns0:publishedPeriod>

<ns0:duration>

251978860800

</ns0:duration>

<ns0:start>

1423382400

</ns0:start>

</ns0:publishedPeriod>

<ns0:status>

</ns0:status>

<ns0:expires_at>

1486575162

</ns0:expires_at>

<ns0:scope>

FB=1_3_8_13_14_18_19_31_32_35_37_38_39_40_4_15_10_46_47_16_5;IntervalDuration=900_3600;BlockDuration=D

aily;HistoryLength=63072000;SubscriptionFrequency=Daily;AccountCollection=1;BR=50036;

</ns0:scope>

<ns0:token_type>

Bearer

</ns0:token_type>

<ns0:resourceURI>

https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Subscription/420091

</ns0:resourceURI>

<ns0:authorizationURI>

https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization/420091

</ns0:authoriz

ationURI>

</ns0:Authorization>

</ns1:content>

</ns1:entry>

March 7, 2017 -- Agenda

•

Future Connect My Data Certification Testing

–

Third Party Connect My Data Certification Tasks

–

Data Custodian Connect My Data Retail Customer

Certification Tasks

February 28, 2017 -- Agenda

•

Should Certification Test verify Data Custodian only sends data authorized

by retail customer?

–

Group agreed the Certification test should verify Data Custodian interval data

must meet Scope FB definitions authorized by retail customer.

•

What data should be returned for

/resource/Subscription/{subscriptionId}/UsagePoint/{usagePointId}/Meter

Reading/

–

Only MeterReading elements will be returned

–

Should DC CMD Test Harness check non-batch API implementations

•

HelpDesk #98 – Alternative Oauth Flow for ESPI to align with Oauth 2.0

Specification

–

California CPUC requires OAuth 2.0 authorization_code flow meet Oauth 2.0

RFC 6749 specifications

•

Current Data Custodian Connect My Data Certification test harness currently meets this

requirement

•

At question is should the current Data Custodian Connect My Data Certification test

harness make Third Party/Data Custodian Scope negotiation optional and thus require

changes to the test case requirements and test steps

February 28, 2017 -- Agenda

•

Future Connect My Data Certification Testing

–

Third Party Connect My Data Certification Tasks

–

Data Custodian Connect My Data Retail Customer

Certification Tasks

CPUC Rule 24: One-Click

•

Has there been a CPUC Final Ruling?

–

Yes.

–

Authorizations must start and finish on the Third Party website

–

CPUC has agreed IOUs can implement authorization via OAuth

2.0

•

Does CPUC require Data Custodian’s to grant multiple Third

Parties Access Tokens with One Customer Authorization

•

How should “Super” Third Party access tokens be assigned

–

“Super” Third Party is a Third Party that retrieves Energy Usage

Information on behalf of their Third Party customer (i.e. Utility

API model)

CPUC Appendix E – DRP Requirements

for Solution 3

•

OAUTH improvements

1.

Support authorizations to 2 or more DRPs for the same

customer at the same time

•

Needs further investigation and discussion

2.

The url that DRP redirects the user to should be the

OAuth authorize url (as defined in OAuth 2.0

specification).

•

Requires a new optional Certification Function Block (FB) to verify

IOU does not require DRP authorizations to access ESPI

ScopeSelectionScreen endpoint

3.

The IOU only redirects to authentication interface if

needed, then redirects back to the original OAuth

authorization url

CPUC Appendix E – DRP Requirements

for Solution 3

4.

Authentication interface must be skipped if user

already has valid authentication session cookie

5.

Authentication interface must be able to allow

password resets/reminders and still remain in

authorization flow

6.

Authentication interface must be able to allow

login credentials as authentication fields

7.

Authentication interface must have alternative

instant authentication for users without logins

(account# + zip, etc.)

CPUC Appendix E – DRP Requirements

for Solution 3

8.

Best case authorization interface must be 1-click

“Authorize” button

9.

Default is all services are pre-selected and

customer has to un-select the ones they want to

exclude

10.

Redirected back to DRP with code after clicking

“Authorize”, no confirmation page on IOU

11.

Valid implementation of OAuth 2.0 Code Grant

Flow per

https://tools.ietf.org/html/rfc6749#section-4.1

CPUC Appendix E – DRP Requirements

for Solution 3

12.

Authorize url meets OAuth 2.0 spec per

https://tools.ietf.org/html/rfc6749#section-

4.1.1

•

Additional value= parameters need to be allowed for

IOU DRP specific information

•

Additional optional Function Block testing for DRP

support needs to be added to the current CMD

certification test suite

13.

Be able to handle state parameters, even

through authentication interface.

CPUC Appendix E – DRP Requirements

for Solution 3

13.

Be able to register multiple redirect_uris with IOUs

so that DRPs can have testing/staging/production

redirect_uris

15.

Be able to handle re-authorization for new code

grant if DRP has lost previous code or access_token

•

Requires addition of test script to confirm Data Custodian

meets above requirement.

16.

Be able to handle a user declining to authorize a DRP

in both authentication and authorization interface.

17.

Be able to redirect errors back to the DRP per

https://tools.ietf.org/html/rfc6749#section-4.1.2.1

Query Parameters

•

Atom

–

published  -- represents the time stamp when the

containing entry was created

–

updated – represents the time stamp when the containing

entry was changed

•

Original Intent

–

Required: query using published_min,max – allows search

of IntervalBlocks that contain intervals between min and

max

•

Does this require correct values for published in atom

or just that the query parameters are properly

interpreted?

Query Parameter Requirements – From GreenButtonAuthorization.docx

Current Implementations

•

LH – published timestamp is the end of the first interval in the

IntervalBlock

•

PGE – published timestamp is the moment of creation of the XML result

•

Query parameters published_min/max must be interpreted in the context

of the IntervalBlocks which is the data actual being sought by the query

•

Certification Test Algorithm:

1.

Test Harness performs an authorization on the test account

2.

Test account must have 4 or more interval blocks of data

3.

Test Harness does GET on resourceURI returning subscription with “n”

IntervalBlocks

4.

Test Harness does GET on resourceURI with

1.

published_min equal to the IntervalBlock.start time of the 2

nd

 IntervalBlock returned

in step 3

2.

published_max equal to the IntervalBlock.start time (n-1)

th

 IntervalBlock returned

Initial Third Party Test Requirements – very rough

Older or other slides

Will build deck with new content

over time.

Topics

Support of Aggregate References

•

Sub-LAP (associated with parent LAP)

–

ApnodeType=LAP(Load Aggregation Point) as a child of

aggregateNodeRef

•

LAP Load Aggregation Point

–

AnodeType=ALR(Aggregate Load Resource)

•

LCA - Load Capacity Area

–

ApnodeType=CA(Control Area)

•

planning bus

–

ApnodeType=BUS

•

market operations bus

–

ApnodeType=BUS

CIM UML Model of Aggregates

espiderived.xsd extension of

UsagePoint

Sample XML

<?xml version="1.0" encoding="UTF-8"?>

UsagePoint

 xmlns

="

http://naesb.org/espi

 xmlns:xsi

="

http://www.w3.org/2001/XMLSchema-instance

xsi:schemaLocation

="

http://naesb.org/espi espiDerived.xsd

">

ServiceCategory

kind

</

kind

</

ServiceCategory

pnodeRefs

pnodeRef

apnodeType

BUS

</

apnodeType

ref

reference to a bus

</

ref

</

pnodeRef

</

pnodeRefs

aggregateNodeRefs

aggregateNodeRef

anodeType

ALR

</

anodeType

ref

reference to an aggregate load resource

</

ref

pnodeRef

apnodeType

LAP

</

apnodeType

ref

reference to an sub aggregated load

</

ref

</

pnodeRef

</

aggregateNodeRef

</

aggregateNodeRefs

</

UsagePoint

A pnode that is a bus

reference

A LAP Aggregate with a

SUB-LAP pnode reference

pnodeRefs

pnodeRef

apnodeType

LAP

</

apnodeType

ref

https://fubar.com/espi/1_1/resources/pnodes/aggregatePnodes/12345656</ref

</

pnodeRef

</

pnodeRefs

aggregateNodeRefs

aggregateNodeRef

anodeType

SYS

</

anodeType

ref

https://fubar.com/espi/1_1/resources/aggregateNodes/LoadAggregationPoints/2468ef2</ref

</

aggregateNodeRef

</

aggregateNodeRefs

Pnodes and AggregateNodes

Some DC Procedures

•

PGE:

–

http://www.pge.com/en/myhome/addservices/sh

aremydata/authorized/api/testing/index.page?

–

http://www.pge.com/en/myhome/addservices/sh

aremydata/authorized/getstarted/index.page

•

<<need to collect from SDG&E, SCE, and

LondonHydro>>

Pnode/AggregationPoints from CIM

Model

UsagePoint Associations that will add

the needed elements

AnodeTypes for Aggregate Nodes

•

 - SYS - System Zone/Region;

•

 - RUC - Reliability Unit Commitment Zone;

–

A specialized class of type AggregatedNode type. Defines RUC Zones. A forecast region represents a

collection of Nodes for which the Market operator has developed sufficient historical demand and relevant

weather data to perform a demand forecast for such area. The Market Operator may further adjust this

forecast to ensure that the Reliability Unit Commitment produces adequate local capacity procurement.

•

 - LFZ - Load Forecast Zone;

•

 - REG - Market Energy/Ancillary Service Region;

•

 - AGR - Aggregate Generation Resource;

•

 - POD - Point of Delivery;

•

 - ALR - Aggregate Load Resource;

•

 - LTAC - Load Transmission Access Charge (TAC) Group;

•

 - ACA - Adjacent Control Area

•

 - ASR - Aggregated System Resource

•

 - ECA - Embedded Control Area

•

LoadAggregatinPoint (ALR?), SubLoadAggregationPoint (ECA?), ICAP or LocalCapacityArea (SYS?) are

in this list or need to be explicitly added.

Resulting XML Schema For UsagePoint

Enhancements

XMLSchema (at end of UsagePoint)

XML

RetailCustomer Model

Identities for Rule 24

Meter Multipliers

Retail

Customer

Minor

Classes

and

Enums

espiderived:

UsagePoint

current

Extends UsagePoint based on

newer CIM model:

iec61970cim17v06a_iec61968cim

12v10_iec62325cim03v02

Backwards compatibility assured

by adding new elements to end of

list.

billLastPeriod

•

billLastPeriod

–

The total bill for the billing period

–

billLastPeriod  =  ∑ costAdditionalDetailLastPeriod.LineItem.amount

•

costAdditionalLastPeriod

–

Deprecate and if present, should have the same value of billLastPeriod

–

if you populate the costAdditionalDetailLastPeriod, then

costAdditionalLastPeriod would be expected to have the total

•

IntervalReading.cost

–

Provided if FB_12 is selected and should probably be consistent with

costAdditionalDetailLastPeriod.LineItem.amount records for which these costs

pertain – but this is not guaranteed

•

billLastPeriod = ∑ costAdditionalDetailLastPeriod.LineItem.amount

–

Should always add up to billLastPeriod. If the details provided are not

complete, a record “other” should be included to make up the difference and

indicate that all billing details have not been provided.

–

If no amounts are presented in this detail, there is no need for a compensating

“other” record to add up to billLastPeriod

Query Parameters

•

There was a significant discussion, led by Partha, about how the

“depth” query parameter should work.  During the call we accessed

the “Implementation Agreement” and discovered the only

documentation of the query parameters is a list of the query

parameter keywords.  The group agreed we need to document how

the parameters work and the expected format they should

contain.  For example, the date query parameters (published-min,

published-max, updated-min, and updated-max) need to indicate

they are to be UTC “Z” time formats and not epoch time.

•

As a result of the two above items, additional test need to be added

to FB_37 to:

–

Ensure query elements containing epoch time generate a 400

response

–

Ensure query elements containing ALL generate a 400 response

–

Ensure responses match requested max & depth values

Topics

•

Value mapping for TOU and CPP and ConsumptionTier

•

sftp for Batch/Bulk/{bulkId}

–

Is there a “user”?

–



sftp://user@localhost/DataCustodian/espi/1_1/resource/Batch/Bulk/{bulkId}

•

Suggestion – fixed user= “GreenButton” so no PII in sftp startup

•

Alternative – let DC provide arbitrary uuid in the notification

•



Conclusion: the DC chooses the “user” and includes it in the notificationUri where the TP gets it for use in the exchange.

•

Target Firm Up end of July: Retailcustomer.xsd

–



Need to define function blocks -- Potentials:

•



FB_X1 Minimal that only provides actual IDs and UsagePoints

•



FB_X2 Service Location Contents Name and Addresses and location,

•

No fb needed now End device

•

No fb needed now Pricing Structure

•



FB_X3 Account data for DMD access

–

Access Tokens

•



Access tokens to access? Individual with access_token, bulk with client_access_token

–

URI in Authorization

•



customerResourceUri needed in OAuth authorization response and Authorization xml structure

•



customerResourceUri in client access Authorization would be batch/BulkRetailCustomerInfo

•



Test requirements –

–

If Scope has RetailCustomer function blocks, then

»

Verify Authorization has customerResourceUri

»

Verify Oauth response has customerResourceUri

»

Verify client_access_token works for esource/Batch/BulkRetailCustomerInfo

»

Verify access_token works for resource/RetailCustomer…

–

Additional attributes

•



Move in move out – use CustomerAgreement.validityInterval

•

Target Firm Up List end of July: UsageSummary.CostAdditionalDetail.itemKind

–

Tax, Other, ThirdParty energy provider fee, ThirdParty energy provider usage, Credit, Discount, Usage, Demand, TOU, incentive, informational, Customer

Charge, Energy Charges, Supply Charges, Distribution Charges, Transmission Charges, Generation Charges, State Gross Receipts Tax, State Tax Adjustment,

Administrative Charge, Ancillary Charge, Balancing Service Charge, Working Capital Charge, Purchased Generation Adjustment, Cost Adjustment, Service

Location Distribution Charge, Other, Minimum charge, Tier Charge, Adjustment Charge, Program Charge/Credit, Amount Paid, Power Factor adjustment,

DWR energy credit (calculation and credit value), UUT exemption status, State Tax, Local Tax, Transmission Charges, Distribution Charges, Nuclear

Decommissioning Charges, Public Purpose Programs Charges, Franchise Fee, Generation Charge

–

Will finish consolidation of list and review

•

OAuth login requirements for the testing

ItemKind Simplified

Energy Generation Fee. A charge for generation of energy.

Energy Delivery Fee. A charge for delivery of energy.

Energy Usage Fee. A charge for electricity, natural gas, water

consumption

Administrative Fee. A fee for administrative services.

Tax. A local, state, or federal energy tax.

Energy Generation Credit. A credit, discount or rebate for

generation of energy.

Energy Delivery Credit. A credit, discount or rebate for delivery

of energy.

Administrative Credit. A credit, discount or rebate for

administrative services.

Payment. A payment for a previous billing.

Information. An informational line item.

TOU, CPP, ConsumptionTier Code

Descriptions

•

TOU, CPP, ConsumptionTier are integers in

ReadingType/IntervalReading

•

What does “3” mean?

•

Draft Solution:

–

Provide an optional table in UsagePoint that

provides the code, name, and description of the

values of TOU and CPP when used underneath it.

UsagePoint.ProgramMappings

RetailCustomer Architecture

•  API

–GET .../resource/Batch/RetailCustomer/{id}

–GET .../resource/CustomerInformation/{id}

–…

–GET .../resource/CustomerInformation/{id}/RetailCustomer/{id}/CustomerAccount/{id}/CustomerAgreement/{id}

–GET …/resource/Customer/{id}

–GET .../resource/CustomerAgreement/{id}

–GET .../resource/Batch/BulkRetailCustomerInfo/{id}

Large Organization Use Case

EMS Co

Corporate

Authorizes

EMS Co

•

There is sometimes an authority that can authorize a

large number of individual accounts, e.g. gsa/McDonalds,

… where the individual accounts may be franchised or

otherwise owned/managed – yet the individual accounts

have the responsibility to maintain the utility account and

pay the bills.

Query Parameters

•

There was a significant discussion, led by Partha, about how the “depth” query

parameter should work.  During the call we accessed the “Implementation

Agreement” and discovered the only documentation of the query parameters is a

list of the query parameter keywords.  The group agreed we need to document

how the parameters work and the expected format they should contain.  For

example, the date query parameters (published-min, published-max, updated-min,

and updated-max) need to indicate they are to be UTC “Z” time formats and not

epoch time.

•

As a result of the two above items, additional test need to be added to FB_37 to:

–

Ensure query elements containing epoch time generate a 400 response

–

Ensure query elements containing ALL generate a 400 response

–

Ensure responses match requested max & depth values

•

Jerry Yip has some additional itemKind elements he wants to discuss during next

week’s OpenADE Task Force call, which he will provide in a follow up e-mail.

