Samsung SmartThings Hub and Zigbee/Zwave Networks
SmartThings
•
The Samsung SmartThings hub is a hub that connects to many Zigbee and
Zwave devices
•
The SmartThings hub itself needs to connect to a standard internet router
so that SkySpark has https access to it
•
It has a static apiKey with ssl/https which yields a level of security
•
The personal access token is sent with requests as a standard bearer token
in a header
•
The SmartThings hub requests are sent to the cloud which allows the
SkySpark server to not be on the local network
Zigbee and Zwave
•
Zigbee and Zwave networks are called mesh networks meaning their
devices can extend the range of the networks and they also dynamically
adjust to provide the strongest possible signal if devices move
•
Devices on battery power will not extend the network to conserve energy
•
Zwave devices can hop four times to extend the network
•
Zigbee devices have no defined limit to number of hops to extend their
network
•
Zigbee and Zwave networks operate on difference frequencies than wifi so
they do not interfere with wifi networks and vice-versa which is a major
advantage
•
Although the SmartThings hub can connect to Zigbee and Zwave
simultaneously, Zigbee will be its own network and Zwave will be its own
network meaning the one will not extend the other
Command and Control
•
These technologies can send commands as well as receive sensor values
•
Can control:
•
Wall plugs (some measure energy)
•
Other devices modelled as on/off switches
•
Dimmable lights
•
Colored lights
•
These can be controlled via virtually anything you can imagine:
•
Time/schedule
•
Remote control
•
Sensors on the following page
Loggable Sensors
•
The following have been modelled and can be logged:
•
Temperature
•
Humidity
•
Light level
•
Motion
•
UV
•
Vibration
•
Door/Window open/close
•
Water leak sensor/presence of water
•
Power, energy, current, and voltage
•
Light level of a dimmable bulb
•
Hue, saturation, level of a colored bulb
Control Applications
•
Here are some popular control applications:
•
Water main off when leak detected
•
Window shades up/down based on outside light
•
Outside lights on/off based on outside light
•
Irrigation system on/off based on if it rained recently, the season, and the time
•
Lights on when door open or motion detected
•
Remote-controlled lights and TVs (yes, SkySpark can log and use the actual values of
remote controls (ie
pushed
,
double
,
held
))
•
Use key fob to change setpoints and turn devices off when not around
Ziva is an Aeotec Distributor
•
These devices have been tested and work great:
•
Aeotec Smart Switch 6 (controllable and measures energy)
•
Aeotec Multisensor 6 (measures 6 attributes/states at once)
•
Aeotec Home Energy Monitor 5
•
Aeotec Nanomote Quad (
does not work as expected with this hub
)
•
Aeotec Door Window Sensor
•
Aeotec Water Sensor 6
•
Aeotec Water Sensor with Probe
•
https://aeotec.com/products/
•
Contact us at: adam@ziva-tech.com to discuss
Other Devices that were Tested
•
Most Samsung SmartThings devices
•
Samsung has built-in support for non-standard devices such as their wifi
wall plugs and even their TVs
•
Sylvania color-changing bulbs
•
Philips Hue dimmable and color bulbs (require Philips Hue hub)
•
Several other wall plugs
•
Inovelli sensors did not work well
•
Some wall plugs that did not work well: Inovelli and Neo
•
If a device is not explicitly mentioned, please contact us before purchasing
at: adam@ziva-tech.com
•
Note that making color-changing bulbs come on white is not fully
implemented
Samsung Integration
•
Samsung has integrated many of their smart devices with the SmartThings
hub
•
Their wifi smart plug with energy monitoring works flawlessly
•
As mentioned before TVs have been tested to work
•
It is presumed that many of their other smart devices such as ones you would find in
a kitchen work, but they have not been tested
SmartThings API Set Up
•
To have SkySpark talk to the SmartThings hub, it is necessary to generate a
personal access token at this site: https://account.smartthings.com/tokens
•
The token that is given will not be accessible on the SmartThings website or in
SkySpark once it is entered into the connector, so
it is recommended that you
type your personal access token somewhere so you do not lose it
SmartThings Connectors in SkySpark
•
Creating a SmartThings connector:
•
dis
: Any Readable Name
•
smartThingsPersonalToken
: This will be provided here:
https://account.smartthings.com/tokens
and acts as both a username and password
•
uri
:
`https://api.smartthings.com/v1/`
•
The
smartThingsPollFreq
tag determines the minimum amount of time before the cache can
be refreshed and how often the curVal values will be updated (which is from where both
polling with intervals and COV come). The default value of 1min is good for detecting COV
changes, but the SmartThings hub has been tested down to 1sec for real-time control and
works very well.
