This proposal focuses on introducing a Mixed Elastic Scattering format to address the need for a more rigorous treatment of thermal elastic scattering effects in selected nuclides. The format extension, compatible with ENDF-6, supports advanced moderator development without impacting existing TSL evaluations. Implementation involves FLASSH TSL evaluation code, NDEX nuclear data processing code, and MC21 neutron transport code. Examples illustrate the treatment of coherent and incoherent elastic scattering effects, with a particular emphasis on 7LiD and 7Li(7LiD) systems.

lillyans
lillyans Follow

Uploaded on Sep 27, 2024 | 0 Views

Download Presentation

Please find below an Image/Link to download the presentation.

The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.

E N D

Presentation Transcript

  1. Mixed Elastic Scattering Format Proposal M. L. Zerkle CSEWG Formats & Processing Committee November 30, 2020 The Naval Nuclear Laboratory is operated for the U.S. Department of Energy by Fluor Marine Propulsion, LLC, a wholly owned subsidiary of Fluor Corporation.

  2. Motivation Selected nuclides exhibit both coherent and incoherent elastic scattering effects in the thermal energy range More rigorous thermal elastic scattering treatment needed to support advanced moderator development Without treatment Bragg peaks either neglected (incoherent approximation) or to deep (coherent approximation) Mixed Elastic Scattering format is a simple extension to ENDF-6 format Provides support for new capability in GNDS No impact on existing TSL evaluations Implementation FLASSH TSL evaluation code (to be released) NDEX nuclear data processing code MC21 neutron transport code Bound Scattering Cross Sections for Selected Nuclides (b) ?? ?? ?? Nuclide natH 1.7568(10) 80.26(6) 82.02(6) 1H 1.7583(10) 80.27(6) 82.03(6) 2H 5.592(7) 2.05(3) 7.64(3) natLi 0.454(10) 0.92(3) 1.37(3) 6Li 0.51(5) 0.46(5) 0.97(7) 7Li 0.619(11) 0.78(3) 1.40(3) natB 0.354(5) 1.70(12) 5.24(11) 7LiD and 7LiH TSL evaluations 10B 0.144(8) 3.0(4) 3.1(4) 11B 5.56(7) 0.21(7) 5.77(10) 23Na 1.66(2) 1.62(3) 3.28(4) 2

  3. D(7LiD) Mixed Elastic Scattering TSL Evaluation Both coherent and incoherent elastic scattering effects captured in NDEX total elastic scattering cross sections 7LiD coherent and D incoherent elastic scattering cross sections approximately the same magnitude 3

  4. 7Li(7LiD) Mixed Elastic Scattering TSL Evaluation 7LiD coherent elastic scattering component larger than 7Li incoherent elastic scattering 7LiD Bragg scattering more prominent in 7Li(7LiD) total scattering cross sections from NDEX 4

  5. ENDF-6 Format Proposal 5

  6. D(7LiD) Mixed Elastic Scattering Example LTHR=3 1.150000+2 1.996800+0 3 0 0 0 15 7 2 2.936000+2 0.000000+0 5 0 1 3374 15 7 2 3374 1 15 7 2 1.235573-3 2.67690-34 2.471146-3 5.24780-34 3.706719-3 3.757353-3 15 7 2 4.942291-3 1.386287-2 6.177864-3 1.386287-2 7.413437-3 1.386287-2 15 7 2 9.884583-3 2.595574-2 1.112016-2 2.595574-2 1.235573-2 2.595574-2 15 7 2 1.359130-2 2.992438-2 1.482687-2 3.549502-2 1.606245-2 3.549502-2 15 7 2 4.399400-2 4.399400-2 4.399400-2 4.399400-2 4.399400-2 4.399400-2 15 7 2 4.399400-2 4.399400-2 15 7 2 2.054202+0 0.000000+0 0 0 1 6 15 7 2 6 2 15 7 2 2.936000+2 8.937898+0 4.000000+2 1.047985+1 5.000000+2 1.213545+1 15 7 2 6.000000+2 1.390890+1 7.000000+2 1.575652+1 8.000000+2 1.765328+1 15 7 2 0.000000+0 0.000000+0 0 0 0 0 15 7 0 1.150000+2 1.996800+0 0 1 0 0 15 7 4 0.000000+0 0.000000+0 0 0 6 0 15 7 4 3.395004+0 1.976285+2 1.996800+0 5.000000+0 0.000000+0 1.000000+0 15 7 4 0.000000+0 0.000000+0 0 0 1 300 15 7 4 300 4 15 7 4 2.936000+2 0.000000+0 5 0 1 200 15 7 4 200 4 15 7 4 2.059042-2 4.931327-4 2.163677-2 5.181545-4 2.273629-2 5.444438-4 15 7 4 2.389168-2 5.720646-4 2.510579-2 6.010840-4 2.638160-2 6.315727-4 15 7 4 Coherent Elastic Bound incoherent scattering cross section Incoherent Elastic Inelastic 6