•

Jerald Pinnecker wants to discuss “subscriptions” during next week’s OpenADE

Task Force call.  Presently they send subscription data to a Third Party when they

register and he wants to know how that data is then tied to the access token when

the Third Party completes the authorization request.  Additionally, he wants to

know who the Third Party is supposed to use the access token.

OAuth Authorization Failure Mode

Usage Scenario:

1.

TP redirect user to DC scope selection.

2.

User approves TP and scope.

3.

DC redirects user to TP with scope parameter.

4.

TP redirects users to DC's OAuth /authorize endpoint with scope and client_id parameters.

5.

DC redirects back to TP redirect_uri with OAuth code parameter.

6.

TP makes a request to DC's OAuth /token endpoint with the code.

7.

DC responds with an access_token and refresh_token.

8.

TP's server crashes and doesn't save either token.

•

How is the TP supposed to get new tokens? In normal OAuth, you simply redirect the user back to the OAuth

/authorize endpoint, the user approves access again and gets redirected back with a new code.

•

However, at least in one current implementation, the TP has to redirect the user to the scope selection screen,

where the user will be told that they have already authorized the TP with no option to re-authorize. In order to get

new tokens, the use manually has to cancel authorization, which causes them to get redirected to the main

website. Then the user manually has to go back to the scope selection screen and authorize the TP again.

•

This re-authorization process is not ideal because it requires us training the user to cancel-then-manually-go-back-

and-reauthorize, which is a very confusing and complex process and doesn't redirect the user back to the TP after

cancellation.

•

Two possible solutions:

–

1. On the DC's scope selection interface, have a re-authorize button if the user has already authorized the TP.

–

2. Allow TP's to redirect the user to OAuth's /authorize endpoint with the same scope, and have the DC ask for re-authorization

at that point.

–

Option 1 is better for GBCMD, in my opinion, because it also allows for the scenario where the TP loses the scope parameter,

too. Option 2 is the more technically correct OAuth procedure. All other OAuth services I can think of do Option 2, but they also

don't require a pre-defined scope parameter for the /authorize endpoint (so there's nothing to lose).

GET Subscription w/wo query

parameters – Default required

behaviors

Problem: The amount of data that is in a:

GET /Batch/Subscription/{subscriptionId}

can potentially be very large. What is the obligation of a DC when that

message is received without query parameters? What about the desire of

some DC’s to provide only a fixed size response of say “X” months? What

about when a subscription contains 1/10/1000 UsagePoints?

•

Alternatives

–

1) Requires date range in GET /Batch/Subscription/{subscriptionId}

•

DC responds with 202 if data is too large to return right away

–

Returns with notification when data is ready and can provide query distinguished URIs

–

2) DC decides maximum depth to return when no query parameters

•

TP may get whole history (from scope parameter HistoryLength) or may get less.

–

3) Term in Scope for default GET Subscription depth

•

The scope can indicate for the specific subscription what the default length is. The DC

decides during scope selection what to include in the offered scopes.

•

Solution:

–

Publish min/max required on resource/Batch/XXXXX APIs

Discussion of responses to requests for

large data sets

Given:

•

It's possible for a subscription to have small or enormous at data sets

•

There GB CMD applications on the market that don't require query parameters

•

Query parameters are specified and the Min and Max public support required for our minimum set

•

If you have or don't have query parameters the third party is likely always to ask the first time for everything

•

We agreed in a face-to-face that we were going to support a response of 202 when large off-line data sets are

requested

•

In a response asking for everything it should be the discretion of the data custodian to determine what the largest

response it's willing to give

•

Some data custodians want to define a fixed maximum size for any request

•

An empty response (feed with no resources) implies no more data

Therefore:

•



Query parameters should remain optional in any given request

•



Absence of query parameters means “everything” – this means all available data that DC is willing to provide

•



202 is a valid response for …./Batch/… followed by a notification when data is ready

•



The DC decides how much a maximum data response to an API request will be

•



A TP that receives less than anticipated can ask for older data.

•



If he gets back an empty feed, he has it all. Note: that if there is a gap in the data and he asks for the gap, he

may get empty feed but there may be more data behind it.

CIM Tariff Model

Charges associated with

time threshholds

Charges associated with

value threshholds

Additional Information for

UsageSummary.CostAdditionalDetail

•

Add an enumeration tag to lineitem to

indicate what kind of charge it is

•

itemKind

–

Tax

–

TOU

–

Demand

–

ThirdParty energy provider fee

–

ThirdParty energy provider usage

Solutions to Add Customer Account

Numbers

Add link

Add Atom

Extension

Extend each Class with

IdentifiedObject.name

Make non-

obfuscatedId





Account/Agreement Topology

Separation of PII containing Resource

RetailCustomer from Subscription*

Customer

UsagePoint

EndDeviceAsset

ServiceLocation

PostionPoint

PricingStructure

Customer

Agreement

Authorization

ServiceSupplier

Normal ESPI

Resources

Subscription

Anononymous

EUI

PII Containing

information

CustomerAccount

Model

•

UsagePoints of RetailCustomer

•

Location of premise

•

Account ID

•

Sub Account (SA) ID—Service Agreement / Account is

name depending on utility

•

Customer name, nickname (or short name)

•

Address and info

•

SDG&E provides only email address and UPID

correspondence csv email and UsagePoint ID (Customer

Obfuscated Key)

•

MeterID

•

ServicePointId

•

Pnode

•

LoadAggregationPoint, SubloadAggregationPoint

•

Climate zone

•

Account open date

•

Account close date

•

SA Open and Close date

•

MDM Agent Id (who does meter read)

•

ServiceSupplierId

•

EnergyServiceProviderId (may be same as service

supplier)

•

Demand Response Provider

•

May need list of Ids for service providers rather than

explicit?? (0..* relationship{role, href})

•

Related assets ???? For example pool pump and pool

pump participation in a program.

•

Related programs ????

RetailCustomer

•



API

–

GET .../resource/Batch/RetailCustomer/{id}

–

GET .../resource/RetailCustomer/{id}

–

…

–

GET .../resource/RetailCustomer/{id}/CustomerAccount/{id}/CustomerAgreement/{id}

–

GET .../resource/CustomerAgreement/{id}

–

GET .../resource/Batch/BulkRetailCustomerInfo/{id}

•



Authorization

–

Scope string addition?

•

RCInfo=AC where – A=Address included , C=AccountInfo included

•

 RCBulkId=123 for access to account info in bulk

–



Access tokens to access? Individual with access_token, bulk with client_access_token

–

Thoughts:

•



Simpler to use the one authorization and the one bulkID for this data which would be used with …/Bulk/{bulkId} and with …/BulkRetailCustomer/{bulkId}

•

Desire to select which APIs query parameters are valid for – but, currently we only test for the specific query paramters needed for IntervalBlock date ranges. Other

parameters and which resources they apply to are optional.

•



Leave generic query parameters as is for all resources but no requirements to support any specific set by resource.

•

FB

–

Has RetailCustomer –

Just one

 FB_4X with RCInfo

–

Has Additional Detail indicated by content of RCInfo

–



Alternative – just like EUI data have separate function blocks for groupings of data (along resource lines) and they are part of scope=FB_xxxxxxxxxx

–

Need to work out FBs that make sense for RetailCustomer

•



Document as a separate document to maintain isolation of the PII and related discussions (CustomerResourceModelHelpdesk83.docx)

•



customerResourceUri needed in authorization and Authorization xml structure

OpenADE Task Force Topics

•

Green Button Connect My Data Testing and Certification (target fall 2014)

–



Complete function block descriptions

–



Complete test case requirements

–

Amend CMD test requirements if gaps are discovered in dry run or other process

•

Issues Raised and Implementation Questions

–



How to use BR=bulkID with application to account and account groupings, as well as, large ThirdParty

collections of Authorizations.

–



Service Request 83 – including Function Block for optional customer info (service point address, etc.)

–



Service Request 84 – having scope selection screen on Data Custodian Site vs 3

rd

 Party site (need to write

up description)

–



Service Request 85 – Duplicating TOU and CPP from ReadingType to IntervalReading as in SEP 2.0

–

Service Request 86 – Desire to add digital signature to Green Button data to protect against tamper.

–



Service Request 90 – Error in GB TestPlan: FB_07,08 AccumulcationBehavior should be 4

–



Service Request 91 – Error in Test Plan: FB_04

–



Mega Third Party

–



Service Request 92 – Certificate reference

–

Service Request 93 -- Customers have requested access to the Green Button CMD API interface to access

their own account information

–



Enhancement of UsageSummary.CostAdditionalDetail to indicate kind of billing determininant

•

New Resources for OpenADE Exchange requested

–

Tariff Model Resource

–



Customer Information Resource

Mega Third Party

•

Host Third Party for smaller third parties

–

Small solar companies that don’t want to implement ESPI

technical requirements

–

Have simple web site

–

Want customer data

•

Why does small third party interface to mega third

party have to be standardized?

–

Have consulting company they are hosting GB on behalf of

–

Retail Customer authorizes little third party and mega third

party to access the data

•

How does mega third party track the authorization

which occurs from the little third party

–

Wants ability to tag a OAuth sequence to associate with

the little third party – perhaps a state parameter???

Issues

•

What if one customer authorizes for two different

provider using mega-third party

–

PG&E only permits one authorization for actual

customer/third party pair.

–

Same customer goes to Solar1 and Solar2 who are

using the services of MegaTP

–

How can DC know one authorization from the next

–



Consensus: let this be private matter between

MegaThirdParty and customer. No additional protocol

required.

•

What if wordpress directs to DC and not TP?

GBCMD Test Harness

•

Using Stunnel Proxy to isolate https from http on test

harness

–

Three message types:

•

1) DataCustodian to Mock Server

–

https



 http

–

Use stunnel server config (tpserver.conf)

•

2) SOAPUI to DataCustodian using groovy script and httpbuilder

–

http



 https

–

Use stunnel client config (tpclient.conf) – host must be what is in

ApplicationInformation remapped to port 8080.

•

3) SOAPUI to DataCustodian via Selenium

–

https web browser integration

–

Use Selenium browser with what is in ApplicationInformation bypassing

stunnel for these messages



Certified Link

<link rel="related" href="https://cert.greenbuttonalliance.org/92348981231"/>

•

Added to feed (or if only entry, added to entry)

•

Assigned by GBA at test request submission

•

Until certified, may return “in progress” or some useful status

•

Optional request of return type for GET (returned by GBA site):

1.

GET

https://cert.greenbuttonalliance.org/92348981231

2.

GET

https://cert.greenbuttonalliance.org/92348981231?format=JSON

3.

GET

https://cert.greenbuttonalliance.org/92348981231

, Header parameter Accept:

application/json

4.

Return (XML Version) – exact form tbd.

Chunking – When the DataCustodian

needs to provide data in “chunks”

•

Have huge data set that DC wants to provide

in “chunks” over HTTPS

•

Use common URI – Subscription or Bulk / id

–

Chunked by index and date?

–

Use ESPI query parameters (FB_37) to distinguish

chunks

<?xml version="1.0" encoding="UTF-8"?>

BatchList

 xmlns

="

http://naesb.org/espi

 xmlns:xsi

http://www.w3.org/2001/XMLSchema-instance



xsi:schemaLocation

="

http://naesb.org/espi espiDerived.xsd

">

resources

../espi/1_1/resource/Batch/Bulk/1?start-index=1&max-results=1000&published-max=

2012-04-02T04:00:00Z



&published-min=

2012-04-02T04:00:00Z

</

resources

resources

../espi/1_1/resource/Batch/Bulk/1?start-index=1&max-results=1000&published-max=

2012-04-02T04:00:00Z



&published-min=

2012-04-02T04:00:00Z

</

resources

</

BatchList

Deferred Response when DC does not

have data ready

Request:

HTTP POST

https://localhost/ThirdParty/espi/1_1/Notification

Content-type: application/xml

Response:

•

ThirdParty makes asynchronous request

•

DataCustodian does not have the data ready – returns HTTP 202

•

Some time later (when ready no guarantees or time limit) DataCustodian sends

Notification with original URL in BatchList

•

DataCustodian provides the result

Request:

HTTP GET

https://localhost/DataCustodian/espi/1_1/Subscription/1

Content-type: application/xml

HTTP returns 202

Request:

HTTP GET

https://localhost/DataCustodian/espi/1_1/Subscription/1

Content-type: application/xml

HTTP returns 200 and Data

Green Button Data File Summary

•

Can there be a “digest” of what is in a Green Button

data set (i.e. feed) so that the whole data set returned

by a GET or DMD can be judged for content without

reviewing the contents

–

Different Usage Points in file may have different contents

–

Content may be dependent on when data is retrieved

–

Simple xpath statements can be used to understand the

contents

–

Unsuitable data is likely to be asked for once not

repeatedly

•

Consensus: Not needed

New XML Schema Tags

•

certificationNumber

–

Provides information about the certificate issued to the creator of the

file

•

contentHash

–

Provides a checksum value of the files contents the recipient of the file

may use to confirm the file has not been tampered with and all

elements of the file were received

–

Response to OpenADE Help Desk item 86

•

http://osgug.ucaiug.org/HelpDesk/Lists/servicerequests/DispForm.aspx?ID=86

&Source=http%3A%2F%2Fosgug%2Eucaiug%2Eorg%2FHelpDesk%2FLists%2Fs

ervicerequests%2FGreenButton%2Easpx

•

Consider RFC 4287 Atom Syndication Format section 5.1 which

describes Digital Signatures for Atom:

https://tools.ietf.org/html/rfc4287#section-5.1

Certification Structure

link type=“text/html”

href=“https://cert.greenbuttonalliance.org/certificate/987654321987654321” />

Possible Options

•

GET

https://cert.greenbuttonalliance.org/92348981231

?ThisGuysScopeIs=FB_

01040507”

•

PGE -

92348981231

 – scopes=1_4_5,1_4_10,1_4_5_10

Variable return types

•

Query Parameter:

–

GET

https://cert.greenbuttonalliance.org/9234898123

1?format=XML

•

Accept Header Parameter:

–

Accept: Application/XML

•

Atom link types

–

<link type=“XML” href=“https://foo.bar.com”/>

Certificate Solutions

•

Create new required resource for GB

•

*** Create a required feed related link

•

Look at other atom feed attributes to

implement

[FB_14] OAD011 [NEG] Malformed Refresh Token Request

•

Verify Data Custodian rejects a malformed Refresh Token Access

Token Request

–

Refresh_token field-value pair that was issued to another Third Party

•

The current CMD test harness can only simulate a single Third Party

application and thus is not able to present a refresh_token request using

another Third Party’s assigned refresh_token

•

Two application information structures would need to be registered at the

Data Custodian under test to be able to support this requirement

–

Refresh_token field-value pair has expired

•

A short lived refresh_token would need to be available to perform this test

requiring the Data Custodian under test to be able to modify the

refresh_token expiration period

•

The authorization server’s token expiration test should not be based on the

type of token issued, therefore the existing test in OAD016 [NEG] Invalid

Access Token Request (Access Token contained in the Authorization Header

has expired) makes this test redundant

Cell Phone API Model

•

How to do authorization for cell phone APP

–

Still need to involve App developer (DC may not

accept request from any app)

–

API FBs

–

Customer and his app authentication

•

Get an access token

–

Differs in certificate management and security

•

Security

•

Privacy

–

Retail Customer vs Subscription

One Data Custodians Potential Design

Dimensions for UsageSummary

Nettable: total cost = sum of nettable components

NEM: Net Metering





Meter Relationships (Additive-Conjunctive, Subtractive)



Special Bill Items

NEM Statement

Shadow Bill Info

Level Pay Plan customers



Rates (bill periods: pricing changes, seasons)

Topics

•

Multiple ReadingTypes in file not referenced

by contents

–



Proposal – permit (right now excluded)

•

Definition of Net metering FB_07 vs. FW/REV

metering FB_08

FB_03

•

espiderived.xsd

–

thirdPartyUserPortalScreen vs. client_uri

•

Appears to duplicate same function

•

client_uri is optional by dynamic registration OAuth protocol

•

Solution

–

Make client_uri and thirdPartyUserPortalScreen optional in schema

–

Authorization.authorizedPeriod and publishedPeriod should be optional since

not needed in authorizations for client admin and registration

•

Solution

–

Make both fields optional in the schema

–

Ensure they are present for access_token based authorizations

–

If present validate authorizedPeriod and publishedPeriod are valid date format

–

If either authorizedPeriod or publishedPeriod is present, both are required

–

Allow duration to be present with “0” values implying non-expiring authorizations

•

grant_types for ApplicationInformation

•

Should it be set of grant_types that DC supports?

