LECTURE # 05
TRAFFIC TURNING
TENDENCY SURVEY
TRANSPORTATION SURVEYS
These are conducted to record existing traffic movements with
in the study area and to collect the data about the factors
affecting these movements.
Transportation surveys include assessment of general traffic
characteristics such as existing traffic volumes, parking studies
including the provision of both on street parking and off- street
parking facilities and public transport facility.
Transportation surveys include some basic surveys to get the
required information such as
Traffic turning tendency
Traffic speed Survey
Parking Survey
Origin and destination Survey
Travel Behaviour Survey
Pedestrian Survey
Noise level survey
Trip Generation Survey
Air pollution Surveys
Household Survey related to transportation.
C
ONT
..
TRAFFIC TURNING
TENDENCY
One of the fundamental measures of traffic on a road system
is the volume of traffic on the road in a given interval of time.
It is also termed as flow and it is expressed in vehicles per
hour or vehicles par day.
When the traffic is composed of a number of types of
vehicles, it is the normal practice to convert the flow into
equivalent Passenger Car Unit (PCUs), by using certain
equivalency factors.
The flow is then expressed as PCUs per hour or PCUs per
day.
Knowledge of the vehicular volume using a road network is
important for understanding the efficiency at which the
system works at present and the general quality of service
offered to the road users.
Knowing the flow characteristic, one can easily determine
whether a particular section of the road is handing traffic
much above or below its capacity.
If the traffic is heavy, the road suffers from congestion with
consequent loss in journey speeds.
Lower speed causes economic loss to the community due to
time lost by the occupants of the vehicles and the higher
operational cost of vehicles.
C
ONT
..
C
ONT
..
Congestion also leads to traffic hazards
Volume counts are, therefore, indicators of the need to
improve the transport facilities and are a valuable tool in the
hands of a transport planner.
They enable him to draw up schemes for improvement of
roads based on a system of relative priorities and to allocate
the scarce economic resources most advantageously.
They provide an equitable basis for the selection of pavement,
shoulder and bridge widths.
TRAFFIC COUNTS
The may be classified into various types such as.
Sort-term counts, say, for one hour two hours
Counts for a full day
Counts for a full week
Continuous counts
DATA COLLECTION
Before going to the field, the observer should know how the
data is going to be used.
The following procedure assumes the observer is gathering
data to identify the peak-hour traffic volume and how it
varies at the peak-hour period.
1.
V
ISIT
THE
SITE
AND
CHOOSE
A
LOCATION
AND
TIME
TO
COLLECT
THE
DATA
It is important to visit the site at, or near the time of day when
data will be collected.
If the purpose is to determine the peak-hour or any other
traffic at the intersection, the observer should start at least one
hour before the projected peak hour and continue for one hour
after the projected peak hour.
It is unusual for traffic volumes to be affected by the presence
of people counting traffic, so the observer should be placed at
such a point that gives a clear view of the intersection and all
of its approaches.
If video cameras are used, the equipment should be placed
where turning vehicles do not block the view of the road.
2.
S
ELECT
T
HE
N
UMBER
O
F
O
BSERVERS
R
EQUIRED
F
OR
T
HE
D
ATA
C
OLLECTION
C
AREFULLY
.
The numbers of observers needed to count the vehicles
depends upon the number of lanes in the highway on which
the count is to be taken and the type of information desired.
It is desirable to record traffic in each direction of travel
separately and post separate observers desirable to record
traffic in each direction of travel separately and post separate
observers for each direction.
3.
C
OLLECT
A
ND
R
ECORD
T
HE
D
ATA
Data is observed in fifteen-minute increments throughout the
count period usually three hours.
Before starting, the times marking the beginning of each
fifteen minute observation period are recorded.
Then the watch is started, and the volume count beings.
During each time period, the approach that each vehicle used
to enter the intersection is recorded as well as whether it
turned left, right or continued straight when exiting the
intersection.
4.
C
HECK
YOUR
WORK
BEFORE
LEAVING
THE
FIELD
Before leaving the field, the data sheets should be checked to
see that they are complete.
Items such as weather, location, street names, observer names,
and the like should be verified.
Any unusual observation should be listed as comments.
Other than note-taking materials and a watch, no special
equipment is required for this survey.
A calculator or laptop computer can be programmed to ease
the counting task.
DATA ANALYSIS
Check the data.
Even though the data is checked for completeness prior to
leaving the field, it is wise to check each field data sheet
again at the office prior to analysis.
Summarize the field sheets.
The field sheet is summarized on the Turning Movement
Counts Summary sheet.
Prepare a graphical summary.
While a tabular summary is useful, a graphical summary
presents information that can be more easily
comprehended.
The number of vehicles that were observed executing a
particular move appears in the appropriate box.
These values are than summed to show the directional
volume for each of roadways.
A check of the entries can be made by summing all of the
values for vehicles entering the intersection and comparing
it to the sum of the values for vehicles exiting the
intersection.
C
ONT
..
Interpret the data and draw conclusions.
Interpretation of volume data depends on the use for which
the count was conducted. Among the question to be
addressed are;
Is the traffic evenly distributed among all the approaches to
the intersection?
Does the peak-hour factor indicate that a rush of traffic is
arriving at the intersection during a particular time frame,
or is the traffic spread out evenly over the peak hour?
Are there heavy turning volumes?
At intersections without signals, is the volume of traffic
moving through the intersection limited because of delays
caused by sign interpretation?
C
ONT
..
C
ONT
..
While some of these questions may lead to useful
conclusions, volume data alone cannot answer all the
questions that may arise about an intersection.
Additional information such as signal timing, pedestrian flow
and volume distribution throughout the remainder of the day
may be needed to complete the traffic engineering analysis.
