MOSFET Measurement Experiment Overview

MOSFET Measurement
b10901065 林奕樺
b10901087 林辛源
1
Outline
Experiment Steps
pFET Measurement
nFET Measurement
Summary
Comparison
2
Experiment Steps
3
Apply voltage on drain and gate, then measure the drain-source current.
Experiment Steps
4
Apply voltage on drain and gate, then measure the drain-source current.
V
s,b
 ground
I
d
-V
g
:V
d
 0.05V or 0.5V (nFET) / -0.05V or -0.5V (pFET)
           V
g
 sweep from 0 to 15 V (nFET) / -15 V (pFET)
I
d
-V
d
:V
OV
 starts from 0 to 5 V (nFET) / -5 V (pFET), every 0.5 V a step
           V
d
 sweep from 0 to 4 V (nFET) / -4 V (pFET)
Ring FET Measurement-Geometric Parameters
5
            G
S                       D
            G
S                       D
R
avg
=268.45 ±
0.69
μm
 D         G
                    S
Ring FET Measurement-Geometric Parameters
6
            G
S                       D
            G
S                       D
R
avg
=268.45 ±
0.69
μm
r
avg
=136.75 ±
0.84
μm
 D         G
                    S
Ring FET Measurement-Geometric Parameters
7
            G
S                       D
            G
S                       D
R
avg
=268.45 ±
0.69
μm
r
avg
=136.75 ±
0.84
μm
L=131.70 ±
1.09μm
W=1272.97 ±
3.42
μm
L
W
 D         G
                    S
W/L=9.67 ±
0.08
Rectangular FET Measurement-Geometric Parameters
8
            G
S                       D
            G
S                       D
L=53.13 ± 0.83
μm
            G
    S              D
Rectangular FET Measurement-Geometric Parameters
9
            G
S                       D
            G
S                       D
L=53.13 ± 0.83
μm
W=282.81 ± 0.98
μm
            G
    S              D
W/L=
5.32
± 0.09
Ring pFET Measurement-I
ds
 vs. V
gs
 (linear scale)
10
V
t
=x intercept of I
d
 tangent

 =-1.10 V
DIBL=ΔV
t
 / ΔV
ds
        =0.98 V/V
Ring pFET Measurement-I
ds
 vs. V
gs
 (log scale)
11
I
ON
/I
OFF
=3.538E3 A/A
SS=dV
gs
/d(log(I
ds
))


=1035 mV/dec
Ring pFET Measurement-I
ds
 vs. V
ds
12
Rectangular pFET Measurement-I
ds
 vs. V
gs
 (linear scale)
13
V
t
=-0.59 V
DIBL=2.31 V/V
Rectangular pFET Measurement-I
ds
 vs. V
gs
 (log scale)
14
I
ON
/I
OFF
=1.207E2 A/A
SS=1723 mV/dec
Rectangular pFET Measurement-I
ds
 vs. V
ds
15
Ring nFET Measurement-I
ds
 vs. V
gs
 (linear scale)
16
V
t
=1.43 V
DIBL=-2.27 V/V
Ring nFET Measurement-I
ds
 vs. V
gs
 (log scale)
17
I
ON
/I
OFF
=12.79 A/A
SS=6098 mV/dec
Ring nFET Measurement-I
ds
 vs. V
ds
18
Rectangular nFET Measurement-I
ds
 vs. V
gs
 (linear scale)
19
V
t
=1.71 V
DIBL=-2.96 V/V
Rectangular nFET Measurement-I
ds
 vs. V
gs
 (log scale)
20
I
ON
/I
OFF
=11.55 A/A
SS=3674 mV/dec
Rectangular nFET Measurement-I
ds
 vs. V
ds
21
Summary
22
Ring pFET
  V
t
=-1.10 V

DIBL=0.98 V/V

I
ON
/I
OFF
=3.538E3 A/A

SS=1035 mV/dec
Ring nFET
  V
t
=1.43 V
  DIBL=-2.27 V/V
  I
ON
/I
OFF
=12.79 A/A
  SS=6098 mV/dec
Rectangular pFET
  V
t
=-1.85 V
  DIBL=2.31 V/V
  I
ON
/I
OFF
=1.207E2 A/A
  SS=1723 mV/dec
Rectangular nFET
  V
t
=1.71 V
  DIBL=-2.96 V/V
  I
ON
/I
OFF
=11.55 A/A
  SS=3674 mV/dec
Conclusion:
  Ring pFET
  shows the best result.
V
t
 <= 0.5 V
I
ON
 ~ 1000uA/um
SS ~ 60 mV/dec
23
 D         G
                    S
Comparison
 S         G
                    D
Comparison
24
Conclusion:
  Drain at outside causes larger leakage current at off-state.
Slide Note
Embed
Share

This experiment involves measuring pFET and nFET devices by applying voltage on drain and gate to measure drain-source current. Geometric parameters of the devices are analyzed, including width, length, and aspect ratios. Detailed measurements and comparisons are made for different types of FETs, showcasing performance characteristics such as threshold voltage, current-voltage relationships, and on/off ratios.