•

Spring requires separate client_id for client_credentials flow

•

Solution:

–

Nothing needs to change

FB_03

•

grant_types test assertion in FND002 re: redirect_uri

–

Solution:

•

Remove the test from FND002 and OADxxx

•

response_types should be “code”

–

Solution:

•

Add test to validate content of response_types is “code”

•

Lifetime of client_access_token

–

If shortlived, you need to do client_credentials each day to

get a new one

•

This forces you to use the “secret” often which is a greater risk

than client access token

•

What does this do the lifetime of the “Authorization”

CMD T&C

T&C Plan

GreenButton Connect My Data Conformance

Testing Requirements Review

•

For Review

•

FB_03 Core GB CMD

•

FB_39 PUSH model-REST Notifications/bulk transfer

•

FB_34 SFTP for bulk

•

FB_35 REST for Bulk

•

FB_13 Security

•

FB_14 Authorization and Authentication

•

Not yet ready for review

•

FB_19 Partial data update

•

FB_40 Offline RetailCustomer authorization

•

FB_37 Query parameters

CMD Test Development Plan

•

Phase I - 11/17/2014..11/21/2014

–

Ron/Don Complete Spreadsheet with Test Requirements and

Test Steps.

–

In parallel John/Marty get scheduled with consenting Data

Custodians for an initial test – GET ServiceStatus which requires

a target URL and a client_access_token for a preconfigured test

Third Party.

•

Phase II - 11/19/2014..11/26/2014

–

OpenADE/OpenESPI Participants review test requirements and

procedures and report by exception

–

Don/Ron are building tests

•

Phase III – 12/1/2014..12/31/2014

–

Don/Ron are building tests

–

John/Marty are running tests with consenting Data Custodians

Set UUT Into Test Harness

•

Harness acts as a TP

–

Need test third party account

•

At least three Test Accounts

–

Two authorized for this third party

–

One known and authorized for any other third party

•

Create / Exchange ApplicationInformation for Test TP

•

Create / Exchange

–

TP client_access_token

–

TP registration_access_token

–

Two Subscription access_token (may included OAuth

authorization process)

–

Third subscription access_token (not owned by TP and used in

negative tests)

Data Custodian Test Capabilities

•

Any given data custodian might fall into three

possible capability categories:

–

The DC has the ability to clear created

authorizations

–

The DC has multiple accounts to authorize so that

when a new authorization is needed it can be

created

–

The DC has to accept that one test failure may

preclude going on to perform other tests

Issues

•

How to expire an access token so it can be tested along

with refresh_token

–



Testee can manually or otherwise “expire” an access token

•

Removal of client_credential flow testing until dynamic

registration

–



Support the API

–

Don’t support in minimum required

•

How the transition from “scope selection” which is not

OAuth, to the OAuth sequence which must originate at the

Third Party occurs.

–

Need to review Authorization document (needs corrections) and

implementers need to check what they are implementing

DataCustodian Registration Values to Communicate

with the Certification Test Harness

•

thirdPartyNotifyUri

–

https://services.greenbuttondata.org/CertificationThirdParty/es

pi/1_1/Notification

•

thirdPartyScopeSelectionScreenURI

–

https://services.greenbuttondata.org/CertificationThirdParty/es

pi/1_1/RetailCustomer/ScopeSelection

•

thirdPartyUserPortalScreenURI

–

https://services.greenbuttondata.org/CertificationThirdParty/es

pi/1_1/RetailCustomer/home

•

client_name

–

Certification Test Harness

•

client_uri

–

https://services.greenbuttondata.org/CertificationThirdParty

GBCMD Testing and Certification

Status

•

Test Project and Harness

–

Need to add target UUT configuration and refactor tests

•

FB_3 Core Green Button Connect My Data

–

Status: Tests almost complete

•

FB_13 Security and Privacy

–

Status: Initial set of test complete; need to adjust to test harness and needs some small

enhancements

•

FB_14 Authorization and Authentication

–

Status: Repertoire of test cases initially identified by Don Coffin and they need to be reviewed

and implemented … implementation begun

•

FB_19 Partial Update Data

–

Status: not started

•

FB_37 Query Parameters

–

Status: not started

•

FB_39 PUSH Model

–

Status: substantially complete

•

FB_34 Bulk SFTP

–

Status: substantially complete (not on github)

•

FB_35 Bulk REST

–

Status: substantially complete (not on github)

Authorization Resource

•

Currently, client_access token can retrieve the collection of

authorizations for the specific third party. A concern was raised that

theft of that one token would provide access to all tokens (in the

Authorization resource) a serious vulnerability. Proposed solutions:

1.

Keep API and schema constant but require the omission of

access_token and refresh_token tags.

2.

Make access to Authorization only based on the contained

access_token. That is, the client_access_token can only retrieve the

corresponding Authorization resource; registration_access_token

can only retrieve the corresponding Authorization resource; the

individual access_tokens can only retrieve the corresponding

Authorization resource.

Consensus solution:





Remove access tokens from the schema.

Access Tokens

•

Reference:

http://www.greenbuttondata.org/espi/access_tokens/

•

ACUDR

•

access_token

•

client_access_token

•

upload_access_token (used only in FB 45)

•

datacustodian_access_token (used only in FB_33)

•

registration_access_token

•

refresh_token ?

CMD Test Development Plan

References

•

All the test development is being done on the

https://github.com/energyos/OpenESPI-

GreenButtonCMDTest

 project, and,

•

The test requirements and test procedures maintained in

the spreadsheet at

https://github.com/energyos/OpenESPI-

GreenbuttonDataSDK/tree/master/GreenButtonTestingReq

uirements

•

You can enter issues for discussion on either project as you

see appropriate.

–

For Test Code Issues:

https://github.com/energyos/OpenESPI-

GreenButtonCMDTest/issues

–

For Test Requirements Issues:

https://github.com/energyos/OpenESPI-

GreenbuttonDataSDK/issues

RETAIL CUSTOMER

Object Identification

•

Objects are instances of classes

•

Objects need to be identified uniquely because

–

Data in a repository needs to be identified as to where

it came from

–

Updates to data (for example from raw to validated)

need to identify that it’s the same data that has been

updated

–

Devices from which data originates often needs to be

associated with the data

–

Devices need to be labeled multiple ways for various

purposes – e.g. in a building topology (2

nd

 floor

floodlight), in an electrical hierarchy (branch 2 load 3)

Master resource identifier issued by a model authority.

The mRID is globally unique within an exchange context.

Global uniqeness is easily achived by using a UUID for the

mRID. It is strongly recommended to do this.

The Name class provides the means to define any

number of human readable  names for an object. The

name can be further attributed by a NameType and a

NameTypeAuthority.

IEC 61970 IdentifiedObject

A simple string to identify the object.

IdentifiedObject

•

mRID – usually a UUID that represents the object

instance

•

name – simple string to identify the object

•

Name – a class that allows additional names to be

used for the same object in different hierarchies.

–

different naming authorities may have the right to

name devices for their own purposes

–

it is important to identify the naming authority and

naming convention (type)

–

These must also be properties of the object to which

they represent since it is the same unique object

ESPI Mapping of IdentifiedObject to

Atom

•

ESPI endpoints expose resources as described by Atom,

IETF RFC 4287.

•

Representations are identified as media type

“application/atom+xml”

•

ESPI namespace and types (“http://naesb.org/espi”) are

used for objects in <content> element

•

espi:mRID is implemented by  atom:id

–

UUIDs are used, as specified in IETF RFC 4122

•

espi:description is implemented by atom:title

•

atom:published and atom:updated are used

•

Associated objects use atom:link (rel=“related”)

•

espi:name is implemented a resource.name

Solutions to Add Customer Account

Numbers

Add link

Add Atom

Extension

Extend each Class with

IdentifiedObject.name

Make non-

obfuscatedId





Account/Agreement Topology

Separation of PII containing Resource

RetailCustomer from Subscription*

RetailCustomer

UsagePoint

EndDeviceAsset

ServiceLocation

PostionPoint

PricingStructure

Customer

Agreement

Authorization

ServiceSupplier

Normal ESPI

Resources

Subscription

Anononymous

EUI

PII Containing

information

CustomerAccount

Model

•

UsagePoints of RetailCustomer

•

Location of premise

•

Account ID

•

Sub Account (SA) ID—Service Agreement / Account is

name depending on utility

•

Customer name, nickname (or short name)

•

Address and info

•

SDG&E provides only email address and UPID

correspondence csv email and UsagePoint ID (Customer

Obfuscated Key)

•

MeterID

•

ServicePointId

•

Pnode

•

LoadAggregationPoint, SubloadAggregationPoint

•

Climate zone

•

Account open date

•

Account close date

•

SA Open and Close date

•

MDM Agent Id (who does meter read)

•

ServiceSupplierId

•

EnergyServiceProviderId (may be same as service

supplier)

•

Demand Response Provider

•

May need list of Ids for service providers rather than

explicit?? (0..* relationship{role, href})

•

Related assets ???? For example pool pump and pool

pump participation in a program.

•

Related programs ????

RetailCustomer

•

API

–

GET .../resource/Batch/RetailCustomer/{id}

–

GET .../resource/RetailCustomer/{id}

–

…

–

GET .../resource/RetailCustomer/{id}/CustomerAccount/{id}/CustomerAgreement/{id}

–

GET .../resource/CustomerAgreement/{id}

–

GET .../resource/Batch/BulkRetailCustomerInfo/{id}

•

Authorization

–

Scope string addition?

•

RCInfo=AC where – A=Address included , C=AccountInfo included

•

RCBulkId=123 for access to account info in bulk

–

Access tokens to access? Individual with access_token, bulk with client_access_token

•

FB

–

Has RetailCustomer – Just one FB_4X with RCInfo

–

Has Additional Detail indicated by content of RCInfo

February Event – Preliminary Planning

•

Celebrate:

 “Birth of the Green Button Ecosystem”

–

Testing and Certification Complete for DMD/CMD

–

UCAIug ITCA fully established

–

Initial Data Custodians successfully certified for

DMD and CMD

–

Shower Successful T&C Adopters with Fame and

Congratulations

•

Venue and participation TBD in coming weeks

Best Practice Reading Quality Flags

•

ReadingType.defaultQuality contains the default quality that applies to all

corresponding IntervalReading data.

•

IntervalReading.ReadingQuality.quality allows specific Intervals to override the

default in ReadingType

•

UsageSummary.qualityOfReading if present overrides default in ReadingType for

those IntervalBlocks within the scope of the UsageSummary.billingPeriod

•

If IntervalReading data are modified, DataCustodian should notify of this change so

ThirdParty can retrieve the changes.

•

If UsageSummary.qualityOfReading overrides the ReadingType or IntervalReadings,

the IntervalReading qualities would change and a subsequent retrieval (not

required) of the IntervalBlocks would come with the corresponding quality flag.

•

The qualityOfReading flag for Usage Summary will indicate latest overriding quality

of previously provided interval values corresponding to BillingPeriod dates

•

The Default Quality (from ReadingTypeRef) for OverallConsumptionLastPeriod will

indicate quality of total billed usage

Requests that are not inside

authorization period

Date of

request April 5



Consensus:

i – agree on 403

ii – agree on 403

FB3 - Core REST Services

•

[R] GET resource/ApplicationInformation/{ApplicationInformationID}

–

[POS] Accept of valid request

–

[NEG] Reject by invalid ID

–

[NEG] Reject by invalid access-token

–

[POS] Results valid to schema and include required fields for OAuth and TP/DC

interaction

•

[C] GET resource/Authorization

•

[C] GET resource/Authorization/{AuthorizationID}

•

[A] GET resource/Batch/Subscription/{SubscriptionID}

•

[C] GET resource/ReadServiceStatus

•

POST: How to test for TP Notification

–

Trigger

–

Uses notification URI from ApplicationInformation

–

Expected content – at least one URI that can be GET’d?

FB_03 Core GB CMD

•

Covers “core services”, resources and access control

–

atom:entry, atom:feed

–

GET,

PUT, POST, DELETE (negative only)

–

ApplicationInformation

–

Authorization (feed)

–

Authorization (entry)

–

Subscription (entry) only available through

batch/subscription

–

ReadServiceStatus (entry)

–

Access token expiration testing?

–

Authorization expiration?

–

Notification move to FB_39?

FB_03 Core GB CMD

•

atom:entry / ApplicationInformation

–

Using required access token of

R(registration_access_token)

•

Verify successful GET and

response contents (which subset of app

info is required in the response?)

–

If it is required by OAuth2 dynamic registration it must be present

–

Other fields not derived from OAuth2?

–

i.e. ContactInfo used in the case of a failed notification to TP

•

Verify negative response to PUT, POST, DELETE: 403 – forbidden

–

Using other access tokens(A,C) or none

•

Verify negative response to GET, PUT, POST, DELETE: 403 –

forbidden

•

No token: 401 – unauthorized

FB_03 Core GB CMD

•

atom:feed / Authorization

–

Using required access token of C(client_access_token)

•

Verify successful GET and

response contents (which subset

of Authorization info is required in the response?)

•

Verify negative response to PUT, POST, DELETE: 403 –

forbidden

–

Using other access tokens (AR) or none

•

Verify negative response to GET, PUT, POST, DELETE: 403 –

forbidden

•

No token: 401 – unauthorized

FB_03 Core GB CMD

•

Authorization(C)- all fields(except error fields),

some have of which have req. values

•

Subscriptions(A) -  feed with at least 1 UsagePoint

•

ReadServiceStatus(C) – all fields with content of

0/1

–

Using required access tokens

•

Verify successful GET and response contents

•

Verify negative response to PUT, POST, DELETE

–

TBD?: Using other access tokens or none

•

Verify negative response

FB_39 Push Model – REST notifications

•

Send Notification to TP

–

pre-test set up – DC needs to know TP stand-in URI (FB_33 could automate this?)

–

DC UT has manual “trigger method” to generate notification

–

ApplicationInformation

–

Authorization

–

Subscription

•

Verify well-formed contents of the Notification

•

Get the data (w/ correct access token) and validate the data

•

[NEG] Test GET out of bounds and deferred response (should be moved to or is

already present in other FB tests)

–

Authorization no longer valid (how?) – MOVE to FB_14

–

Data no longer available (i.e. TP took too long for requesting the data) – SFTP error 2 ref to file

that does not exist / REST GET error

–

Issue REST GET with wrong token (

what token should the test use?

) applies specifically to

FB_39 to ensure notification data is secure

•

[NEG] If TP Notify fails, verify by demonstration that failure was detected

–

TP is off-line

FB_34 SFTP for Bulk

–

Prerequisites

•

Pre configured Authorizations

•

Authorizations need bulk scope

–

Notification of Bulk sent to test harness

•

i.e.

sftp://services.greenbuttondata.org/DataCustodian/espi/1_1/resource/Batch/Bulk/{BulkID}

–

Test harness retrieves data via SFTP

–

Validate the data

•

Pass schema

•

Must contain 1 feed w/ 1 or more entry(s)

•

Verify there is a valid authorization for each entry and the scope of each authorization for each

entry has BR=BulkId

•

Use

https://services.greenbuttondata.org/DataCustodian/espi/1_1/resource/Authorization

for

list of authorizations to check against

–

Is URI a pointer to a folder or a pointer to a file?

–

SFTP GETALL – could retrieve a set of files from a folder or

–

SFTP GET – single file

FB_35 REST for Bulk

–

Notification of Bulk

•

Authorizations must be present

•

Authorizations need bulk scope

•

i.e.

sftp://services.greenbuttondata.org/DataCustodian/espi/1_1/resource/B

atch/Bulk/{BulkID}

–

Test harness retrieves data via REST GET

–

Validate the data

•

Pass schema

•

1 feed w/ 1 or more entry(s)

•

Verify there is a valid authorization for each entry and the scope of each

authorization for each entry has BR=BulkId

•

Use

https://services.greenbuttondata.org/DataCustodian/espi/1_1/resource/

Authorization

 for list of authorizations to check against

FB 13: Security Testing

•

Cyber Security and Privacy Test Requirements

–

Based on Authorization.docx section 2.7

•

From SGIP SGCC Committee review of REQ.21

•

Reviewed with NIST Cyber Security staff

•

NAESB REQ.21 section

•

Initial set of test requirements on next slide

FB 13: Security Testing

Initial Set of Test Requirements

•

[TR_TC001] Test software shall issue a service request over an SSL session and shall

verify that the response HTTP header contains the following fields and information –

fields TBD

•

[TR_TC002] Verify that REST request headers include –

fields TBD

•

[TR_TC003] Verify that the Data Custodian implements TLS 1.2.

•

[TR_TC004] Verify that when communicating with a Retail Customer the Data Custodian

negotiates the highest level of TLS mutually supported.

