RNA and Protein Synthesis Processes


RNA



Gene
 – section of DNA that are coded
instructions for the cell

The instructions are to make proteins, which
in turn run and carry out processes in the cell

RNA is needed to help carry out the code.


RNA is made of nucleotides like DNA. There are a
few differences….

5 carbon sugar –
ribose (instead of deoxyribose)
Phosphate group
Nitrogen base-  NO THYMINE (T)
                               instead is
uracil (U
)
                                 A-U


o


RNA is a
single strand







What is wrong with this pic?
 There are 3 Types of RNA

mRNA- messenger RNA
 copies code of DNA and delivers it

rRNA- ribosomal RNA
  part of ribosome

tRNA- transfer RNA
   carries amino acid coded for to build protein


n
Protein Synthesis

For DNA to create a protein  there are 2 major
steps:

1.
Transcription

2.
Translation
TRANSCRIPTION

DNA is copied into mRNA in the nucleus

(*DNA NEVER leaves the nucleus)

mRNA carries the code outside the nucleus to
the ribosome to be read
TRANSLATION

mRNA is read by the ribosome—in the
cytoplasm!

The code “calls” for specific amino acids to
join to create a protein

Amino acids brought into place by tRNA


j
Slide Note
Embed
Share

RNA plays a crucial role in protein synthesis as it carries coded instructions from DNA. There are three types of RNA - mRNA, rRNA, and tRNA, each serving specific functions in the process. The steps of protein synthesis involve transcription, where DNA is copied into mRNA, and translation, where mRNA is read by ribosomes to create proteins using amino acids delivered by tRNA.

  • RNA
  • Protein Synthesis
  • mRNA
  • Transcription
  • Translation

Uploaded on Sep 27, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript


  1. RNA

  2. Gene section of DNA that are coded instructions for the cell The instructions are to make proteins, which in turn run and carry out processes in the cell RNA is needed to help carry out the code.

  3. RNA is made of nucleotides like DNA. There are a few differences . 5 carbon sugar ribose (instead of deoxyribose) Phosphate group Nitrogen base- NO THYMINE (T) instead is uracil (U) A-U

  4. o

  5. RNA is a single strand What is wrong with this pic?

  6. There are 3 Types of RNA mRNA- messenger RNA copies code of DNA and delivers it rRNA- ribosomal RNA part of ribosome tRNA- transfer RNA carries amino acid coded for to build protein

  7. n

  8. Protein Synthesis For DNA to create a protein there are 2 major steps: 1. Transcription 2. Translation

  9. TRANSCRIPTION DNA is copied into mRNA in the nucleus (*DNA NEVER leaves the nucleus) mRNA carries the code outside the nucleus to the ribosome to be read

  10. TRANSLATION mRNA is read by the ribosome in the cytoplasm! The code calls for specific amino acids to join to create a protein Amino acids brought into place by tRNA

  11. j