•
Of course, these records will have the
smartThingsConn
and
conn
tags
•
These can be created in the connector app
SmartThings Connector
Polling of curVal
•
smartThingsPollFreq
(duration)
•
How often you want SkySpark to poll the connector for COV
•
The default is 1min
•
It is a tuning parameter
•
Note that this determines how often the curVal in SkySpark changes. You would still need
to set how often the data is collected with the hisCollect tags.
SmartThings Functions
•
smartThingsCmd – send the smartThings a custom request; defaults to a lobby that you can
walk
•
read(smartThingsConn).smartThingsCmd
•
smartThingsLearn – return a grid of all available cur and his points
•
read(smartThingsConn).smartThingsLearn
•
smartThingsSyncCur – force one or more points to sync
•
readAll(smartThingsCur).smartThingsSyncCur
•
smartThingsWrite – write a value back to the smartThings
•
read(plug and smartThingsWrite and cmd).smartThingsWrite(true, 9, "me")
•
smartThingsPing – send
ping
to connector to check connection
•
read(smartThingsConn).smartThingsPing
Getting Data for SmartThings Points
Manually or Automatically
•
Collecting current values (from curVal):
•
Each point must have these tags:
•
smartThingsConnRef
(ref) which is a ref that points to the SmartThings Connector
•
smartThingsCur
(str)
which points to the SmartThings point object
•
his
(marker)
•
cur
(marker)
•
hisCollectCov
(marker or number) for cov collection
OR
•
hisCollectInterval
(duration) for polling
•
Some devices such as certain Samsung TVs go completely offline when they are off, so instead of
checking for a value like normal, we can see if the device is online or offline. The tag to add for this is
useHealthCheck
.
Note: we recommend
also using a
hisCollectInterval of
24hr when using a
hisCollectCov to
catch faulty sensors.
Writing to SmartThings Points from SkySpark
Manually or with Automated Tasks
•
Writing/Sending current values to a SmartThings point:
•
Each point must have these tags:
•
smartThingsConnRef
(ref) which is a ref that points to the SmartThings Connector
•
smartThingsWrite
(string)
which points to the SmartThings point object
•
writable
(marker)
•
writeAttempts
(number) (
optional
) this tag will send the write command multiple times if used when this
point is sent a command
•
Note: The
pointWrite()
command is the only writing command that is truly supported. The
pointAuto()
function is only used to clear the
writeVal
on SkySpark’s end. It does not do
anything on the device’s end.
Basic Troubleshooting
•
Note that it is normal for a connection to close when it has no points in a watch
for a given period of time
•
For larger systems, you want to set the poll frequency to a higher value to
avoid network congestion
Getting Points via Code
() => do
conn: read(smartThingsConn)
conn.smartThingsLearn().map r => do
r = r.merge(
{equipRef: read(equip)->id,
siteRef: read(site)->id,
hisCollectInterval: if (r->kind == "Number") 15min,
hisCollectCov: if (r->kind != "Number") marker(),
})
end.each r => commit(diff(null, r, {add}))Run as a task in large systems to avoid a timeout error
Getting Points with GUI
•
We recommend using the Builder App’s drag and drop capability to select
which points are of interest as there are often many superfluous points