•

[TR_TC005] Verify that when communicating with a Retail Customer the Data Custodian

rejects TLS_RSA_WITH_NULL_SHA cipher suites.

•

[TR_TC006] Verify that when communicating with a Retail Customer at a minimum the

Data Custodian accepts the TLS_RSA_WITH_AES_128_CBC_SHA cipher suite.

•

[TR_TC007] Verify that when communicating with a Third Party the Data Custodian

negotiates the highest level of TLS mutually supported.

•

[TR_TC008] Verify that the Data Custodian maintains an unexpired unrevoked RSA

certificate with a public key length of at least 2048 bits.

FB 13: Security Testing

Initial Set of Test Requirements

•

[TR_TC009] Test software or manual inspection shall verify that the Data Custodian RSA

certificate was issued by a Certificate Authority (CA) that has been successfully audited

according to the criteria of ETSI or WebTrust.

•

[TR_TC010] Test software or manual inspection shall verify that Tokens and IDs

communicated by the Data Custodian are opaque and if based on actual Customer

information that they are randomized using a secure method to protect privacy.

•

[TR_TC011] Test software or manual inspection shall verify that Tokens and IDs

communicated by the Data Custodian consist of at least 48 bits and can be the random

number part of an RFC2422 UUID.

•

[TR_TC012] Manual inspection of supporting documentation shall confirm that the Data

Custodian implementation utilizes software libraries which are FIPS 140-2 level 1 or

higher and listed on the CMVP website.

•

[TR_TC013] Verify that the Third Party implements TLS 1.1 or higher.

•

[TR_TC014] Verify that when communicating with a Retail Customer the Third Party

negotiates the highest level of TLS mutually supported.

FB 13: Security Testing

Initial Set of Test Requirements

•

[TR_TC015] Verify that when communicating with a Data Custodian the Third Party

negotiates the highest level of TLS mutually supported.

•

[TR_TC016] Verify that the Third Party maintains an unexpired unrevoked RSA

certificate with a public key length of at least 2048 bits.

•

[TR_TC017] Test software or manual inspection shall verify that the Third Party RSA

certificate was issued by a Certificate Authority (CA) that has been successfully audited

according to the criteria of ETSI or WebTrust.

•

[TR_TC018] Test software or manual inspection shall verify that Tokens and IDs

communicated by the Third Party are opaque and if based on actual Customer

information that they are randomized using a secure method to protect privacy.

•

[TR_TC019] Test software or manual inspection shall verify that Tokens and IDs

communicated by the Third Party consist of at least 48 bits and can be the random

number part of an RFC2422 UUID.

•

[TR_TC020] Manual inspection of supporting documentation shall confirm that the

Third Party implementation utilizes software libraries which are FIPS 140-2 level 1 or

higher and listed on the CMVP website.

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA001] Verify Data Custodian provides an Authorization Endpoint per OAuth 2.0 specification

•

[TR_OA002] Verify Data Custodian provides a Token Endpoint per OAuth 2.0 specification

•

[TR_OA004] Verify Data Custodian provides client with Third Party ID value per OAuth 2.0 specification

•

[TR_OA005] Verify Data Custodian provides client with Third Party Secret value per OAuth 2.0 specification

•

[TR_OA007]

Verify Data Custodian rejects an Authorization Code Request with NO "Response Code" parameter

•

[TR_OA008]

Verify Data Custodian rejects an Authorization Code Request with NO "client_id" parameter

•

[TR_OA009]

Verify Data Custodian rejects an Authorization Code Request with NO "scope" parameter

•

Check on “redirect_uri” parameter

•

Check on “state” parameter

•

[TR_OA010]

Verify Data Custodian rejects an Authorization Code Request containing multiple "response_type"

parameters

•

[TR_OA011]

 Verify Data Custodian rejects an Authorization Code Request containing multiple "client_id" parameters

•

[TR_OA012]

Verify Data Custodian rejects an Authorization Code Request containing multiple "scope" parameters

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA013]

Verify Data Custodian rejects an Authorization Code Request containing multiple "redirect_uri"

parameters

•

[TR_OA014]

Verify Data Custodian rejects an Authorization Code Request containing multiple "state" parameters

•

[TR_OA015]

Verify Data Custodian rejects an Authorization Code Request containing an INVALID parameter

•

[TR_OA016]

Verify Data Custodian rejects an Authorization Code Request with an INVALID "Response Code" parameter

•

[TR_OA017]

Verify Data Custodian rejects an Authorization Code Request with an INVALID "client_id" parameter

•

[TR_OA018]

Verify Data Custodian rejects an Authorization Code Request with an INVALID "redirect_uri" parameter

•

[TR_OA019]

Verify Data Custodian rejects an Authorization Code Request with an INVALID "scope" parameter

<Note:

May need various forms of Invalid SCOPE Parameter Values ????>

•

[TR_OA020] Verify Data Custodian properly validates Retail Customer while processing a valid Authorization Code

Request

•

[TR_OA021]

Verify Data Custodian proper handles a Retail Customer who fails to pass authentication testing while

processing a valid Authorization Code Request

•

[TR_OA022] Verify Data Custodian properly obtains the Retail Customer's authorization for the Third Party to access

their data while processing a valid Authorization Code Request

•

[TR_OA023]

Verify Data Custodian properly processes a Retail Customer's denial to allow a Third Party to access their

data while processing a valid Authorization Code Request

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA024] Verify Data Custodian properly processes a Retail Customer's authorization to allow a Third Party to access

their data while processing a valid Authorization Code Request

•

[TR_OA027] Verify Data Custodian properly authenticates and accepts an Access Token Request with a valid HTTP

BASIC Authorization header

•

[TR_OA028]

Verify Data Custodian rejects an Access Token Request with an INVALID HTTP BASIC Authorization header

•

[TR_OA029]

 Verify Data Custodian properly authenticates the authorization_code contained in the "code=" parameter

of an Access Token Request was issued to the "client_id" in the Access Token Request

•

[TR_OA030] Verify Data Custodian accepts an Access Token Request containing an authorization_code ("code="

parameter) issued to the "client_id" in the Access Token Request

•

[TR_OA031]

 Verify Data Custodian rejects an Access Token Request with NO "grant_type" parameter

•

[TR_OA032]

Verify Data Custodian rejects an Access Token Request with NO "code" parameter

•

[TR_OA033]

Verify Data Custodian rejects an Access Token Request with NO "redirect_uri" parameter

•

[TR_OA034]

Verify Data Custodian rejects an Access Token Request with NO "client_id" parameter

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA035]

Verify Data Custodian rejects an Access Token Request with multiple "grant_type" parameters

•

[TR_OA036]

Verify Data Custodian rejects an Access Token Request with multiple "code" parameters

•

[TR_OA037]

Verify Data Custodian rejects an Access Token Request with multiple "redirect_uri" parameters

•

[TR_OA038]

Verify Data Custodian rejects an Access Token Request with multiple "client_id" parameters

•

[TR_OA039]

Verify Data Custodian rejects an Access Token Request with a "client_id" parameter and a HTTP BASIC

authorization field

•

[TR_OA040]

 Verify Data Custodian rejects an Access Token Request containing an authorization_code ("code="

parameter) NOT issued to the "client_id" in the Access Token Request

•

[TR_OA041]

Verify Data Custodian rejects an Access Token Request containing an INVALID authorization_code

("code=" parameter)

•

[TR_OA042]

 Verify Data Custodian rejects an Access Token Request not containing a "redirect_uri" parameter if the

original Authorization Request contained a "redirect_uri" parameter

•

[TR_OA043]

 Verify Data Custodian rejects an Access Token Request containing a "redirect_uri" parameter if the

"redirect_uri" does NOT match the "redirect_uri" parameter contained in the original Authorization Request

parameter

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA044]

 Verify Data Custodian rejects an Access Token Request containing a "redirect_uri" parameter if the original

Authorization Request did NOT contain a "redirect_uri" parameter

•

[TR_OA045]

Verify Data Custodian rejects an Access Token Request containing a previously used authorization_code

•

[TR_OA046]

Verify Data Custodian rejects an Access Token Request containing an expired authorization_code

•

[TR_OA047] Verify Data Custodian issues a properly formatted Access Token Response (grant_type=authorization_code)

•

[TR_OA050] Verify Data Custodian issues a properly formatted Access Token Response (grant_type=client _credentials)

•

[TR_OA051]

Verify Data Custodian rejects an Access Token Request with multiple "grant_type" parameters

•

[TR_OA052]

Verify Data Custodian rejects an Access Token Request with multiple "scope" elements

•

[TR_OA053]

Verify Data Custodian rejects an Access Token Request with an INVALID "scope" parameter

<Note: May need various

forms of Invalid SCOPE Parameter Values ????>

•

[TR_OA056]

Verify Data Custodian rejects a Refresh Token Request with NO "grant_type" parameter

•

[TR_OA057]

Verify Data Custodian rejects a Refresh Token Request with NO "refresh_token" parameter

•

[TR_OA058]

Verify Data Custodian rejects a Refresh Token Request with multiple  "grant_type" parameters

FB_14: Authorization and Authentication (OAuth)

Initial Set of Test Requirements

•

[TR_OA059]

Verify Data Custodian rejects a Refresh Token Request with multiple "refresh_token" parameters

•

[TR_OA060]

Verify Data Custodian rejects a Refresh Token Request with multiple "scope" parameters

•

[TR_OA061] Verify Data Custodian properly authenticates and accepts a Refresh Token Request with a valid HTTP

BASIC Authorization header

•

[TR_OA062]

Verify Data Custodian rejects a Refresh Token Request with a INVALID HTTP BASIC Authorization header

•

[TR_OA063]

Verify Data Custodian rejects a Refresh Token Request containing a "refresh_token" element that was

NOT issued to the requesting Third Party Application

•

[TR_OA064]

Verify Data Custodian rejects a Refresh Token Request containing a "refresh_token" element that is

expired

•

[TR_OA065]

Verify Data Custodian rejects a Refresh Token Request containing a "scope" element that does NOT

match the "scope" element value used to obtain the original Access Token.

•

[TR_OAxxx]

Verify Data Custodian handling of expired Access Token and Refresh Token

FB_19: Partial update of data

•

Is this requirement for upload role and not

core data custodian?

[FB_37] Query Parameters

•

Support published_min, published_max

[FB_40] Offline RetailCustomer

Authorization

•

Manual Creation of ApplicationInformation,

Authorization(s)

ReadingType Attributes

•

PG&E notices that their MDM uses various

ReadingType attribute values that are not the

same as those in the DMD test suite.

•

Question – should meter data reflect the

diversity of the meter system or the meaning

of data conveyed to the ThirdParty

•

Folks will look at their data and thinking

further.

Interpretation of Quality Flags for UsageSummary,

ReadingType, and IntervalReading

•

ReadingType.defaultQuality contains the default quality that applies

to all corresponding IntervalReading data.

•

IntervalReading.ReadingQuality.quality allows specific Intervals to

override the default in ReadingType

•

If IntervalReading data or quality tags are modified, DataCustodian

should notify of this change so ThirdParty can retrieve the changes.

•

UsageSummary.qualityOfReading if present indicates that those

IntervalBlocks within the scope of the UsageSummary.billingPeriod

may have changed quality as well. Third Party may want to retrieve

data again to see the revisions if any.

•

The DC may indicate to the TP that IntervalBlock data has changed

by sending a notification for the IntervalBlocks that changed.

Testing and Certification Issues

•

Test Third Party role for testing DataCustodian

•

Test accounts (how many ; real-or-not ; how much

history?)

•

Test Set up – Application Information

•

How to put DC in reproducible state – reset?

•

Minimum FBs to test –

–

FB_3, 13, 14, 19,37,39

•

Alternative – Test Environment that is same as the Live

environment

–

Same Certs etc…

–

Does it need to be real data?

ElectricPowerUsageSummary

•

Make general UsageSummary and deprecate

ElectricPower one…

•

Let query determine period not current/last

•

How to rename fields to remove current/last

ambiguity for past requests

•

Determine what required fields might be and

some possible new FB to support ecosystem

interoperability

•

Single Demand fields too limiting for modern

tariffs.

UsageSummary Recommendataions

•

Create new UsageSummary (which is NAESB REQ.18

name)

•

Add new tags recommended by PG&E

•

Retain all existing tags and make UsageSummary and

ElectricPowerUsageSummary identical – but mark old

one deprecated for backwards compatibility – new

implementations will have to accept either Resource

on input

•

Revise descriptions of existing tags to make clear what

goes with billing period etc.

•

Provide documentation on how to interpret query

parameters for GET UsageSummary

UsageSummary Use Cases

•

I ask for summary today (with day later publishing)

•

I ask for 3 months last year (query parameters?)

•

Billing period is non-calendar

•

John: I ask for an arbitrary period “roll-up” of

consumption

•

GET UsageSummary

min=1/15/2014&max=2/28/2014

&rollup=True

–

In PGE concept – you get 2 UsageSummarys – one for

billing period January and one for billing period February

–

In John concept – you get 1 UsageSummary with totals for

1/15..2/28

Documentation Issues

•

Do in GreenButtonAuthorization.docx section

2.4

–

Use Cases for Authorization Termination

(revocation) --

–

DC-oriented control of termination process due

regulatory requirements in Ca.

•

Do in section 2.8

–

Behavior of GET UsageSummary with query

parameters

Service Request 83 – including Function Block for optional customer info

(service point address, etc.)

•

Requirements

–

UsagePoints of RetailCustomer

–

Location of premise

–

Account ID

–

Sub Account (SA) ID—Service Agreement / Account is name depending on utility

–

Customer name, nickname (or short name)

–

Address and info



 from Lynn will provide more information

–

SDG&E provides only email address and UPID correspondence csv email and UsagePoint ID (Customer Obfuscated Key)

–

Current ESPI resources will never return PII

–

GET Subscription does not contain PII

–

Single Authorization covers entire Subscription and Authorization Scope

–

MeterID

–

ServicePointId

–

Pnode

–

LoadAggregationPoint, SubloadAggregationPoint

–

Climate zone

–

Account open date

–

Account close date

–

SA Open and Close date

–

MDM Agent Id (who does meter read)

–

ServiceSupplierId

–

EnergyServiceProviderId (may be same as service supplier)

–

Demand Response Provider

–

May need list of Ids for service providers rather than explicit?? (0..* relationship{role, href})

–

Related assets ???? For example pool pump and pool pump participation in a program.

–

Related programs ????

•

Implementation

–

Resource Definition

•

Probably multiple resources are good idea

–

REST service to exchange resource(s)

•

GET only

–

Function Block(s)

•

Wholesale vs Retail

–

Optionality vs Required

–

Possible Scope spec

For May 20 Topics

•

Use Case for “verified for billing”

–

Added

•

ServiceStatus – return data

–

Simple status or, outstanding batchlists

–

Consensus: Don’t really need this extension because the

DC can determine if it wants to send a notification of what

hasn’t been retrieved at its discretion.

•

Revised Authorization document

•

Use Case for Small ThirdParty / Mega ThirdParty …

maybe another day in future

xs:enumeration

 value

="

">

xs:annotation

xs:appinfo

revenue-quality

</

xs:appinfo

xs:documentation

data that is valid for billing purposes

</

xs:documentation

</

xs:annotation

</

xs:enumeration

Service Status

•

Consensus: Don’t really need this extension because the DC

can determine if it wants to send a notification of what hasn’t

been retrieved at its discretion.

•

As is in standard

•

Enhanced to add current outstanding batchlist

<?xml version="1.0" encoding="UTF-8"?>

ServiceStatus

 xmlns

="

http://naesb.org/espi

 xmlns:xsi

="

http://www.w3.org/2001/XMLSchema-instance



xsi:schemaLocation

="

http://naesb.org/espi espiDerived.xsd

">

extension

text

</

extension

currentStatus

</

currentStatus

batchList

resources

../espi/1_1/resource/Batch/Bulk/1?start-index=1&max-results=1000&amp;published-max=2012-04-02T04:00:00Z&amp;





published-min=2012-04-02T04:00:00Z

</

resources

resources

../espi/1_1/resource/Batch/Bulk/1?start-index=1&max-results=1000&amp;published-max=2012-04-02T04:00:00Z&amp;



published-min=2012-04-02T04:00:00Z

</

resources

</

batchList

</

ServiceStatus

<?xml version="1.0" encoding="UTF-8"?>

ServiceStatus

 xmlns

="

http://naesb.org/espi

 xmlns:xsi

="

http://www.w3.org/2001/XMLSchema-instance



xsi:schemaLocation

="

http://naesb.org/espi espiDerived.xsd

">

currentStatus

</

currentStatus

</

ServiceStatus

Authorization

•

What happens when authorization changes –

UsagePoints or period

–

When Authorization changes, place

authorizationUri in notification to ThirdParty

which can then re-establish its state

What can you negotiate with Scope?

