Presentation Transcript

1. Microservices? Anton Boyko Microsoft Azure MVP Ninja Azure Consultant boyko.ant@live.com

2. Agenda What and why? What is microservice architecture approach and why should I care? Several examples Several examples of microservice architecture from real life projects Implementation checklist Several important points you need to consider while planning your microservice architecture What about Azure? What Microsoft Azure can offer for my microservices?

3. WHAT AND WHY?

4. Criteria Maintainability Monitoring Scalability How easy is it to maintain the code? How easy is it to fix a bug? How easy is it to monitor solution health? How easy is it to add new computin power and handle heavier load? Updates Onboarding How easy is it to update solution to the newest version? How easy is it to get onboard a new team member?

5. Spaghetti $conn = new mysqli($servername, $username, $password, $dbname); if ($conn->connect_error) { die("Connection failed: " . $conn->connect_error); } $sql = "SELECT firstname, lastname FROM users"; $result = $conn->query($sql); if ($result->num_rows > 0) { echo "<table>"; while($row = $result->fetch_assoc()) { echo "<tr><td>"; echo $row["firstname"] . "</td><td>" . $row["lastname"]; echo "</td></tr>"; } echo "</table>"; } else { echo "0 results"; } $conn->close();

6. Spaghetti Maintainability Monitoring Scalability Impossible Almost impossible Sometimes possible Updates Onboarding Requires shutdown Highly demotivating

8. Monolith Application in which user interface and data access code are combined into a single program. Design philosophy is that the application is responsible not just for a particular task, but can perform every step needed to complete a particular function.

9. Monolith Solution Presentation Application Data NLB Solution Solution Solution Server Server Server

10. Monolith Maintainability Monitoring Scalability Mostly possible Highly depends on solution size Possible Mostly possible Updates Onboarding Requires shutdown Possible Highly depends on solution size

11. Microservices Microservices is a variant of the service- oriented architecture (SOA) architectural style that structures an application as a collection of loosely coupled services. Microservices should be fine-grained and protocols should be lightweight. Application is easier to understand, develop and test.

12. Microservices Microservice 1 Presentation Application Data NLB Microservice 2 Application Data Microservice 3 Presentation Server Server Server

13. Microservices Maintainability Monitoring Scalability Possible Possible Highly depends on solution size Possible Updates Onboarding Can be handled without shutdown Highly depends on solution size Possible

14. Nanoservices Nanoservices is a microservices anti-pattern where each service is too fine grained. Nanoservice is a service whose overhead (communications, maintenance etc.) outweighs its utility.

15. Nanoservices Get my orders User login Get categories Get goods Presentation Presentation Presentation Presentation Application Application Application Application Data Data Data Data Create order User register Add category Get good by id Presentation Presentation Presentation Presentation Application Application Application Application Data Data Data Data

16. Nanoservices Maintainability Monitoring Scalability Almost impossible Almost impossible Possible Updates Onboarding Can be handled without shutdown Extremely depends on solution size Sometimes possible

19. SEVERAL EXAMPLES

20. Online shop Identity Client Profile Admin Search Data Ad Social

21. Community portal Web Admin Rendering Identity Member Data Notification Speaker

22. IMPLEMENTATION CHECKLIST

23. Infrastructure components Microservices hosts Configuration source Routing and/or autodiscovery engine Monitoring engine Logging engine

24. CQRS Synchronous queries send request and wait for response with data it s acceptable to join data on a client side Asynchronous commands send request and wait for command unique id use command id to check execution status handling distributed transactions that affect several microservices can be tricky commands should be idempotent

25. CAP theorem Consistency Availability Partitioning

26. Eventual consistency After command for data modification was received, it may take some time for new data to be available for querying write entity Client app API DB id = 42 write [ 42 ] Client cache

27. Eventual consistency After command for data modification was received, it may take some time for new data to be available for querying read list Client app API DB [ 1, 20, 50, ] read [ 42, 60 ] Client cache

28. Eventual consistency After command for data modification was received, it may take some time for new data to be available for querying read list Client app API DB [ 1, 20, 42, 50, ] read [ 60 ] remove [ 42 ] Client cache

29. WHAT ABOUT AZURE?

30. Azure Service Fabric Service Fabric itself is platform agnostic Stateless and statefull services Service discovery Health monitoring Fault domains and upgrade domains Enterprise-ready https://docs.microsoft.com/en- us/azure/service-fabric/

31. Fault and upgrade domains Fault 1 Fault 2 Fault 3 Fault 4 Fault 5 Update 1 Node 1 Update 2 Node 2 Update 3 Node 3 Update 4 Node 4 Update 5 Node 5 Main Primary reserved Secondary reserved Microservice 1 1 2 3 Microservice 2 2 3 4 Microservice 3 3 4 5 Microservice 4 4 5 1 Microservice 5 5 1 2

32. Azure App Services .NET, Java, PHP, Node.JS, Python Shared web farm, isolated web apps Configuration management Backups Sticky sessions Built-in MySQL database https://docs.microsoft.com/en-us/azure/app- service-web/

33. Azure App Services NLB Server 1 Server 2 Server 3 Server 4 CPU RAM CPU RAM CPU RAM CPU RAM App 1 root App 2 root App 3 root App 4 root App 5 root Distributed file system

34. Azure App Services NLB Server 1 Server 2 Server 3 Server 4 CPU RAM CPU RAM CPU RAM CPU RAM App 1 root App 2 root App 3 root App 4 root App 5 root Distributed file system

35. Azure Functions Built on top of Azure App Services Small and independent unit of work Designed for handling huge amount of small parallel independent executions Consider them as event handlers Triggers and bindings Can be chained to handle sequential workflow Dedicated and consumption pricing plans https://docs.microsoft.com/en- us/azure/azure-functions/

36. Azure Functions

37. Azure Functions bindings Type Service Trigger Input Output Schedule Azure Functions HTTP Azure Functions Blob Storage Azure Storage Events Azure Event Hubs Queues Azure Storage Queues and topics Azure Service Bus Storage tables Azure Storage SQL tables Azure Mobile Apps No-SQL DB Azure DocumentDB Push Notifications Azure Notification Hubs Twilio SMS Text Twilio SendGrid email SendGrid

38. Azure functions quickstart Create cross-platform desktop apps using JavaScript and Azure https://www.youtube.com/playlist?list=PLi8ga rtTlTVx7sKg3XLuCQik1XSgUMNgl Sql Saturday 2017 Kyiv https://www.youtube.com/playlist?list=PLi8ga rtTlTVxR9lGYAXUNTk1Mo0qG1j7i

39. Questions? Anton Boyko Microsoft Azure MVP Ninja Azure Consultant boyko.ant@live.com
