Python Data Mining and Cluster Analysis in Context
Python Programming in Context
Chapter 7
Objectives
•
To use Python lists as a means of storing data
•
To implement a nontrivial data mining
application
•
To understand and implement cluster analysis
•
To use visualization as a means of displaying
patterns
Cluster
•
Data points that have something in common
•
Clusters are dissimilar to each other
•
Use simple Euclidean distance to measure
how close one point is to another
•
Centroid is a point that represents a cluster
(not necessarily a real data point)
Figure 7.1
Figure 7.2
Figure 7.3
Figure 7.4
Listing 7.1
def euclidD(point1, point2):
sum = 0
for index in range(len(point1)):
diff = (point1[index]-point2[index]) ** 2
sum = sum + diff
euclidDistance = math.sqrt(sum)
return euclidDistance
Figure 7.5
Listing 7.2
def readFile(filename):
datafile = open(filename, "r")
datadict = {}key = 0
for aline in datafile:
key = key + 1
score = int(aline)
datadict[key] = [score]
return datadict
Indefinite Iteration
•
Repeating a process an unknown number of
times
•
Control is based on a boolean expression
•
Infinite loop is possible
•
Any for loop can be written as a while loop
Listing 7.3
while <condition>:
statement1
statement2
...
statementn
Figure 7.6
Listing 7.4
sum = 0
for anum in range(1,11):
sum = sum + anum
print(sum)
Listing7.5
sum = 0
anum = 1 #initialization
while anum <= 10: #condition
sum = sum + anum
anum = anum + 1 #change of state
print(sum)
Listing 7.6
sum = 0
anum = 1
while anum <= 10:
sum = sum + anum
print(sum)
Listing 7.7
def readFile(filename):
datafile = open(filename, "r")
datadict = {}key = 0
aline = datafile.readline()
while aline != "":
key = key + 1
score = int(aline)
datadict[key] = [score]
aline = datafile.readline()
return datadict
Creating Clusters
•
Decide on number of clusters
•
Choose data points to be initial centroids
•
Assign data points to be members of a
centroid
•
Recompute centroids
•
Repeat
Listing 7.8
def createCentroids(k, datadict):
centroids=[]
centroidCount = 0
centroidKeys = []
while centroidCount < k:
rkey = random.randint(1,len(datadict))
if rkey not in centroidKeys:
centroids.append(datadict[rkey])
centroidKeys.append(rkey)
centroidCount = centroidCount + 1
return centroids
Listing 7.9
def createClusters(k, centroids, datadict, repeats):
for apass in range(repeats):
print("****PASS",apass,"****")clusters = []
for i in range(k):
clusters.append([])
for akey in datadict:
distances = []
for clusterIndex in range(k):
dist = euclidD(datadict[akey],centroids[clusterIndex])
distances.append(dist)
mindist = min(distances)
index = distances.index(mindist)
clusters[index].append(akey)
dimensions = len(datadict[1])
Listing 7.9 continued
for clusterIndex in range(k):
sums = [0]*dimensions
for akey in clusters[clusterIndex]:
datapoints = datadict[akey]
for ind in range(len(datapoints)):
sums[ind] = sums[ind] + datapoints[ind]
for ind in range(len(sums)):
clusterLen = len(clusters[clusterIndex])
if clusterLen != 0:
sums[ind] = sums[ind]/clusterLen
centroids[clusterIndex] = sums
for c in clusters:
print ("CLUSTER")for key in c:
print(datadict[key], end=" ")
print()
return clusters
Figure 7.7
Listing 7.10
def clusterAnalysis(dataFile):
examDict = readFile(dataFile)
examCentroids = createCentroids(5, examDict)
examClusters = createClusters(5,
examCentroids, examDict, 3)
clusterAnalysis("cs150exams.txt")Visualizing Clusters
•
Earthquake data
•
Show clusters on a map
•
Use turtle module to plot data
Figure 7.8
Listing 7.11
def visualizeQuakes(dataFile):
datadict = readFile(dataFile)
quakeCentroids = createCentroids(6, datadict)
clusters = createClusters(6, quakeCentroids, datadict, 7)
quakeT = turtle.Turtle()
quakeWin = turtle.Screen()
quakeWin.bgpic("worldmap.gif")quakeWin.screensize(448,266)
quakeWin.setup(width=500, height=300)
wFactor = (quakeWin.screensize()[0]/2)/180
hFactor = (quakeWin.screensize()[1]/2)/90
quakeT.hideturtle()
quakeT.up()
colorlist = ["red","green","blue","orange","cyan","yellow"]
for clusterIndex in range(6):
quakeT.color(colorlist[clusterIndex])
for akey in clusters[clusterIndex]:
lon = datadict[akey][0]
lat = datadict[akey][1]
quakeT.goto(lon*wFactor,lat*hFactor)
quakeT.dot()
quakeWin.exitonclick()
Figure 7.9