•

FBTerms – data content, CMD services

•

ValueTerms – default durations and blocking,

history length, subscription frequency (i.e.

daily data cycle)

•

ResourceTerms – specific resources available

by api, bulkID assignments, bulkaccount

•

Other?

Scope Negotiation

HTTP Redirect with

Scope={scope1} {scope2} …

Logon

Logon

Authorization request

Scope={scope2}

Authorization response

Scope={scope2}

access-token

resourceUri

authorizationUri

referenceId

…

Oversimplified sequence diagram of Use Case #2

showing essence of scope negotiation

Scope issues

•

Limit Scope to access-token and minimal exchange requirements

•

Add list of UPs in a subsequent GET request

–

Could include UPs, optional location, additional data

–

We would define new resource that has this data

•

Are there options?

–

FB_XX Minimum data –

»

UsagePoint

–

FB_XY Optional data

»

location

•

Should it be a different namespace and XSD?

–

We need to make sure they are mutually exclusive – the usage and the PII containing data

–

Namespace and separate schema minimize the opportunity for comingling of data

•

Single authorization with multiple UPs with different scopes

–

Don suggested that the scope is a union of capabilities. You need to get the data to see details

–

Jerry suggests scope be provided with UP?

CSV from GB Data

CSV File that

opens in Excel

Notification

HTTP POST

Content-type: application/atom+xml

A Couple of Use Cases

•

Use Case 1: How to do Gas and Electric in one Authorization

–

An Authorization

–

Two UsagePoints

–

One Gas One Electric

–

Different Scope

•

Use Case 2: CISR based Authorization

–

Customer logs in has id for utility website

–

Each login has multiple electricity accounts

–

Each account can be multiple usage points

–

Customer login id becomes obfuscated {referenceId} which can be used in

REST Uris of the form: /espi/1_1/resource/RetailCustomer/{referenceId}/**

–

Authorization enables a subcriptionID and authorizationID which is (internally)

correlated to the customer and the subselection of usagepoints

Discussion on Authorization Structure

•

Authorization enables the following URLs:

•

<resourceURI>http://localhost:8080/DataCustodian/espi/1_1/resource/Batch/Subscription/1</resourceURI>

•

<authorizationURI>http://localhost:8080/DataCustodian/espi/1_1/resource/Authorization/1</authorizationURI>

•

/espi/1_1/resource/RetailCustomer/<referenceID>/UsagePoint/...

•

•

(SA == UsagePoint, CISR == subscription == authorization)

•

•

with Access-token

•

GET /espi/1_1/resource/RetailCustomer/<referenceID>/UsagePoint

•

•

<feed>

•

    <entry>

•

    <id>urn:uuid:40BE6242-F7E6-4B51-828E-59B5FC0C35F0</id>

•

        <link rel="self" href="https://localhost:8080/DataCustodian/espi/1_1/resource/RetailCustomer/9B6C7065/UsagePoint/5446AF3F"/>

•

        <link rel="up" href="https://localhost:8080/DataCustodian/espi/1_1/resource/RetailCustomer/9B6C7065/UsagePoint"/>

•

        <link rel="related" href="https://localhost:8080/DataCustodian/espi/1_1/resource/RetailCustomer/9B6C7065/UsagePoint/5446AF3F/MeterReading"/>

•

        <link rel="related"

href="https://localhost:8080/DataCustodian/espi/1_1/resource/RetailCustomer/9B6C7065/UsagePoint/5446AF3F/ElectricPowerUsageSummary"/>

•

        <link rel="related" href="https://localhost:8080/DataCustodian/espi/1_1/resource/LocalTimeParameters/01"/>

•

        <title>a galaxy far, far away</title>

•

        <content>

•

            <UsagePoint xmlns="http://naesb.org/espi">

•

                <ServiceCategory>

•

                    <kind>0</kind>

•

                </ServiceCategory>

•

            </UsagePoint>

•

        </content>

•

        <published>2012-05-03T04:00:00Z</published>

•

        <updated>2012-05-03T04:00:00Z</updated>

•

    </entry>

•

...

•

</feed>

Customer Information Resource

•

Requirements

–

UsagePoints of RetailCustomer

–

Location of premise

–

Account ID

–

Sub Account (SA) ID -- Service Agreement / Account is name depending on utility

–

Customer name

–

SDG&E provides only email address and UPID correspondence csv email and UsagePoint ID

(Customer Obfuscated Key)

–

Current ESPI resources will never return PII

–

GET Subscription does not contain PII

–

Single Authorization covers entire Subscription and Authorization Scope

•

Implementation

–

Resource Definition

–

REST service to exchange resource(s)

–

Function Block

–

Possible Scope spec

NAESB REQ.18 Extended Customer Information

This data is already

part of the PAP10

parent model to

ESPI – REQ.18

This data is part of CIM and associated

with CustomerAgreement

ServiceLocation may be equal to

ServiceDeliveryPoint which is no longer

in CIM

Common Information Model (CIM) Customer

Overview

IEC 61968 and IEC 61970

UsagePoint (from espiderived.xsd)

Obfuscated tariff ID

Obfuscated

customerAgmtID

Possible Arrangement of Data

“pulling the string”

RetailCustomer

UsagePoint

EndDeviceAsset

ServiceLocation

PostionPoint

TariffProfile

Customer

Agreement

Authorization

ServiceSupplier

Normal ESPI

Resources

Possible Arrangement of Data

“pulling the string”

RetailCustomer

UsagePoint

EndDeviceAsset

ServiceLocation

PostionPoint

TariffProfile

Customer

Agreement

Authorization

ServiceSupplier

FB3 - Core REST Services

–

[TR_CR003] Verify ReadServiceStatus returns

“active” status

FB31 - Core REST Services

–

[TR_CR001] Verify the Authorization can be retrieved using the

authorizationUri (from the authorization process in FB-14 or FB-40)

–

[TR_CR002] Verify the Authorization resource does not contain PII by

inspection

–

[TR_CR003] Verify ReadServiceStatus returns “active” status

–

[TR_CR004] Verify Batch/Subscription/{subscriptionId} returns a valid

Atom

feed with all UsagePoints and related data including all interval data

–

[TR_CR005] Verify structured URIs are of the form

{DataCustodianResourceEndpoint}[/{keyterm}/{id}]* based on the structure of

Green Button APIs

–

[TR_CR006] Verify /RetailCustomer/{retailCustomerID}/UsagePoint Returns list

of UsagePoints only under the Authorization

–

[TR_CR007] Verify

Batch/RetailCustomer/{RetailCustomerId}/UsagePoint/{UsagePointId} Returns

all data under and including a single UsagePoint

–

[TR_CR008] Verify that resources returned by the resourceUri are valid to the

schema, proper linking, and verify that the data meets the test requirements

based on PICS for content and consistency

FB 13: Security Testing

•

Cyber Security and Privacy Test Requirements

–

Based on Authorization.docx section 2.7

•

From SGIP SGCC Committee review of REQ.21

•

Reviewed with NIST Cyber Security staff

•

NAESB REQ.21 section

•

Initial set of test requirements on next slide

Initial Set of Test Requirements

•

[TR_TC001] Test software shall issue a service request over an SSL session and shall verify that the response HTTP header contains the following fields

and information – fields TBD

•

[TR_TC002] Verify that REST request headers include – fields TBD

•

[TR_TC003] Verify that the Data Custodian implements TLS 1.2.

•

[TR_TC004] Verify that when communicating with a Retail Customer the Data Custodian negotiates the highest level of TLS mutually supported.

•

[TR_TC005] Verify that when communicating with a Retail Customer the Data Custodian rejects TLS_RSA_WITH_NULL_SHA cipher suites.

•

[TR_TC006] Verify that when communicating with a Retail Customer at a minimum the Data Custodian accepts the

TLS_RSA_WITH_AES_128_CBC_SHA cipher suite.

•

[TR_TC007] Verify that when communicating with a Third Party the Data Custodian negotiates the highest level of TLS mutually supported.

•

[TR_TC008] Verify that the Data Custodian maintains an unexpired unrevoked RSA certificate with a public key length of at least 2048 bits.

•

[TR_TC009] Test software or manual inspection shall verify that the Data Custodian RSA certificate was issued by a Certificate Authority (CA) that has

been successfully audited according to the criteria of ETSI or WebTrust.

•

[TR_TC010] Test software or manual inspection shall verify that Tokens and IDs communicated by the Data Custodian are opaque and if based on

actual Customer information that they are randomized using a secure method to protect privacy.

•

[TR_TC011] Test software or manual inspection shall verify that Tokens and IDs communicated by the Data Custodian consist of at least 48 bits and

can be the random number part of an RFC2422 UUID.

•

[TR_TC012] Manual inspection of supporting documentation shall confirm that the Data Custodian implementation utilizes software libraries which

are FIPS 140-2 level 1 or higher and listed on the CMVP website.

•

[TR_TC013] Verify that the Third Party implements TLS 1.1 or higher.

•

[TR_TC014] Verify that when communicating with a Retail Customer the Third Party negotiates the highest level of TLS mutually supported.

•

[TR_TC015] Verify that when communicating with a Data Custodian the Third Party negotiates the highest level of TLS mutually supported.

•

[TR_TC016] Verify that the Third Party maintains an unexpired unrevoked RSA certificate with a public key length of at least 2048 bits.

•

[TR_TC017] Test software or manual inspection shall verify that the Third Party RSA certificate was issued by a Certificate Authority (CA) that has

been successfully audited according to the criteria of ETSI or WebTrust.

•

[TR_TC018] Test software or manual inspection shall verify that Tokens and IDs communicated by the Third Party are opaque and if based on actual

Customer information that they are randomized using a secure method to protect privacy.

•

[TR_TC019] Test software or manual inspection shall verify that Tokens and IDs communicated by the Third Party consist of at least 48 bits and can

be the random number part of an RFC2422 UUID.

•

[TR_TC020] Manual inspection of supporting documentation shall confirm that the Third Party implementation utilizes software libraries which are

FIPS 140-2 level 1 or higher and listed on the CMVP website.

[FB_14] Authorization and

Authentication (Oauth 2.0)

–

Verifying response to invalid authorization request

(invalid access-token for resource)

–

Verify rejection of request missing access-token

–

Missing header parameters

–

Invalidation of access-token at end of

authorization period

Function Blocks for CMD

Opaque vs Structured URIs

•

No structure, support

Opaque URIs

using either HTTPS or FTPS

protocols in conjunction with the

espiDerived.xsd

 schema. Make

Opaque URIs part of the

CORE CMD function block

•

 Optional support Structured URIs using either HTTPS or FTPS

protocols:  make Opaque URIs part of the

CORE CMD function

block

,  and  structured URIs an

optional Function Block

 in CMD

Testing & Certification in conjunction with

the

espiDerived.xsd

 schema

•

Required Structure, make structured URIs a requirement but allow

some variability – e.g. User versus RetailCustomer; Thus s

tructured

URIs would be part of the CORE CMD function block

 in CMD Testing

& Certification in conjunction with the

espiDerived.xsd

 schema.

•





Specific Required Structure  based on

espiDerived.xsd

Resource Names as described in two

documents:

GreenButtonAtomLinks

and

Authorization document

Changes in espiderived.xsd from

espi.xsd

•

*Enumerations: The largest volume of changes is in the explicit

documentation of the many enumerations in the standard. In the

standard, only a few examples from the IEC standard were provided

in a comment. Values that distinguish measurements of Wh, W, VAr,

VA, gas, water, etc… are tested for in DMD if corresponding FBs are

indicated.

•

*Errors of data type corrected – value, cost, and currency all had

deficient data types that were recognized early on

•

*Representation of conversion factors from UTC to Local Time:

LocalTimeParameters resource was added

•

*Missing overallConsumptionLastPeriod was added to make

ElectricPowerUsageSummary rational as a record of billing period

consumption

•

Support for OAuth 2.0: the second largest volume of changes to the

schemas is in support of CMD (no impact to DMD)

* Differences tested for in T&C

Test Requirements for CMD

Brainstorm

•

FB31 - Core REST Services

–

Verify the authorization can be retrieved

–

Lack of PII

–

Ditto Batch/Subscription, Batch/RetailCustomer, and

UsagePoint

–

Verify that resource returned is valid to schema and

links are correct

–

Verify structured URIs

–

Verify all required content is present (based on PICs)

–

Could be FB_14

•

Verifying response to invalid authorization request (invalid

access-token for resource)

•

Verify rejection of request missing access-token

•

Missing header parameters

•

Invalidation of access-token at end of authorization period

For February 25

•

John Teeter raises issue of path vs opaque

URIs for REST services for individual and

subscription resources

–

Does the uri give any indication of what will be

retrieved or not?

Some URIs Found In GBDMD Files

•

URI ::= protocol://hostname:port/datacustodian/espi/1_1/resource/



 resource endpoint of the server

•

<link rel="self" href="User/9b6c7063/UsagePoint/01"/>

•

<NS:link rel="self" href="/User/9b6c7063/UsagePoint/01"/>

•

<atom:link href="User/9b6c7063/UsagePoint/01" rel="self"/>

•

<link rel="self" href="User/25cd2af5c5f6f693f8f6d62852033843/UsagePoint/01" />

•

<link rel="self" href="RetailCustomer/10/UsagePoint/01"/>

•

<link href="RetailCustomer/115973279529374200002937445377/UsagePoint/0" rel="self"/>

•

<link rel="self" href="RetailCustomer/765786587/UsagePoint/01" />

•

<link rel="self" href="/User/9b6c7063/UsagePoint/01"/>

•

<atom:link href="User/9b6c7063/UsagePoint/01" rel="self"/>

•

<link rel="self" href="/User/9b6c7064/UsagePoint/01"/>

•

<atom:link href="/User/9b6c7063/UsagePoint/01" rel="self"/>

•

<link rel="self" href="/RetailCustomer/1/UsagePoint/J2753386"/>

•

<link href="/v1/User/455/UsagePoint/580" rel="self"></link>

•

<link rel="self" href="User/9b6c7063/UsagePoint/01"/>

•

<link rel="self" href="User/9b6c7063/UsagePoint/01"/>

•

<link rel="self" href="User/9e610ca8441264b3d21cad5b2a13d028/UsagePoint/01" />

•

<link href="/v1/User/12704625/UsagePoint/4218907" rel="self"></link>

•

<link href="/User/4685/UsagePoint/67" rel="self"/>

•

<link rel="self" href="User/00e308198d020442995dea12c013f77a/UsagePoint/01" />

•

<link rel="self" href="/User/1564408+15644/UsagePoint/0"/>

Opaque URIs

•

Opaque URIs

–

No need to test structure

–

No need to recognize structure in sw

•

Structured URIs

–

Easier to recognize the links

–

Easier to validate what you are doing by looking at them

–

If I have interval block, I know all the possible URIs for that UsagePoint

•

Possible Outcomes of OpenADE Discussion?

–

No structure, support opaqueness

–

Optional Structure, make structured URIs an optional Function Block

–

Required Structure, make structured URIs a requirement but allow

some variability – e.g. User versus RetailCustomer

–



Single Required Structure – defined structure based roughly on

GreenButtonAtomLinks and Authorization documents

SFTP for Bulk Transfer

•

Pertinent to the SFTP discussion are the concepts that each Third Party has a defined relationship with the Data

Custodian.

–

For automated exchange of information about his relationship there is a special Authorization obtained in Use Case #1 (see the

Authorization.docx --

http://osgug.ucaiug.org/sgsystems/OpenADE/Shared%20Documents/Testing%20and%20Certification/GreenButtonTestPlan/ref

erenceMaterial/GreenButtonAuthorization.docx

).

–

We anticipate that when the Data Custodian has data available, it sends an asynchronous Notification to the Third Party.

–

This Notification provides URIs of note that it is assumed the Third Party will want to retrieve.

•

For the purposes of Bulk transfer, this URI will be:

–

sftp://hostname:port/DataCustodian/espi/1_1/resource/Batch/Bulk/{bulkId}

–

where {bulkId} is a unique identifier assigned by the Data Custodian and the balance of the URI is presented in the

ApplicationInformation resource  that both parties share (contains all relevant URIs and data for interchange via OAuth etc…).

The Third Party would then retrieve the bulk data by using an SFTP client with that URI. This is a straw man concept for

discussion on the call. Its advantage is that it in harmony with overall architecture of the Green Button Connect My Data RESTful

architecture and simply adds SFTP as a means of transfer when a large data set is to be returned.

•

Used to Retrieve the data using SFTP protocols

–

How to initiate the SSH connection?

–

What is the role if any of the client_credentials authorization to control access to SFTP enabled resources?

•

Discussion –

–

After authorization of TP, they use Pene test, so what is benefit of access-token?

