The Food-Energy-Water Nexus and Climate Change Impacts
CLEWS Country Module
1. The food-energy-water nexus and sustainable development
2. The need for integrated planning: case studies
3. The CLEWS modelling approach
4. CLEWS case studies
5. Hands-on exercises with CLEWS
3. The CLEWS modelling approach
CLEWS
•
Energy for fertilizer production
•
Energy required for field
preparation and harvest
•
Biomass for biofuel production
and other energy uses
Climate
Greenhouse
gas emissions
Precipitation
temperature
•
Water for biofuel crops (rain-fed and
irrigated)
•
Water needs for food, feed and fibre
crops (rain-fed and irrigated)
•
Energy for water processing and treatment
•
Energy for water pumping
•
Energy for desalination
•
Water available for hydropower
•
Water for power plant cooling
•
Water for (bio-) fuel processing
Quantifies
the
food-
energy-
water
nexus
Adding climate allows
assessment of policy
robustness to climate change
Residential
Electricity and
heat
25.3%
Other
en
ergy
9.9%
Industry
18.1%
Waste
2.9%
Transport
14.2%
6.5%
Agriculture,
forestry
and other land use
23.1%
Global emissions by sector
Greenhouse gas emissions and
the food-energy-water nexus
Greenhouse gas emissions
from electricity generation
Climate change and the food-energy-water nexus
Climate change is often said to “manifest through water”
•
More frequent extreme weather events (e.g., more droughts and
floods)
•
Shifting precipitation patterns
•
Potential for major impacts on agriculture
•
Impact on energy infrastructure
•
Sea level rise has dramatic consequences for land use
•
Global mean temperature prospects
CLEWS
•
Time horizon is typically one or more decades
•
Intended for longer term assessments and studies
•
Scenario-based analysis
•
Explores alternatives, risks and uncertainties through scenarios and sensitivity
analysis
•
Assesses the role of technology and technological change
•
Tests policies and measures
•
Flexible
•
Model user chooses system boundaries
•
Model user chooses level of detail
•
Model user chooses geographical coverage
•
Identifying and quantifying
interlinkages among sectors
•
Identifying robust relationships (i.e.,
impacts/relationships that are true
for a wide range of
conditions/assumptions)
•
Identifying key risks
(impacts/relationships that are true
under certain circumstances)
•
Exploring technology and policy
alternatives to
•
Mitigate unwanted outcomes (minimize
impact of trade-offs)
•
Realize co-benefits (maximize synergies)
CLEWs
Implementing a CLEWS assessment
Implementing a CLEWS assessment, cont’d
Examples of modelling tools
CLEWS
Climate
AEZ
Emissions
Integrated
assessment
Water management modelling
W
a
t
e
r
q
u
a
n
t
i
t
y
W
a
t
e
r
q
u
a
l
i
t
y
S
e
a
s
o
n
a
l
i
t
y
o
f
f
l
o
w
R
e
g
u
l
a
t
i
o
n
Water management model: critical questions
•
How to allocate water to competing uses?
•
How to best operate water infrastructure (e.g., dams, diversion works)?
•
How water allocation, operation rules and constraints should adjust to new
management directives?
•
How to jointly manage water for irrigation and energy requirements?
The water model
Required model inputs include:
•
Definition of all catchment areas
•
Real climatic data: rainfall, minimum
and maximum temperature, humidity...
•
All main rivers and reservoirs plus
stream flow data and reservoir levels
•
Modelling of existing
canals/distribution systems
•
Using GIS: land cover classes to
calculate evapotranspiration
•
Water demand data (urban and
agricultural) according to national
statistics and population density
The energy model
Used to represent physical flows, capacities and energy balances through an
energy system
•
Accounting models:
Can be used to assess the impacts of predetermined
pathways for development, e.g., LEAP, MAED
•
Simulation models:
Represent decisions of actors within the system
•
Potential for replacing existing technologies with low-carbon, more efficient or cost
effective alternatives
•
Optimization models:
Can be used to maximize benefits; or minimize
costs,
e.g
. OSeMOSYS, MESSAGE, MARKAL
•
Technology learning rates, resource availability, technical limitations, vintage of
infrastructures, penetration rates, environmental criteria, costs, etc. directly affect
the optimal system design.
Energy system model: critical questions
•
What are the investment requirements in generation and network
infrastructure and their timing to meet electricity demand and when?
•
How can energy security be enhanced?
•
What is the cost of expanding modern energy services?
•
What technologies and fuels grant the lowest cost, most reliable energy
mix?
•
What is the scope for producing biofuels and generating electricity form
large-scale solar photovoltaic parks or wind farms?
•
What are the water requirements—e.g., water for cooling, hydropower,
irrigation of biofuels?
•
What pollutants are emitted and in what quantities?
The land-use model
•
Inputs
•
Climate data
•
Detailed soil map and data from soil profiles
•
Slopes and marginal land
•
GIS data for land cover
•
Irrigated areas
•
Output
•
Grid map showing optimal crops, and
potential water use and yield, plus a crop
calendar
A
E
Z
–
A
G
R
O
-
E
C
O
L
O
G
I
C
A
L
Z
O
N
I
N
G
Agro-ecological modelling
Geospatially based analysis of agricultural
output to assess:
•
What is the potential yield of a range of
crops in each region?
•
What are the water requirements for each
crop in each modelled sector?
•
How do different climate scenarios affect
crop yield?
•
Quantification of input requirements to
achieve a certain level of yield.
Example: rainfall pattern and water demand by crop
Agro-ecological modelling
Climate representation
Climate is defined by the major assumptions in land-use, water
management and energy systems models.
•
Apparent need for consistency—e.g., greenhouse gas emissions limits
versus long-term estimates for air temperature and precipitation
•
Accounting of greenhouse gas emissions
•
Temperature and precipitation affecting agricultural production
•
Solar insolation affecting photovoltaic and concentrated solar power
generation
•
Precipitation affecting hydropower and water irrigation demand,
quantifying seasonality of availability
Interlinkages between effects across sectors are highlighted
Optimization in the integrated CLEWs tool
Representation of the physical system (i.e., “bottom up”)
•
Technologies are described by their technical and economic characteristics
•
Full value chains (e.g., well-to-wheel or field-to-fork)
•
Web of interconnected value chains
•
Meets consumer demands
Balance of supply and demand
•
Clears each commodity market in every value chain
Identifies cost-effective strategies subject to constraints
•
Configures system to find deployment and utilization patterns that meet
demands at lowest possible cost
CLEWS
Inputs
•
Demand curves
•
Technology performance
•
Technology cost (capital, operation
and management)
•
Commodity cost (extraction cost,
import cost)
•
Cost of capital
•
Emissions intensity
•
Constraints (environmental,
regulatory, policy, market, etc. )
Outputs
•
Investment (physical units and cost)
•
Total production capacity
•
Operating costs
•
Asset utilization
•
Output (physical units)
•
Fuel expenditures
•
Emissions
•
Shadow prices
Integrated CLEWS optimization tool
Concluding remarks
•
A flexible modelling tool to quantitatively
assess the food-energy-water nexus in the
context of climate change
•
Integrated entry point to inform
sustainable development policies,
including related to the 2030 Agenda and
Paris Agreement
•
Retains sector relevance while providing an
integrated assessment
•
Can contribute to institutional coordination
for integrated policy formulation