  • MOSFET
  • Measurement
  • Experiment
  • Geometric Parameters
  • Device Performance

Uploaded on Sep 12, 2024 | 0 Views


Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

You are allowed to download the files provided on this website for personal or commercial use, subject to the condition that they are used lawfully. All files are the property of their respective owners.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author.

E N D

Presentation Transcript


  1. MOSFET Measurement b10901065 b10901087 1

  2. Outline Experiment Steps pFET Measurement nFET Measurement Summary Comparison 2

  3. Experiment Steps Apply voltage on drain and gate, then measure the drain-source current. 3

  4. Experiment Steps Apply voltage on drain and gate, then measure the drain-source current. Vs,b ground Id-Vg Vd 0.05V or 0.5V (nFET) / -0.05V or -0.5V (pFET) Vg sweep from 0 to 15 V (nFET) / -15 V (pFET) Id-Vd VOV starts from 0 to 5 V (nFET) / -5 V (pFET), every 0.5 V a step Vd sweep from 0 to 4 V (nFET) / -4 V (pFET) 4

  5. Ring FET Measurement-Geometric Parameters G Ravg=268.45 0.69 m S D D G G S S D 5

  6. Ring FET Measurement-Geometric Parameters G Ravg=268.45 0.69 m S D ravg=136.75 0.84 m D G G S S D 6

  7. Ring FET Measurement-Geometric Parameters G Ravg=268.45 0.69 m S D W ravg=136.75 0.84 m L L=131.70 1.09 m W=1272.97 3.42 m D G G S S D W/L=9.67 0.08 7

  8. Rectangular FET Measurement-Geometric Parameters G S D L=53.13 0.83 m G S D G S D 8

  9. Rectangular FET Measurement-Geometric Parameters G S D L=53.13 0.83 m W=282.81 0.98 m G W/L=5.32 0.09 S D G S D 9

  10. Ring pFET Measurement-Ids vs. Vgs (linear scale) Vt=x intercept of Id tangent =-1.10 V DIBL= Vt / Vds =0.98 V/V 10

  11. Ring pFET Measurement-Ids vs. Vgs (log scale) ION/IOFF=3.538E3 A/A SS=dVgs/d(log(Ids)) =1035 mV/dec 11

  12. Ring pFET Measurement-Ids vs. Vds 12

  13. Rectangular pFET Measurement-Ids vs. Vgs (linear scale) Vt=-0.59 V DIBL=2.31 V/V 13

  14. Rectangular pFET Measurement-Ids vs. Vgs (log scale) ION/IOFF=1.207E2 A/A SS=1723 mV/dec 14

  15. Rectangular pFET Measurement-Ids vs. Vds 15

  16. Ring nFET Measurement-Ids vs. Vgs (linear scale) Vt=1.43 V DIBL=-2.27 V/V 16

  17. Ring nFET Measurement-Ids vs. Vgs (log scale) ION/IOFF=12.79 A/A SS=6098 mV/dec 17

  18. Ring nFET Measurement-Ids vs. Vds 18

  19. Rectangular nFET Measurement-Ids vs. Vgs (linear scale) Vt=1.71 V DIBL=-2.96 V/V 19

  20. Rectangular nFET Measurement-Ids vs. Vgs (log scale) ION/IOFF=11.55 A/A SS=3674 mV/dec 20

  21. Rectangular nFET Measurement-Ids vs. Vds 21

  22. Summary Ring pFET Vt=-1.10 V DIBL=0.98 V/V ION/IOFF=3.538E3 A/A SS=1035 mV/dec Rectangular pFET Vt=-1.85 V DIBL=2.31 V/V ION/IOFF=1.207E2 A/A SS=1723 mV/dec Conclusion Ring pFET shows the best result. Ring nFET Vt=1.43 V DIBL=-2.27 V/V ION/IOFF=12.79 A/A SS=6098 mV/dec Rectangular nFET Vt=1.71 V DIBL=-2.96 V/V ION/IOFF=11.55 A/A SS=3674 mV/dec Vt <= 0.5 V ION ~ 1000uA/um SS ~ 60 mV/dec 22

  23. Comparison D G S G S D 23

  24. Comparison Conclusion Drain at outside causes larger leakage current at off-state. 24