–

sftp user:pw, user=<tpname>, password=<tp client-credentials access-token>

•

Summary

–

sftp://hostname:port/DataCustodian/espi/1_1/resource/Batch/Bulk/{bulkId}

–

sftp user:pw, user=<tpname>, password=<tp client-credentials access-token>

Function Blocks for CMD

•

Authorization Sequence

–

Scope

–

access-token

–

Refresh-token

–

resourceUri (the subscription)

–

authorizationUri

–

expiration of the access-token and refresh-token

–

token-type

Proposed CMD Function Blocks

Draft of API Allocations to FBs

Scope

Green Button Connect My Data Testing

and Certification

•

Complete function block descriptions

–

Current:

•

[FB_3] Green Button Connect My Data

•

[FB_13] Security and Privacy classes

•

[FB_14] Authorization and Authentication (OAuth)

•

[FB_19] Partial update data

–

New?:

•

Core Rest Services

–

GET Batch/Subscription

–

…

•

Resource Level REST

–

GET PUT POST DELETE individual resources …

•

SFTP for Bulk

•

REST for Bulk

•

Use Case 1: Client Registration

•

Query Parameters

•

On Demand Requests (as opposed to Notification followed by GET)

•

PUSH model

•

Offline Authorization to Complement OAuth – should this be outside the scope of standard and testing  or standardized?

–

No standard isolated way to get the token to a third party without OAuth

–

On exceptional basis some customers can’t be required to use a web account

–

Sometime commercial accounts don’t need privacy and want a service provider just to register the data.

–

Could use Notification service to tell TP about new authorizations made by DC. Out of band how RetailCustomer is identified to the TP

–

“transitive” model TP gets bulk data from DC and  then becomes DC – can this architecture be of help here?

–

Possible provision by DC of access token for conveyence to thirdparty devoid of customer information. Maybe even encrypted for TP as in software

activations:

»

“Please provide this to your TP (the text between  the ====)

»

=============================================

»

ashoiqwherfhdjnvcjq2dhijvkqnvoiikdfv

»

=============================================“

Questions

•

retailCustomerID=authorization=subscription

–

Corresponds to a single authorization

–

Results in one or more usagePoints being associated with subscription

–

Scope=

“FB=4,5,15;IntervalDuration=3600;BlockDuration=monthly;HistoryLen

gth=13;BulkAccountCollection=10”

•

Says that the BulkAccountCollection has 10 usage points

Authorization provides two URIs that can be used:

resourceUri



 GET this to retrieve usage data (all UPs)

authorizationUri



 GET/PUT details of Authorization

Notification is a list of URIs

All nested resources under the UPs are accessible under the single

authorization

Service Request 83 – including Function Block for optional customer info

(service point address, etc.)

Service Request 84 – having scope selection screen on Data Custodian Site vs

rd

 Party site

[85] Time of Use tier indicator alignment with

SEP 2.0

Here is a list of topics raised by you all that

we will touch on

•

Issues Raised and Implementation Questions

–

How to use BR=bulkID – relates to HD #61

–

Service Request 83 – including Function Block for

optional

 customer info (service point address, etc.)

–

Service Request 84 – having scope selection screen on

Data Custodian Site vs 3

rd

 Party site

–

Tariff Model Resource

•

Green Button Connect My Data Testing and

Certification

–

Complete function block descriptions

–

Complete test case requirements

How to use BR=bulkID – relates to HD #61

•

Application Profiles

–

BulkID was proposed for large sets of authorizations

–

One account level authorization on top of service level

accounts – how to do this

•

Degrees of freedom we have now – can we cover

–

Subscription – 1 or more Usage Points

•

Granularity of a customer authorization

–

BulkID

•

“macro” for a large set of existing authorizations

–

Is there another degree needed?

Contributed by Jerry Yip



Clarification/confirmation about ESPI standard:  Does ‘shared resource key’ referenced in the

NAESB Ratified word doc correspond to Access Token for oAuth?



Yes: This is the access token in the new Oauth 2.0 paradigm.



Formal Submission of Application Profile for bulk (vs. batch?) use case as part of GB/GBC

Conformance Testing Plan



Write up coming to test concept of BulkIDs



Question:  (options to address 1 Acct to many SA issue)

- Does UUID correspond to usage point (1-to-1 relationship)?

Is there passing of UUIDs (as resource

terms in Scope section of GBAuthorization) during authorization sequence?  (how would 3

rd

 Party

know multiple usage points have been authorized via single oAuth sequence/login?)

- Can multiple access tokens be issued (1 token per SA) per oAuth session?



An Authorization is one access_token



How does Third Party get to know the depth of data (how many Ups) are in the authorization



Perhaps an extension of scope string to have numUPs?



Request to consider scope selection screens at Data Custodian Portal instead of 3

rd

 party portal

(Need customer to select SAs to share – only Data Custodian has that info) – also minimizes number

of redirects (?)



Customer info as optional functional block (atom feed) for authorization (sharing with 3Ps)



John suggests – prep a large multi account data set and test against a reference sw implementation

and measure. SFTP and Streaming, compressed and non-compressed method and compare.

How to use BR=bulkID with application to account and

account groupings, as well as, large ThirdParty

collections of Authorizations

•

Establish Use Case Story for Commercial

Accounts

•

Design Scope String(s) that convey it

•

Repaint the storyboard with appropriate

content

Application Profile

•

Per footnote 1, pg 20 of GBAuthorization.doc:

–

A “Web Customer” may actually manage more than one “Retail Customer” where “Retail Customer” is an actual “Customer Account”.   Thus identifying the

specific Retail Customer may be part of the scope selection on both sides. The scenarios in this section refer to the “Retail Customer” for simplicity.

•

Suggest: new FB or Application Profile to properly capture this scenario

•

[FB_31] Web Customer Manages Multiple Customer Accounts

(OR: 3.9 Application Profile)

•

For GBCMD, this FB/AP contains tests associated with a Web Customer accessing a Data Custodian’s Web Portal to manage multiple customer

accounts.  Upon log in to the Data Custodian’s Web Portal, the web customer can manage multiple customer accounts, for which each customer

account can represent multiple usage points (for electricity and/or gas).  This mostly impacts large agricultural and commercial customer accounts for

which a single web customer can represent hundreds to thousands of individual usage points – imagine a franchise manager with multiple branch

locations across a data custodian’s service territory.

•

In this scenario, the Web Customer should have the ability to authorize, deauthorize and change scope on an individual “usage point” basis and

optionally at the larger aggregated web customer or customer account basis.  This includes the ability to perform one-time authorization of multiple

customer accounts by a single web customer to third party, and any subsequent scope changes (whether on an aggregated or individual basis) – third

party acknowledgement/communication of which customer accounts have been authorized, deauthorized or whose scope has changed needs to be

determined.

•

Notes:

–

Whether scope selection in this scenario should live on the 3

rd

 party portal vs. the Data Custodian’s portal needs to be determined as well.

–

Collection has one description or multiple?

–

What is the scope string for this use case?

–

Is there a need for a bulkId in this case (maybe not).

–

New Scope Resource Term= “BulkAccountCollection”

–

Scope= “FB=4,5,15;IntervalDuration=3600;BlockDuration=monthly;HistoryLength=13;BulkAccountCollection”

•

1/14/2014

–

To allow the TP to know how many Ups are being provided, suggest Add to BulkAccountCollection a number of UsagePoints BulkAccountCollection=nnn

UsagePoint Grouping in Commercial

Account Management

BulkId

SubscriptionId

UsagePointId

/web account

Via gui

Scope= “FB=4,5,15;IntervalDuration=3600;BlockDuration=monthly;HistoryLength=13;BulkAccountCollection”

Slide Note

Embed Share

Download

Agenda items discussed in the Weekly OpenADE Meeting on March 7, 2017 included Alternative OAuth Flow for ESPI alignment with OAuth 2.0 Specification, considerations on the authorizedPeriod definition, and decisions on Data Custodian scope negotiation and authorization period indications. The Task Force focused on ensuring compliance with current specifications and addressing potential challenges related to data certification testing.

whi_ehr Follow

Uploaded on Sep 17, 2024 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript

Weekly OpenADE Meeting Notes Tuesday, March 7, 2017

March 7, 2017 -- Agenda HelpDesk #98 Alternative Oauth Flow for ESPI to align with Oauth 2.0 Specification California CPUC requires OAuth 2.0 authorization_code flow meet Oauth 2.0 RFC 6749 specifications Current Data Custodian Connect My Data Certification test harness currently meets this requirement At question is should the current Data Custodian Connect My Data Certification test harness make Third Party/Data Custodian Scope negotiation optional and thus require changes to the test case requirements and test steps The Task Force decided that the Data Custodian Connect My Data certification test harness MUST provide the ability to be certified using the current Scope Selection Screen flow and the Oauth 2.0 authorization_code flow without accessing the Scope Selection Screen endpoint HelpDesk #98 Is the current definition of authorizedPeriod sufficient? The current definition of authorizedPeriod (found in the ESPI authorization structure) is UINT32, which supports 4,294,967,295 seconds. Some Data Custodians are setting "infinite" expiration periods that exceed this maximum value. The Task Force decided to enforce the current UINT32 definition and ensure Data Custodians use an end date that does not exceed the UINT32 capacity How should a Data Custodian indicate an infinite period? The Task Force decided to indicate a value of 0 in the authorizedPeriod represents an infinite authorization period as part of the ESPI Redline revision.

<ns1:entry> <ns1:id xsi:type="ns1:idType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">bed0b17a-6712-40f4-96a1- 487ca6a75244</ns1:id> <ns1:link href="https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization" rel="up" xsi:type="ns1:linkType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"/> <ns1:link href="https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization/420091" rel="self" xsi:type="ns1:linkType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"/> <ns1:published xsi:type="ns1:dateTimeType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">2017-02- 08T16:37:40.701Z</ns1:published> <ns1:updated xsi:type="ns1:dateTimeType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">2017-02- 08T16:37:40.702Z</ns1:updated> <ns1:content xsi:type="ns1:contentType" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"> <ns0:Authorization xmlns:ns0="http://naesb.org/espi"> <ns0:authorizedPeriod> <ns0:duration>251,915,702,400</ns0:duration> 4,294,967,295 <ns0:start>1486540800</ns0:start> </ns0:authorizedPeriod> <ns0:publishedPeriod> <ns0:duration>251978860800</ns0:duration> <ns0:start>1423382400</ns0:start> </ns0:publishedPeriod> <ns0:status>1</ns0:status> <ns0:expires_at>1486575162</ns0:expires_at> <ns0:scope>FB=1_3_8_13_14_18_19_31_32_35_37_38_39_40_4_15_10_46_47_16_5;IntervalDuration=900_3600;BlockDuration=D aily;HistoryLength=63072000;SubscriptionFrequency=Daily;AccountCollection=1;BR=50036;</ns0:scope> <ns0:token_type>Bearer</ns0:token_type> <ns0:resourceURI>https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Subscription/420091</ns0:resourceURI> <ns0:authorizationURI>https://api.pge.com/GreenButtonConnect/espi/1_1/resource/Authorization/420091</ns0:authoriz ationURI> </ns0:Authorization> </ns1:content> </ns1:entry>

March 7, 2017 -- Agenda Future Connect My Data Certification Testing Third Party Connect My Data Certification Tasks Data Custodian Connect My Data Retail Customer Certification Tasks

February 28, 2017 -- Agenda Should Certification Test verify Data Custodian only sends data authorized by retail customer? Group agreed the Certification test should verify Data Custodian interval data must meet Scope FB definitions authorized by retail customer. What data should be returned for /resource/Subscription/{subscriptionId}/UsagePoint/{usagePointId}/Meter Reading/ Only MeterReading elements will be returned Should DC CMD Test Harness check non-batch API implementations HelpDesk #98 Alternative Oauth Flow for ESPI to align with Oauth 2.0 Specification California CPUC requires OAuth 2.0 authorization_code flow meet Oauth 2.0 RFC 6749 specifications Current Data Custodian Connect My Data Certification test harness currently meets this requirement At question is should the current Data Custodian Connect My Data Certification test harness make Third Party/Data Custodian Scope negotiation optional and thus require changes to the test case requirements and test steps

February 28, 2017 -- Agenda Future Connect My Data Certification Testing Third Party Connect My Data Certification Tasks Data Custodian Connect My Data Retail Customer Certification Tasks

CPUC Rule 24: One-Click Has there been a CPUC Final Ruling? Yes. Authorizations must start and finish on the Third Party website CPUC has agreed IOUs can implement authorization via OAuth 2.0 Does CPUC require Data Custodian s to grant multiple Third Parties Access Tokens with One Customer Authorization How should Super Third Party access tokens be assigned Super Third Party is a Third Party that retrieves Energy Usage Information on behalf of their Third Party customer (i.e. Utility API model)

CPUC Appendix E DRP Requirements for Solution 3 OAUTH improvements 1. Support authorizations to 2 or more DRPs for the same customer at the same time Needs further investigation and discussion 2. The url that DRP redirects the user to should be the OAuth authorize url (as defined in OAuth 2.0 specification). Requires a new optional Certification Function Block (FB) to verify IOU does not require DRP authorizations to access ESPI ScopeSelectionScreen endpoint 3. The IOU only redirects to authentication interface if needed, then redirects back to the original OAuth authorization url

CPUC Appendix E DRP Requirements for Solution 3 4. Authentication interface must be skipped if user already has valid authentication session cookie 5. Authentication interface must be able to allow password resets/reminders and still remain in authorization flow 6. Authentication interface must be able to allow login credentials as authentication fields 7. Authentication interface must have alternative instant authentication for users without logins (account# + zip, etc.)

CPUC Appendix E DRP Requirements for Solution 3 8. Best case authorization interface must be 1-click Authorize button 9. Default is all services are pre-selected and customer has to un-select the ones they want to exclude 10.Redirected back to DRP with code after clicking Authorize , no confirmation page on IOU 11.Valid implementation of OAuth 2.0 Code Grant Flow per https://tools.ietf.org/html/rfc6749#section-4.1.

CPUC Appendix E DRP Requirements for Solution 3 12.Authorize url meets OAuth 2.0 spec per https://tools.ietf.org/html/rfc6749#section- 4.1.1. Additional value= parameters need to be allowed for IOU DRP specific information Additional optional Function Block testing for DRP support needs to be added to the current CMD certification test suite 13.Be able to handle state parameters, even through authentication interface.

CPUC Appendix E DRP Requirements for Solution 3 13. Be able to register multiple redirect_uris with IOUs so that DRPs can have testing/staging/production redirect_uris 15. Be able to handle re-authorization for new code grant if DRP has lost previous code or access_token Requires addition of test script to confirm Data Custodian meets above requirement. 16. Be able to handle a user declining to authorize a DRP in both authentication and authorization interface. 17. Be able to redirect errors back to the DRP per https://tools.ietf.org/html/rfc6749#section-4.1.2.1

Query Parameters Atom published -- represents the time stamp when the containing entry was created updated represents the time stamp when the containing entry was changed Original Intent Required: query using published_min,max allows search of IntervalBlocks that contain intervals between min and max Does this require correct values for published in atom or just that the query parameters are properly interpreted?

Query Parameter Requirements From GreenButtonAuthorization.docx

Current Implementations LH published timestamp is the end of the first interval in the IntervalBlock PGE published timestamp is the moment of creation of the XML result Query parameters published_min/max must be interpreted in the context of the IntervalBlocks which is the data actual being sought by the query Certification Test Algorithm: 1. Test Harness performs an authorization on the test account 2. Test account must have 4 or more interval blocks of data 3. Test Harness does GET on resourceURI returning subscription with n IntervalBlocks 4. Test Harness does GET on resourceURI with 1. published_min equal to the IntervalBlock.start time of the 2nd IntervalBlock returned in step 3 2. published_max equal to the IntervalBlock.start time (n-1)th IntervalBlock returned

Initial Third Party Test Requirements very rough [FB_20] Common Common configuration data exchange [FB_21] Connect My Data Support Application Info request or other similar from FB_03 Support notification reception [FB_22] Security and Privacy Classes Support the TP version of FB_13 (relaxes from TLS 1.2 to TLS 1.1, I don t know if there is anything else different). [FB_23] Authorization and Authentication Perform the client side of OAuth [FB_24] Request Bulk UsagePoints If supported, receive a Notification and to an bulk GET or SFTP GETALL [FB_25] Request Partial Update Data No initial tests required [FB_26] Properly Respond to Various Bad or Missing Data Perform authorization, TP performs GET of resourceURI, provide several examples of bad data [FB_42] Core REST Services No initial tests required

Older or other slides Will build deck with new content over time.

