OpenStackClient: Your CLI Experience Matters!
OpenStackClient, led by Dean Troyer and Steve Martinelli, is a command-line client for OpenStack aiming to provide a cohesive user experience spanning Compute, Identity, Image, Network, Object Storage, and Block Storage APIs. Learn about its scope, user base, contributions, and future plans in this informative session.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
OpenStackClient Your CLI experience matters! Dean Troyer Software Developer, Intel OpenStackClient PTL Twitter: @dtroyer Steve Martinelli Software Developer, IBM Keystone PTL, OpenStackClient Core Twitter: @stevebot
About the presenters Dean Troyer Senior Cloud Software Developer @ Intel OpenStackClient PTL (and creator!) Been working on OpenStack since day 0 Twitter: @dtroyer Steve Martinelli Senior Software Developer @ IBM Keystone PTL and OpenStackClient Core Reviewer Been contributing to OpenStack since the Grizzly release Twitter: @stevebot
Agenda Overview of OpenStackClient (OSC) Scope of OpenStackClient What s new in 3.0.0? UX Commandments OpenStackClient parity Who uses OpenStackClient? How you can contribute? Future Plans for OpenStackClient
Overview of OpenStackClient
Overview of OpenStackClient Mission statement: OpenStackClient (aka OSC) is a command-line client for OpenStack that provides a uniform set of commands for Compute, Identity, Image, Network, Object Storage, and Block Storage APIs In simple terms: Provide a better user experience (UX) with the CLI, via a single pane of glass, that is consistent
Scope of OpenStackClient What is in the box Compute (nova) Identity (keystone) v2 and v3 Image (glance) v1 and v2 Network (neutron) Object (swift) Volume (cinder) v1 and v2 Additional projects are supported as plugins Install openstackclient first Install a plugin of your choice! (heatclient, barbicanclient, etc) What is missing from the ecosystem? Database (trove), Containers (magnum), Telemetry (ceilometer), SW Dev Lifecycle (solum)
Scope of OpenStackClient zaqar senlin tripleo sahara searchlight aodh sahara Image Compute Network gnocchi OpenStackClient murano Identity Object Volume barbican mistal congress designate cue heat ironic
Whats new in OpenStackClient 3.0.0?
OpenStackClient 3.0.0 During the Newton development cycle, we released OpenStackClient 3.0.0, this was a MAJOR release! Added a ton of networking commands (agent, network rbac, port, subnet, fixed and floating ip address, router, etc) Made networking commands service-agnostic. The commands common to both will work with Neutron and Nova-net (whenever possible)! Special thanks to Richard Theis and the Neutron team for making this happen! Integrated with keystoneauth Now able to authenticate with any number of keystone supported plugins First release of osc-lib -- a library that OpenStackClient plugins can depend on, rather than using all of python-openstackclient Support bulk deletion for all delete commands
OpenStack UX Commandments
UX commandment #1 $ openstack user delete user1 user2 $ openstack volume delete volume1 volume2 Thou shalt always provide a multi-delete option
UX commandment #2 $ openstack volume set <volume> [--name <name>] [--description <description>] [--bootable | --non-bootable] [--properties <key=value>] [--state <state>] [--size <size>] Instead of $ cinder set-bootable <volume> <True|true|False|false> $ cinder metadata <volume> <action> <key=value> $ cinder extend <volume> <new_size> $ cinder reset-state <volume> --state <state> $ cinder <i-don t-know-which-cmd-to-change-name> Thou shalt always group operations logically, NOT by API
$ openstack volume set vol2 --size 3 --property foo=bar Failed to set volume size: Volume is in error state, it must be available before size can be extended One or more of the set operations failed UX commandment #3 $ openstack volume set vol2 --size 3 --name vol3 Failed to set volume size: New size must be greater than 4 GB One or more of the set operations failed Provide meaningful error messages $ openstack volume delete vol1 vol2 Failed to delete volume with name or ID 'vol1': No volume with a name or ID of 'vol1' exists. 1 of 2 volumes failed to delete
Leverage -c and -f value to get the value directly UX commandment #4 $ openstack user create user3 -c id -f value ae33531e0d064052aafe47e18503453a Works with lists too! $ openstack user list -c ID -f value 2e7c787e522940549195acfbed96c3a8 879b10520fae4949829b4bbdb0c0338a Down with prettyTable! Long live cliff! Rather than: $ keystone user create foo | grep " id " | get_field 2 $ keystone user-list | awk "/ foo / { print \$2 }"
Leverage built-in formatters when showing data UX commandment #5 $ openstack user list -c Name -c ID -f json [ { "ID": "09e4cfd6adb25a77ccaef4b0a5", "Name": "alt_demo" }, { "ID": "1e186fac6a04cab99cc52afe81", "Name": "user2" } ] Thou shalt provide YAML, JSON and CSV support
$ openstack user show --help positional arguments: <user> User to display (name or ID) UX commandment #6 $ openstack user show user3 +----------+----------------------------------+ | Field | Value | +----------+----------------------------------+ | email | None | | enabled | True | | id | ae33531e0d064052aafe47e18503453a | | name | user3 | | username | user3 | +----------+----------------------------------+ Support both name and ID when possible (hide this distinction from the user!) $ openstack user show ae33552aafe47e18503453a +----------+---------------------------------+ | Field | Value | +----------+----------------------------------+ | email | None | | enabled | True | | id | ae33531e0d064052aafe47e18503453a | | name | user3 | | username | user3 | +----------+----------------------------------+
UX commandment #7 Use project not tenant Use real words for resources Do not abbreviate Do not include hyphens (-) or underscores (_) Use properties not metadata Above all, be CONSISTENT
OpenStackClient Parity with Legacy CLIs
OpenStackClient Parity with Legacy CLIs What s commands are missing from the project CLIs when compared to OSC? Compute Pretty good! Some contrib items missing, but the most used commands are in! Identity Fully compatible with both v2 and v3 APIs. Keystone CLI was removed in Mitaka! Image Pretty good compatibility with v1; lacking new commands introduced in v2 Network Neutron CLI v6.0.0 has 128 core commands with 56% transitioned to OSC OSC has 77 network commands ( with WIP patches for another 30+ commands) Missing support for VPNaaS, LBaaS, FWaaS and BGP Gets tricky for advanced features/services due to stadium approach Object Basic support, could be better Volume About 80% of v1 CLI commands are implemented About 65-70% of v2 CLI commands are implemented We are constantly playing catch-up. We have to aim for high value targets first -- the commands that are most often used. We fill in the gaps as the need arises.
Glowing reviews for OpenStackClient https://www.mail-archive.com/openstack-dev@lists.openstack.org/msg64944.html
Glowing reviews for OpenStackClient https://www.mail-archive.com/openstack-dev@lists.openstack.org/msg79361.html
How can you contribute to OpenStackClient?
How can you contribute? As a user / operator We love hearing feedback, good or bad. File a bug report Poke dtroyer or stevemar on IRC (#openstack-sdks) Tweet about it Post something on the mailing list As a developer Help get us to parity! As a PTL of another project (nova, neutron, cinder, glance) If a contributor is creating a new command for the project Python library and/or CLI, enforce that they add it to OpenStackClient as well.
Future Plans for OpenStackClient
Future Plans for OpenStackClient Plugin enhancements Extend existing commands (i.e. allow plugins to hook into the quota commands) Handle business logic Create a purge command to remove everything associated with a project --help needs help Local caching of tokens Keyring integration Move additional common bits into osc-lib Output column naming
