1. NERC IBR Alert NERC IBR Alert Summary Summary Mark Henry Mark Henry Director, Reliability Outreach Director, Reliability Outreach 1 [PUBLIC] NERC IBR Alert Summary

2. NERC IBR Alert Summary NERC Level 2 Alert issued March 14, 2023 Issued as a result of multiple disturbance events Pertained specifically to registered of BES-connected solar PV resources Does not include wind or storage facilities Purpose was to gather data understand whether additional actions are necessary to mitigate possible BPS performance risks Data collection included specific settings for inverter and plant level controls Due date extended to July 31, 2023 NERC-wide data collection included responses from 521 generation facilities Over 53,500 MW 15 different OEM s 2 [PUBLIC] NERC IBR Alert Summary

3. NERC IBR Alert Summary for ERCOT Region Inverter Manufacturer General Electric KACO Other Power Electronics Schneider Electric SMA Sungrow TMEIC Grand Total Sum of Nameplate MW 525 820 185 3,275 # Facilities 2 7 2 16 # Inverters 165 624 84 1,090 1 1 7 91 64 450 3,968 6,536 182 225 1,277 4,214 10,703 19 55 Key Takeaways: At the time the Alert was issued, this represented all NERC-registered solar facilities and approximately 70% of the total ERCOT commercial operation solar capacity 3 [PUBLIC] NERC IBR Alert Summary

4. IBR Fault Ride-Through Behavior Sum of Nameplate MW Fault ride-through behavior enabled at the facility Active and reactive current injection (active current priority at current limit) Active and reactive current injection (reactive current priority at current limit) Momentary cessation (no active or reactive current injection) Reactive current injection (no active current injection) No response Grand Total # Facilities 9 2,126 32 6,009 5 705 5 1,085 4 779 55 10,703 Key Takeaways: Momentary cessation is undesired (two plants affected during 2022 Odessa event). Reducing active power to provide reactive also goes against the recent FERC order. Reactive current priority at current limit is the desired response for low voltage conditions. 4 [PUBLIC] NERC IBR Alert Summary

5. PLL Loss of Sync and Phase Jump Protection Do the inverters have phase lock loop loss of synchronization protection or phase jump protection (enabled or hard-coded)? No Phase Angle # Facilities Sum of Nameplate MW 27 5,467 Yes KACO: 60-90 deg Power Electronics: 25-30 deg TMEIC: 15-35 deg 25 4,548 No response 3 688 Grand Total 55 10,703 Key Takeaways: It is preferred that phase-lock-loop or phase jump protection be disabled for BES-connected solar facilities (five plants affected during 2022 Odessa event). If this protection is required by the OEM, a minimum phase of 25 degrees is desired. 5 [PUBLIC] NERC IBR Alert Summary

6. Instantaneous AC Overcurrent Protection Do the inverters have instantaneous ac overcurrent protection settings (enabled or hard-coded)? No Yes No response Grand Total Sum of # Facilities 4 48 3 55 Nameplate MW 908 9,107 688 10,703 Key Takeaways: Instantaneous AC overcurrent tripping during disturbances such as Odessa is indicative of inverter control issues. 6 [PUBLIC] NERC IBR Alert Summary

7. Power Plant Controller Tripping Does the power plant controller have protection settings enabled that can trip the entire facility or individual inverters? No Yes No response Grand Total Sum of # Facilities 30 21 4 55 Nameplate MW 5,506 4,252 945 10,703 Key Takeaways: Power plant control protections settings are often not documented in models. Plant-level controller interactions can inhibit or delay recovery from an event (two plants affected during 2022 Odessa disturbance). Plant-level control parameters should be optimized to support the grid without triggering inverter protection 7 [PUBLIC] NERC IBR Alert Summary

8. Inverter Manufacturer Event History Has the inverter manufacturer(s) experienced instances of inadvertent tripping at other facilities due to instantaneous voltage protection, instantaneous frequency protection, instantaneous ac overcurrent, or dc protection for the specific inverter make, model, and firmware used at your facility? No/No response KACO TMEIC Power Electronics Yes Grand Total # Facilities 40 7 5 9 15 55 Sum of Nameplate MW 7,788 820 1,419 1,719 2,915 10,703 Key Takeaways: Manufacturer s highlighted were involved in both Odessa events. The No response indicates a potential communication issue between the facility owners and the OEMs, and a possible outreach opportunity between NERC, Regional Entities, and facility owners. 8 [PUBLIC] NERC IBR Alert Summary

9. Frequency/Voltage Settings vs Inverter Capability Is the setting based on the maximum capability of the inverter? HVRT LVRT Yes No Pct % Yes Yes No HFRT No LFRT No Manufacturer General Electric KACO Other Power Electronics Schneider Electric SMA Sungrow TMEIC Total Pct Yes Pct Yes Pct 8 0 100% 8 2 80% 2 0 100% 3 0 100% 11 0 7 8 61% 0% 9 0 13 8 41% 0% 6 0 11 6 35% 0% 4 0 11 8 27% 0% 6 40 13% 6 44 12% 1 34 3% 1 34 3% 0 5 0% 0 5 0% 0 2 0% 0 4 0% 0 1 26 52 8 0% 3% 39% 28% 0 0 40 63 4 22 27 125 0% 0% 60% 34% 0 1 22 32 4 18 33 108 0% 5% 40% 23% 0 1 18 27 4 20 30 111 0% 5% 38% 20% 29 40 137 Key Takeaways: Frequency and voltage ride through settings should be reflective of the maximum equipment capability of the inverter. PRC-024 curves are intended for the point of interconnection and not at the inverter terminals. 9 [PUBLIC] NERC IBR Alert Summary

10. Questions? 10 [PUBLIC] NERC IBR Alert Summary

11. ERCOT vs Overall NERC Comparison ERCOT NERC-Wide 11 [PUBLIC] NERC IBR Alert Summary

12. ERCOT vs Overall NERC Comparison ERCOT NERC-Wide 12 [PUBLIC] NERC IBR Alert Summary

13. ERCOT vs Overall NERC Comparison ERCOT NERC-Wide 13 [PUBLIC] NERC IBR Alert Summary

14. ERCOT vs Overall NERC Comparison ERCOT NERC-Wide 14 [PUBLIC] NERC IBR Alert Summary

15. ERCOT vs Overall NERC Comparison ERCOT NERC-Wide 15 [PUBLIC] NERC IBR Alert Summary

16. DC Bus Protection DC Bus Protection # Facilities Enabled On-Site 23 40 27 51 24 34 51 44 27 6 22 MW # Facilities Not Enabled 27 10 24 1 27 16 MW Current Unbalance DC Bus Balance DC Bus Minimum Voltage DC Ground Fault DC Insulation Fault DC Overcurrent DC Overvoltage DC Reverse Current DC Undervoltage DC/AC Power Unbalance Voltage Unbalance 4164 7707 4414 9463 4487 6102 9203 8120 4709 1260 4059 4839 1296 4790 160 4716 2902 7 1303 4494 7743 4944 24 44 28 16 [PUBLIC] NERC IBR Alert Summary