Topics Service Request 95 Green Button Download My Data Gas Function Block [FB_10] only allows "therms" UOMType = 169 Permit therms, joules, ft3, m3 expand acceptance of test Optionally if you have volume, add MeterReading, ReadingType, and IntervalBlock for convervion factor history Service Request 96 Green Button Download My Data Water Function Block [FB_11] only allows UOMType = 128 (US gl (US Gallons) Permit US Gallons, ft3, and m3 expand acceptance of test Service Request 97 Update UsagePoint for 61968-9 2nd edition elements Service Request 83 including Function Block for optional customer info (service point address, etc.) retailcustomer.xsd Updated schema espiderived.xsd LSE, MDMA, MSP identification Sub-LAP and LCA planning bus and a market operations bus? Accept API and FBs Generate Test Requirements espiderived.xsd Updated UsagePoint Populating UsageSummary bill elements Query Parameter Testing for FB_37 Testing Requirements for Third Parties Tariff Model Resource

Support of Aggregate References Sub-LAP (associated with parent LAP) ApnodeType=LAP(Load Aggregation Point) as a child of aggregateNodeRef LAP Load Aggregation Point AnodeType=ALR(Aggregate Load Resource) LCA - Load Capacity Area ApnodeType=CA(Control Area) planning bus ApnodeType=BUS market operations bus ApnodeType=BUS

CIM UML Model of Aggregates class Aggregate... class Aggregate... enumeration MktDomain:: AnodeType class AggregateNode class AggregateNode MktDomain:: AnodeType +RTO MktOrganisation RTO 1 SYS RUC LFZ REG AGR POD ALR LTAC ACA ASR ECA RTO +RTO 0..1 RUCZone RUCZone +RTO 1 +AggregateNode 0..* IdentifiedObject LoadAggregationPoint LoadAggregationPoint AggregateNode AggregateNode + anodeType: AnodeType [0..1] + endEffectiveDate: DateTime [0..1] + qualifASOrder: Integer [0..1] + startEffectiveDate: DateTime [0..1] MarketRegion MarketRegion 0..1 +AggregateNode class Apnode class Apnode +AggregateNode 0..* 0..* +AggregateNode enumeration MktDomain:: ApnodeType MktDomain:: ApnodeType 0..* +CnodeDistributionFactor IdentifiedObject AG CPZ DPZ TH SYS CA DCA GA GH EHV ZN INT BUS +RegisteredResources +RegisteredResource 0..* CnodeDistributionFactor CnodeDistributionFactor 0..* +Pnode PowerSystemResource MarketCommon:: RegisteredResource +RegisteredResource + factor: Float [0..1] + podLossFactor: Float [0..1] IdentifiedObject Pnode +Pnode MarketCommon:: RegisteredResource Pnode 0..* 0..* 0..1 +Pnodes 0..* 0..* +CnodeDistributionFactor +MktConnectivityNode RegisteredGenerator RegisteredGenerator RegisteredLoad RegisteredLoad AggregatedPnode AggregatedPnode +MktConnectivityNode 1 0..* ConnectivityNode MarketOpCommon:: MktConnectivityNode +MktConnectivityNode MarketOpCommon:: MktConnectivityNode IndividualPnode IndividualPnode RegisteredInterTie RegisteredInterTie 0..1 1 +IndividualPnode +MktConnectivityNode 0..1

espiderived.xsd extension of UsagePoint

Sample XML <?xml version="1.0" encoding="UTF-8"?> <UsagePoint xmlns="http://naesb.org/espi" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://naesb.org/espi espiDerived.xsd"> <ServiceCategory> <kind>1</kind> </ServiceCategory> <pnodeRefs> <pnodeRef> <apnodeType>BUS</apnodeType> <ref>reference to a bus</ref> </pnodeRef> </pnodeRefs> <aggregateNodeRefs> <aggregateNodeRef> <anodeType>ALR</anodeType> <ref>reference to an aggregate load resource</ref> <pnodeRef> A pnode that is a bus reference A LAP Aggregate with a SUB-LAP pnode reference <apnodeType>LAP</apnodeType> <ref>reference to an sub aggregated load</ref> </pnodeRef> </aggregateNodeRef> </aggregateNodeRefs> </UsagePoint>

Pnodes and AggregateNodes <pnodeRefs> <pnodeRef> <apnodeType>LAP</apnodeType> <ref>https://fubar.com/espi/1_1/resources/pnodes/aggregatePnodes/12345656</ref> </pnodeRef> </pnodeRefs> <aggregateNodeRefs> <aggregateNodeRef> <anodeType>SYS</anodeType> <ref>https://fubar.com/espi/1_1/resources/aggregateNodes/LoadAggregationPoints/2468ef2</ref> </aggregateNodeRef> </aggregateNodeRefs>

Some DC Procedures PGE: http://www.pge.com/en/myhome/addservices/sh aremydata/authorized/api/testing/index.page? http://www.pge.com/en/myhome/addservices/sh aremydata/authorized/getstarted/index.page? <<need to collect from SDG&E, SCE, and LondonHydro>>

Pnode/AggregationPoints from CIM Model class AggregateNode class AggregateNode +RTO MktOrganisation RTO 1 RTO +RTO 0..1 RUCZone RUCZone +RTO 1 +AggregateNode 0..* IdentifiedObject LoadAggregationPoint LoadAggregationPoint AggregateNode AggregateNode + anodeType: AnodeType [0..1] + endEffectiveDate: DateTime [0..1] + qualifASOrder: Integer [0..1] + startEffectiveDate: DateTime [0..1] MarketRegion MarketRegion 0..1 +AggregateNode +AggregateNode 0..* 0..* +AggregateNode 0..* +CnodeDistributionFactor IdentifiedObject +RegisteredResources +RegisteredResource 0..* CnodeDistributionFactor CnodeDistributionFactor 0..* +Pnode PowerSystemResource MarketCommon:: RegisteredResource +RegisteredResource + factor: Float [0..1] + podLossFactor: Float [0..1] IdentifiedObject Pnode +Pnode MarketCommon:: RegisteredResource Pnode 0..* 0..* 0..1 +Pnodes 0..* 0..* +CnodeDistributionFactor +MktConnectivityNode RegisteredGenerator RegisteredGenerator RegisteredLoad RegisteredLoad AggregatedPnode AggregatedPnode +MktConnectivityNode 1 0..* ConnectivityNode MarketOpCommon:: MktConnectivityNode +MktConnectivityNode MarketOpCommon:: MktConnectivityNode IndividualPnode IndividualPnode RegisteredInterTie RegisteredInterTie 0..1 1 +IndividualPnode +MktConnectivityNode 0..1

UsagePoint Associations that will add the needed elements class CustomersOverview class CustomersOverview IdentifiedObject Metering::UsagePoint Metering::UsagePoint + isSdp: Boolean [0..1] + isVirtual: Boolean [0..1] + phaseCode: PhaseCode [0..1] + grounded: Boolean [0..1] + servicePriority: String [0..1] + serviceDeliveryRemark: String [0..1] + estimatedLoad: CurrentFlow [0..1] + checkBilling: Boolean [0..1] + ratedCurrent: CurrentFlow [0..1] + nominalServiceVoltage: Voltage [0..1] + ratedPower: ActivePower [0..1] + outageRegion: String [0..1] + readCycle: String [0..1] + readRoute: String [0..1] + amiBillingReady: AmiBillingReadyKind [0..1] + connectionState: UsagePointConnectedKind [0..1] + minimalUsageExpected: Boolean [0..1] enumeration MktDomain:: AnodeType MktDomain:: AnodeType SYS RUC LFZ REG AGR POD ALR LTAC ACA ASR ECA 0..* 0..* +UsagePoints +UsagePoints +AggregateNodes 0..* +Pnode 0..1 IdentifiedObject IdentifiedObject ReferenceData::AggregateNode ReferenceData::AggregateNode ReferenceData::Pnode ReferenceData::Pnode +Pnode +AggregateNode + anodeType: AnodeType [0..1] + endEffectiveDate: DateTime [0..1] + qualifASOrder: Integer [0..1] + startEffectiveDate: DateTime [0..1] + endEffectiveDate: DateTime [0..1] + isPublic: Boolean [0..1] + startEffectiveDate: DateTime [0..1] 0..* 0..*

AnodeTypes for Aggregate Nodes - SYS - System Zone/Region; - RUC - Reliability Unit Commitment Zone; A specialized class of type AggregatedNode type. Defines RUC Zones. A forecast region represents a collection of Nodes for which the Market operator has developed sufficient historical demand and relevant weather data to perform a demand forecast for such area. The Market Operator may further adjust this forecast to ensure that the Reliability Unit Commitment produces adequate local capacity procurement. - LFZ - Load Forecast Zone; - REG - Market Energy/Ancillary Service Region; - AGR - Aggregate Generation Resource; - POD - Point of Delivery; - ALR - Aggregate Load Resource; - LTAC - Load Transmission Access Charge (TAC) Group; - ACA - Adjacent Control Area - ASR - Aggregated System Resource - ECA - Embedded Control Area LoadAggregatinPoint (ALR?), SubLoadAggregationPoint (ECA?), ICAP or LocalCapacityArea (SYS?) are in this list or need to be explicitly added.

Resulting XML Schema For UsagePoint Enhancements XML XMLSchema (at end of UsagePoint)

RetailCustomer Model Identities for Rule 24 class RetailCustomer class RetailCustomer class RetailCustomer class RetailCustomer Enumeration PaymentMetering: :SupplierKind PaymentMetering: :SupplierKind PaymentMetering::ServiceSupplier PaymentMetering::ServiceSupplier + kind: SupplierKind [0..1] + issuerIdentificationNumber: String [0..1] utility retailer other lse mdma msp Meter Multipliers class RetailCustomer class RetailCustomer class RetailCustomer class RetailCustomer Enumeration Metering:: MeterMultiplierKind Metering:: MeterMultiplierKind +Meter Metering::Meter Metering::Meter kH kR kE ctRatio ptRatio transformerRatio + formNumber: String [0..1] Metering::MeterMultiplier Metering::MeterMultiplier 0..1 0..* + kind: MeterMultiplierKind [0..1] + value: Float [0..1] +MeterMultipliers

Retail Customer class RetailCustomer class RetailCustomer IdentifiedObject Common:: OrganisationRole IdentifiedObject IdentifiedObject Common:: OrganisationRole +Roles Common::Document Common::Document Common::Organisation Common::Organisation +Organisation 0..* + type: String [0..1] + authorName: String [0..1] + createdDateTime: DateTime [0..1] + lastModifiedDateTime: DateTime [0..1] + revisionNumber: String [0..1] + electronicAddress: ElectronicAddress [0..1] + subject: String [0..1] + title: String [0..1] + docStatus: Status [0..1] + status: Status [0..1] + comment: String [0..1] + streetAddress: StreetAddress [0..1] + postalAddress: StreetAddress [0..1] + phone1: TelephoneNumber [0..1] + phone2: TelephoneNumber [0..1] + electronicAddress: ElectronicAddress [0..1] 0..1 Common::Agreement Common::Agreement PaymentMetering::ServiceSupplier PaymentMetering::ServiceSupplier + signDate: Date [0..1] + validityInterval: DateTimeInterval [0..1] + kind: SupplierKind [0..1] + issuerIdentificationNumber: String [0..1] Customers:: CustomerAccount Customers:: CustomerAccount Customers::Customer Customers::Customer Customers:: CustomerAgreement Customers:: CustomerAgreement + kind: CustomerKind [0..1] + specialNeed: String [0..1] + pucNumber: String [0..1] + status: Status [0..1] + priority: Priority [0..1] + locale: String [0..1] deprecated + vip: Boolean [0..1] + billingCycle: String [0..1] + budgetBill: String [0..1] + lastBillAmount: Money [0..1] + loadMgmt: String [0..1] + isPrePay: Boolean [0..1] + shutOffDateTime: DateTime [0..1] +CustomerAgreements 0..* +CustomerAgreements 0..* +PricingStructures0..* +DemandResponsePrograms 0..* Customers:: PricingStructure Customers:: PricingStructure Metering::DemandResponseProgram Metering::DemandResponseProgram IdentifiedObject Common::Location Common::Location + type: String [0..1] + mainAddress: StreetAddress [0..1] + secondaryAddress: StreetAddress [0..1] + phone1: TelephoneNumber [0..1] + phone2: TelephoneNumber [0..1] + electronicAddress: ElectronicAddress [0..1] + geoInfoReference: String [0..1] + direction: String [0..1] + status: Status [0..1] IdentifiedObject Assets::Asset Assets::Asset + type: String [0..1] + utcNumber: String [0..1] + serialNumber: String [0..1] + lotNumber: String [0..1] + purchasePrice: Money [0..1] + critical: Boolean [0..1] + electronicAddress: ElectronicAddress [0..1] + lifecycle: LifecycleDate [0..1] + acceptanceTest: AcceptanceTest [0..1] + initialCondition: String [0..1] + initialLossOfLife: PerCent [0..1] + status: Status [0..1] Work:: Work:: WorkLocation WorkLocation Assets:: AssetContainer Assets:: AssetContainer Customers::ServiceLocation Customers::ServiceLocation + accessMethod: String [0..1] + siteAccessProblem: String [0..1] + needsInspection: Boolean [0..1] +ServiceLocation 0..1 +UsagePoints Metering:: UsagePoint Metering:: UsagePoint 0..* Metering::EndDevice Metering::EndDevice + isVirtual: Boolean [0..1] + isPan: Boolean [0..1] + installCode: String [0..1] + amrSystem: String [0..1] Metering::Meter Metering::Meter +Meter +MeterMultipliers + formNumber: String [0..1] Metering::MeterMultiplier Metering::MeterMultiplier 0..1 0..* + kind: MeterMultiplierKind [0..1] + value: Float [0..1]

class RetailCustomer class RetailCustomer Minor Classes and Enums Compound Common::Status Enumeration Compound Common::TownDetail Common::Status Customers::CustomerKind Customers::CustomerKind Common::TownDetail + value: String [0..1] + dateTime: DateTime [0..1] + remark: String [0..1] + reason: String [0..1] residential residentialAndCommercial residentialAndStreetlight residentialStreetlightOthers residentialFarmService commercialIndustrial pumpingLoad windMachine energyServiceSupplier energyServiceScheduler internalUse other + code: String [0..1] + section: String [0..1] + name: String [0..1] + stateOrProvince: String [0..1] + country: String [0..1] Compound Common::Priority Compound Common::Priority Common::StreetDetail Common::StreetDetail + rank: Integer [0..1] + type: String [0..1] + justification: String [0..1] + number: String [0..1] + name: String [0..1] + suffix: String [0..1] + prefix: String [0..1] + type: String [0..1] + code: String [0..1] + buildingName: String [0..1] + suiteNumber: String [0..1] + addressGeneral: String [0..1] + addressGeneral2: String [0..1] + addressGeneral3: String [0..1] + withinTownLimits: Boolean [0..1] Enumeration PaymentMetering: :SupplierKind PaymentMetering: :SupplierKind utility retailer other lse mdma msp Compound Assets::AcceptanceTest Assets::AcceptanceTest + type: String [0..1] + success: Boolean [0..1] + dateTime: DateTime [0..1] Compound Enumeration Metering:: MeterMultiplierKind Common::TelephoneNumber Common::TelephoneNumber Metering:: MeterMultiplierKind Compound Assets::LifecycleDate Assets::LifecycleDate + countryCode: String [0..1] + areaCode: String [0..1] + cityCode: String [0..1] + localNumber: String [0..1] + extension: String [0..1] + dialOut: String [0..1] + internationalPrefix: String [0..1] + ituPhone: String [0..1] kH kR kE ctRatio ptRatio transformerRatio + manufacturedDate: Date [0..1] + purchaseDate: Date [0..1] + receivedDate: Date [0..1] + installationDate: Date [0..1] + removalDate: Date [0..1] + retiredDate: Date [0..1] Compound Compound Common:: ElectronicAddress Common::StreetAddress Common::StreetAddress Common:: ElectronicAddress + streetDetail: StreetDetail [0..1] + townDetail: TownDetail [0..1] + status: Status [0..1] + postalCode: String [0..1] + poBox: String [0..1] + lan: String [0..1] + mac: String [0..1] + email1: String [0..1] + email2: String [0..1] + web: String [0..1] + radio: String [0..1] + userID: String [0..1] + password: String [0..1]

espiderived: UsagePoint current Extends UsagePoint based on newer CIM model: iec61970cim17v06a_iec61968cim 12v10_iec62325cim03v02 Backwards compatibility assured by adding new elements to end of list.

