Strength-Duration Curve in Neuromuscular Stimulation
StudyMafia
.Org
Submitted To:
Submitted By:
Studymafia.org Studymafia.org
Table Contents
•
Definition
•
Introduction
•
Types of S-D Curve
•
Factors affecting the S-D Curve
•
Advantages of S-D Curve
•
Disadvantages of S-D Curve
•
Clinical Significance
•
Conclusion
2
Introduction
–
The strength-duration curve is a graphical
representation of the relationship between the
intensity of an electrical stimulus at the motor
point of a muscle and the length of time taken
to elicit a minimal contraction in that muscle.
–
Here, strength refers to the stimulus intensity
on the vertical axis while duration refers to the
pulse duration on the horizontal axis. It is used
to determine nerve damage in lower motor
neuron lesions.
3
4
Normal Innervation
•
This is also called a "nerve curve". All nerve fibers
supplying the muscle are intact. The shape of the curve is a
continuous rectangular hyperbola.
•
The same intensity is required to produce a response at
longer durations. The intensity increases steadily for
shorter durations. The curve is usually seen rising at the
1ms mark.
●●●
5
Types of Strength-Duration
Curve
Complete Denervation
•
This is also called a "muscle curve". All nerve fibers
supplying the muscle have degenerated. The curve is
characteristically steep and shifted to the right.
•
The intensity keeps increasing when lowering the duration
below 100ms. There is no response seen at very short
durations.
●●●
6
Types of Strength-Duration
Curve
Partial Denervation
•
Some of the nerve fibers supplying the muscles have
degenerated while others are intact. A characteristic
kink is present in the curve.
•
The right side of the curve represents the denervated
part of the muscle while the left side represents the
innervated fibers of the muscle.
●●●
7
Types of Strength-Duration
Curve
Rheobase
•
It is the minimum intensity of current required to stimulate
a muscle at infinite duration. Its normal value ranges
between 2 and 18 mA. The rheobase is greater for
denervated muscles.
Chronaxie
•
It is the minimum time required for a current of double the
intensity of rheobase to stimulate a muscle. Its normal
value is below 1ms. Chronaxie is inversely proportional to
excitability. Thus, its value is greater for denervated
muscles.
8
Types of Strength-Duration
Curve
Factors affecting the
S-D Curve
•
Skin resistance
•
Subcutaneous tissue like fat
•
Temperature
•
Electrode size, material and placement
•
Age of the subject
•
Fatigue
9
Advantages
•
It is quick and easy to perform. It requires
minimal training.
•
It is economical in comparison to other
clinical tests.
10
Disadvantages
•
It only provides qualitative data in relation to
the degree of denervation.
•
It cannot locate the site of the lesion. In large
muscles, only a few fibers can be studied due to
the limits of the method.
11
Clinical Significance
•
It ascertains the excitability of the nerve and thus, can
detect the magnitude of nerve damage. It can show
recovery over a period of time. It is a valuable
diagnostic and prognostic tool. It is usually performed
after 3 weeks of nerve injury to allow for Wallerian
degeneration.
•
The intrarater reliability (r = .541) is lower than
interrater reliability (r = .945), this was attributed to
normal physiological variation in subjects.
12
Conclusion
The strength—duration curve is a property of nodal
membrane and, while it depends on a number of
factors, its measurement may shed light on axonal
properties when taken in conjunction with
measurements of axonal excitability.
13
References
–
Google.com
–
Wikipedia.org
–
Studymafia.org
–
Slidespanda.com
T
h
a
n
k
s
T
o
S
t
u
d
y
M
a
f
i
a
.
o
r
g
The strength-duration curve depicts the relationship between electrical stimulus intensity and time required for minimal muscle contraction. It helps assess nerve damage in lower motor neuron lesions. Various types of curves exist based on innervation status, such as normal innervation, complete denervation, and partial denervation, each with distinct characteristics like curve shape and response patterns. Understanding rheobase and chronaxie values also plays a crucial role in muscle stimulation. This curve aids in clinical diagnostics and treatment planning for neuromuscular disorders.