billLastPeriod billLastPeriod The total bill for the billing period billLastPeriod = costAdditionalDetailLastPeriod.LineItem.amount costAdditionalLastPeriod Deprecate and if present, should have the same value of billLastPeriod if you populate the costAdditionalDetailLastPeriod, then costAdditionalLastPeriod would be expected to have the total IntervalReading.cost Provided if FB_12 is selected and should probably be consistent with costAdditionalDetailLastPeriod.LineItem.amount records for which these costs pertain but this is not guaranteed billLastPeriod = costAdditionalDetailLastPeriod.LineItem.amount Should always add up to billLastPeriod. If the details provided are not complete, a record other should be included to make up the difference and indicate that all billing details have not been provided. If no amounts are presented in this detail, there is no need for a compensating other record to add up to billLastPeriod

Query Parameters There was a significant discussion, led by Partha, about how the depth query parameter should work. During the call we accessed the Implementation Agreement and discovered the only documentation of the query parameters is a list of the query parameter keywords. The group agreed we need to document how the parameters work and the expected format they should contain. For example, the date query parameters (published-min, published-max, updated-min, and updated-max) need to indicate they are to be UTC Z time formats and not epoch time. As a result of the two above items, additional test need to be added to FB_37 to: Ensure query elements containing epoch time generate a 400 response Ensure query elements containing ALL generate a 400 response Ensure responses match requested max & depth values

Topics Value mapping for TOU and CPP and ConsumptionTier sftp for Batch/Bulk/{bulkId} Is there a user ? sftp://user@localhost/DataCustodian/espi/1_1/resource/Batch/Bulk/{bulkId} Suggestion fixed user= GreenButton so no PII in sftp startup Alternative let DC provide arbitrary uuid in the notification Conclusion: the DC chooses the user and includes it in the notificationUri where the TP gets it for use in the exchange. Target Firm Up end of July: Retailcustomer.xsd Need to define function blocks -- Potentials: FB_X1 Minimal that only provides actual IDs and UsagePoints FB_X2 Service Location Contents Name and Addresses and location, No fb needed now End device No fb needed now Pricing Structure FB_X3 Account data for DMD access Access Tokens Access tokens to access? Individual with access_token, bulk with client_access_token URI in Authorization customerResourceUri needed in OAuth authorization response and Authorization xml structure customerResourceUri in client access Authorization would be batch/BulkRetailCustomerInfo Test requirements If Scope has RetailCustomer function blocks, then Verify Authorization has customerResourceUri Verify Oauth response has customerResourceUri Verify client_access_token works for esource/Batch/BulkRetailCustomerInfo Verify access_token works for resource/RetailCustomer Additional attributes Move in move out use CustomerAgreement.validityInterval Target Firm Up List end of July: UsageSummary.CostAdditionalDetail.itemKind Tax, Other, ThirdParty energy provider fee, ThirdParty energy provider usage, Credit, Discount, Usage, Demand, TOU, incentive, informational, Customer Charge, Energy Charges, Supply Charges, Distribution Charges, Transmission Charges, Generation Charges, State Gross Receipts Tax, State Tax Adjustment, Administrative Charge, Ancillary Charge, Balancing Service Charge, Working Capital Charge, Purchased Generation Adjustment, Cost Adjustment, Service Location Distribution Charge, Other, Minimum charge, Tier Charge, Adjustment Charge, Program Charge/Credit, Amount Paid, Power Factor adjustment, DWR energy credit (calculation and credit value), UUT exemption status, State Tax, Local Tax, Transmission Charges, Distribution Charges, Nuclear Decommissioning Charges, Public Purpose Programs Charges, Franchise Fee, Generation Charge Will finish consolidation of list and review OAuth login requirements for the testing

ItemKind Simplified 1 2 3 Energy Generation Fee. A charge for generation of energy. Energy Delivery Fee. A charge for delivery of energy. Energy Usage Fee. A charge for electricity, natural gas, water consumption Administrative Fee. A fee for administrative services. Tax. A local, state, or federal energy tax. Energy Generation Credit. A credit, discount or rebate for generation of energy. Energy Delivery Credit. A credit, discount or rebate for delivery of energy. Administrative Credit. A credit, discount or rebate for administrative services. Payment. A payment for a previous billing. Information. An informational line item. 4 5 6 7 8 9 10

TOU, CPP, ConsumptionTier Code Descriptions TOU, CPP, ConsumptionTier are integers in ReadingType/IntervalReading What does 3 mean? Draft Solution: Provide an optional table in UsagePoint that provides the code, name, and description of the values of TOU and CPP when used underneath it.

UsagePoint.ProgramMappings <UsagePoint> </UsagePoint> <ServiceCategory> <kind>1</kind> </ServiceCategory> <programIdMappings> <programIdMapping> </programIdMapping> <programIdMapping> </programIdMapping> </programIdMappings> <tOUorCPPorConsumptionTier>tou</tOUorCPPorConsumptionTier> <code>1</code> <name>Summer Peak</name> <tOUorCPPorConsumptionTier>tou</tOUorCPPorConsumptionTier> <code>2</code> <name>Winter Peak</name>

RetailCustomer Architecture API GET .../resource/Batch/RetailCustomer/{id} GET .../resource/CustomerInformation/{id} GET .../resource/CustomerInformation/{id}/RetailCustomer/{id}/CustomerAccount/{id}/CustomerAgreement GET /resource/Customer/{id} GET .../resource/CustomerAgreement/{id} GET .../resource/Batch/BulkRetailCustomerInfo/{id} PG&E proposal Current Architecture

Large Organization Use Case Corporate Authorizes EMS Co Resource Example EMS Co Web Account Safeway Company Customer SF Regional Mgr, Oakland RM Customer Account Individual Stores Service Agreement Gas service, Electrical service Service Point Usage Points There is sometimes an authority that can authorize a large number of individual accounts, e.g. gsa/McDonalds, where the individual accounts may be franchised or otherwise owned/managed yet the individual accounts have the responsibility to maintain the utility account and pay the bills.

Query Parameters There was a significant discussion, led by Partha, about how the depth query parameter should work. During the call we accessed the Implementation Agreement and discovered the only documentation of the query parameters is a list of the query parameter keywords. The group agreed we need to document how the parameters work and the expected format they should contain. For example, the date query parameters (published-min, published-max, updated-min, and updated-max) need to indicate they are to be UTC Z time formats and not epoch time. As a result of the two above items, additional test need to be added to FB_37 to: Ensure query elements containing epoch time generate a 400 response Ensure query elements containing ALL generate a 400 response Ensure responses match requested max & depth values Jerry Yip has some additional itemKind elements he wants to discuss during next week s OpenADE Task Force call, which he will provide in a follow up e-mail. Jerald Pinnecker wants to discuss subscriptions during next week s OpenADE Task Force call. Presently they send subscription data to a Third Party when they register and he wants to know how that data is then tied to the access token when the Third Party completes the authorization request. Additionally, he wants to know who the Third Party is supposed to use the access token.

OAuth Authorization Failure Mode Usage Scenario: 1. TP redirect user to DC scope selection. 2. User approves TP and scope. 3. DC redirects user to TP with scope parameter. 4. TP redirects users to DC's OAuth /authorize endpoint with scope and client_id parameters. 5. DC redirects back to TP redirect_uri with OAuth code parameter. 6. TP makes a request to DC's OAuth /token endpoint with the code. 7. DC responds with an access_token and refresh_token. 8. TP's server crashes and doesn't save either token. How is the TP supposed to get new tokens? In normal OAuth, you simply redirect the user back to the OAuth /authorize endpoint, the user approves access again and gets redirected back with a new code. However, at least in one current implementation, the TP has to redirect the user to the scope selection screen, where the user will be told that they have already authorized the TP with no option to re-authorize. In order to get new tokens, the use manually has to cancel authorization, which causes them to get redirected to the main website. Then the user manually has to go back to the scope selection screen and authorize the TP again. This re-authorization process is not ideal because it requires us training the user to cancel-then-manually-go-back- and-reauthorize, which is a very confusing and complex process and doesn't redirect the user back to the TP after cancellation. Two possible solutions: 1. On the DC's scope selection interface, have a re-authorize button if the user has already authorized the TP. 2. Allow TP's to redirect the user to OAuth's /authorize endpoint with the same scope, and have the DC ask for re-authorization at that point. Option 1 is better for GBCMD, in my opinion, because it also allows for the scenario where the TP loses the scope parameter, too. Option 2 is the more technically correct OAuth procedure. All other OAuth services I can think of do Option 2, but they also don't require a pre-defined scope parameter for the /authorize endpoint (so there's nothing to lose).

GET Subscription w/wo query parameters Default required behaviors Problem: The amount of data that is in a: GET /Batch/Subscription/{subscriptionId} can potentially be very large. What is the obligation of a DC when that message is received without query parameters? What about the desire of some DC s to provide only a fixed size response of say X months? What about when a subscription contains 1/10/1000 UsagePoints? Alternatives 1) Requires date range in GET /Batch/Subscription/{subscriptionId} DC responds with 202 if data is too large to return right away Returns with notification when data is ready and can provide query distinguished URIs 2) DC decides maximum depth to return when no query parameters TP may get whole history (from scope parameter HistoryLength) or may get less. 3) Term in Scope for default GET Subscription depth The scope can indicate for the specific subscription what the default length is. The DC decides during scope selection what to include in the offered scopes. Solution: Publish min/max required on resource/Batch/XXXXX APIs

Discussion of responses to requests for large data sets Given: It's possible for a subscription to have small or enormous at data sets There GB CMD applications on the market that don't require query parameters Query parameters are specified and the Min and Max public support required for our minimum set If you have or don't have query parameters the third party is likely always to ask the first time for everything We agreed in a face-to-face that we were going to support a response of 202 when large off-line data sets are requested In a response asking for everything it should be the discretion of the data custodian to determine what the largest response it's willing to give Some data custodians want to define a fixed maximum size for any request An empty response (feed with no resources) implies no more data Therefore: Query parameters should remain optional in any given request Absence of query parameters means everything this means all available data that DC is willing to provide 202 is a valid response for ./Batch/ followed by a notification when data is ready The DC decides how much a maximum data response to an API request will be A TP that receives less than anticipated can ask for older data. If he gets back an empty feed, he has it all. Note: that if there is a gap in the data and he asks for the gap, he may get empty feed but there may be more data behind it.

CIM Tariff Model class TariffProfile class TariffProfile Document Customers:: PricingStructure Customers:: PricingStructure +PricingStructures 0..* +Tariffs 0..* Document Customers:: Tariff IdentifiedObject Metering:: ReadingType Customers:: Tariff Metering:: ReadingType Charges associated with time threshholds Charges associated with value threshholds +Tariffs 0..* +ReadingType 0..1 +TariffProfiles 0..* Document +TariffProfiles +TariffProfiles TariffProfile TariffProfile 0..* 0..* + tariffCycle: String [0..1] +ConsumptionTariffIntervals +TimeTariffIntervals +ConsumptionTariffIntervals 0..* 0..* 0..* TimeTariffInterval TimeTariffInterval ConsumptionTariffInterval ConsumptionTariffInterval +TouTariffIntervals +ConsumptionTariffIntervals + sequenceNumber: Integer [0..1] + startTime: Time [0..1] + sequenceNumber: Integer [0..1] + startValue: Float [0..1] 0..* 0..* 0..* 0..* +TimeTariffIntervals +ConsumptionTariffIntervals Compound AccountingUnit IdentifiedObject Charge AccountingUnit Charge +Charges +Charges + value: Float [0..1] + energyUnit: RealEnergy [0..1] + monetaryUnit: Currency [0..1] + multiplier: UnitMultiplier [0..1] + kind: ChargeKind [0..1] + fixedPortion: AccountingUnit [0..1] + variablePortion: PerCent [0..1] 0..* 0..* +ParentCharge 0..1 +ChildCharges 0..*

Additional Information for UsageSummary.CostAdditionalDetail Add an enumeration tag to lineitem to indicate what kind of charge it is itemKind Tax TOU Demand ThirdParty energy provider fee ThirdParty energy provider usage

Solutions to Add Customer Account Numbers Make non- obfuscatedId Add link Extend each Class with IdentifiedObject.name Add Atom Extension

Account/Agreement Topology

Separation of PII containing Resource RetailCustomer from Subscription* PII Containing information Anononymous EUI Subscription Customer CustomerAccount UsagePoint Customer Agreement Normal ESPI Resources ServiceLocation PostionPoint Key Authorization ServiceSupplier New Resource EndDeviceAsset PricingStructure Existing Resource *This data structure is to be developed on an aggressive schedule based on HelpDesk issue #83 and PAP10 NAESB Std REQ.18. No single API request can retrieve both PII and Anonymous data Non-Resource Class

class CustomerProfile class CustomerProfile OrganisationRole Customers::Customer Need to determine which are IdentifiedObjects -> resources {root} Model + kind: CustomerKind [0..1] + specialNeed: String [0..1] + pucNumber: String [0..1] + status: Status [0..1] + priority: Priority [0..1] + locale: String [0..1] ::IdentifiedObject + description: String [0..1] + mRID: String [0..1] + name: String [0..1] Document Customers::CustomerAccount + billingCycle: String [0..1] + budgetBill: String [0..1] ::Document + createdDateTime: DateTime [0..1] + lastModifiedDateTime: DateTime [0..1] + revisionNumber: String [0..1] + status: Status [0..1] ::IdentifiedObject + description: String [0..1] + mRID: String [0..1] + name: String [0..1] +CustomerAgreements +Customer Agreement +CustomerAccounts Customers::CustomerAgreement 1 0..* + loadMgmt: String [0..1] ::Agreement + signDate: Date [0..1] + validityInterval: DateTimeInterval [0..1] ::Document + createdDateTime: DateTime [0..1] + lastModifiedDateTime: DateTime [0..1] + revisionNumber: String [0..1] + status: Status [0..1] ::IdentifiedObject + description: String [0..1] + mRID: String [0..1] + name: String [0..1] UsagePoints of RetailCustomer Location of premise Account ID Sub Account (SA) ID Service Agreement / Account is name depending on utility Customer name, nickname (or short name) Address and info SDG&E provides only email address and UPID correspondence csv email and UsagePoint ID (Customer Obfuscated Key) MeterID ServicePointId Pnode LoadAggregationPoint, SubloadAggregationPoint Climate zone Account open date Account close date SA Open and Close date MDM Agent Id (who does meter read) ServiceSupplierId EnergyServiceProviderId (may be same as service supplier) Demand Response Provider May need list of Ids for service providers rather than explicit?? (0..* relationship{role, href}) Related assets ???? For example pool pump and pool pump participation in a program. Related programs ???? deprecated + vip: Boolean [0..1] +CustomerAccount 1 0..* +CustomerAgreements +CustomerAgreements +CustomerAgreements 0..* +CustomerAgreements 0..* 0..* 0..* WorkLocation Customers::ServiceLocation Customers::ServiceLocation Common:: PositionPoint Common:: PositionPoint + accessMethod: String [0..1] + siteAccessProblem: String [0..1] + needsInspection: Boolean [0..1] ::Location + type: String [0..1] + mainAddress: StreetAddress [0..1] + secondaryAddress: StreetAddress [0..1] + phone1: TelephoneNumber [0..1] + phone2: TelephoneNumber [0..1] + electronicAddress: ElectronicAddress [0..1] + geoInfoReference: String [0..1] + direction: String [0..1] + status: Status [0..1] ::IdentifiedObject + description: String [0..1] + mRID: String [0..1] + name: String [0..1] +PositionPoint + xPosition: String [0..1] + yPosition: String [0..1] + zPosition: String [0..1] 0..1 +ServiceLocation +ServiceLocations 0..1 0..* +ServiceLocation 0..1 Metering:: UsagePoint Metering:: UsagePoint +UsagePoints 0..* +ServiceLocation 0..1 AssetContainer Metering::EndDevice Metering::EndDevice +EndDevices PaymentMetering::ServiceSupplier +ServiceSupplier + isVirtual: Boolean [0..1] + isPan: Boolean [0..1] + installCode: String [0..1] + amrSystem: String [0..1] ::Asset + type: String [0..1] + utcNumber: String [0..1] + serialNumber: String [0..1] + lotNumber: String [0..1] + purchasePrice: Money [0..1] + critical: Boolean [0..1] + electronicAddress: ElectronicAddress [0..1] + lifecycle: LifecycleDate [0..1] + initialCondition: String [0..1] + initialLossOfLife: PerCent [0..1] + status: Status [0..1] ::IdentifiedObject + description: String [0..1] + mRID: String [0..1] + name: String [0..1] + kind: SupplierKind [0..1] + issuerIdentificationNumber: String [0..1] 0..* 1 Metering::DemandResponseProgram Metering::DemandResponseProgram +DemandResponsePrograms + type: String [0..1] + validityInterval: DateTimeInterval [0..1] 0..* Customers:: PricingStructure Customers:: PricingStructure +PricingStructures 0..* + code: String [0..1]

Weekly OpenADE Meeting Notes - March 7, 2017

Download Presentation

Presentation Transcript

Related

More Related Content
