1. 2014 - Lugano Microsoft Azure Overview Ken Casada Technical Evangelist Microsoft Switzerland kcasada@microsoft.com

2. Microsoft Azure Flexible Open Solid

3. Global Footprint

4. Pay for what you use

5. IaaS (VM & VPN)

6. Does Your App Need a Virtual Network? Virtual Machines deployed into a virtual network have an infinite DHCP lease (not static but effectively the same thing) Deploy apps in the cloud that requires Active Directory Windows Azure VM 1 VM 2 Subnet 1 ROLE 1 Subnet 2 Requirement for connectivity between your data center and the public cloud Corpnet Connecting a PaaS to IaaS Service (for better performance / there are apps that have dependencies on resources that require VM such as SharePoint, SQL Server, Active Directory, )

7. Creating a Virtual Private Network

8. Creating a Virtual Private Network Note: Previously: was not possible to statically assign an IP address. IP address was allocated as the VM was allocated! The IP address remain the same as long as the VM is allocated. New: you can statically set an IP address (today only via PowerShell) How? http://blogs.msdn.com/b/windowsazure/archive/2014/04/22/static-internal-ip-address-for-virtual-machines.aspx Reserve public IP addresses (up to 5 for free) keep it even if you delete the VM

9. Virtual Machines

10. Cloud Service VM1 Port 80 Public Port 80 LB VM2 Port 80 Port 80 VM3 Port 80

11. Cloud Service VM1 Port 80 TCP Probe Public Port 80 LB VM2 VM2 Port 80 Port 80 VM3 Port 80

12. Cloud Service VM1 Port 80 /healthcheck.aspx Public Port 80 LB VM2 Port 80 Port 80 /healthcheck.aspx VM3 Port 80 /healthcheck.aspx

13. Web Sites Build with popular web framework (ASP .NET, PHP , Python or Node.js) With a SQL DB or MySQL database Deploy in seconds with WebDeploy, FTP Source Control Deployment (ex. Git/TFS ) Start for free, scale up as your traffic grows

14. Web sites

15. Cloud Services (PaaS) Automated application management Support rich multi-tier architectures Web Role / Worker Role Build stateless highly scalable apps and services

16. Deploying a cloud service

17. Packaging and Deployment (Paas) Upload to Windows Azure Storage Microsoft Visual Studio Web Role Package *.cspkg Windows Azure Fabric Controller Worker Role Config *.cscfg Network Load Balancer

18. Monitoring (Paas) Windows Azure Fabric Controller Network Load Balancer Package

19. What is a Cloud Service? A collection of related service roles

20. Big data Database Storage Traffic Messaging Caching Identity Media CDN Networking

21. DB

22. New Service Tiers (still in preview) -Basic Basic: for small size database (from ~5CHF/month) / light transactional workload / infrequently used apps -Standard Standard: offers mid-level performance / support for multiple concurrent queries (max 500 sessions) -Premium (dedicated resources): large database (up to 500 GB), for high transactional volume Note: Web / Business Editions will be retired in 2015 . (http://msdn.microsoft.com/library/azure/dn741330.aspx) Which one to use? Which one to use? It depends: which features do you need ? It depends: which features do you need ? Performance requirement: Performance requirement: http://msdn.microsoft.com/library/azure/dn741336.aspx http://msdn.microsoft.com/library/azure/dn741336.aspx see next slide! see next slide!

23. Self-Service Restore for oops recovery of data deletion or alteration - Automatic backup taken in 5 min increments - Point-in-time restore up to 7/35 days back (standard/premium) Active Geo-Replication (only in Premium offer) - Create up to 4 readable secondary replicas - Replicate to any Azure region

24. Windows Azure Storage replication done synchronously Option 2 (default): additional 3 copies within the secondary region (Default option) replication done asynchronously Option 3 (new): data in secondary region is also read-only More: http://blogs.msdn.com/b/windowsazurestorage/archive/2013/12/04/introducing-read-access-geo-replicated- storage-ra-grs-for-windows-azure-storage.aspx

25. Traffic

26. Intelligentlydirects requestsfromusersacrossinstances of an appdeployedin differentAzure datacenter Policy options: Performance: all requests sent to the closest datacenter Failover: all requests sent to specified datacenter, unless datacenter is not available Round Robin: all requests equally spread across all datacenters

28. New VM Extensions (some extensions are in preview) ExpressRouteis GA http://blog.equinix.com/2014/05/microsoft-azure-expressroute-now-available-in- equinix-data-centers-customers-tap-benefits-to-deliver-hybrid-cloud-solutions/ Internal Load Balancing Support (preview) General Availability of Azure Import/Export Service (+Europe coverage) Windows Azure Files: new SMB file sharing service (preview) Azure API Management Service (preview) Hybrid connections between WebSite/Mobile Service and on-premises resources . more Info available here .

29. Q & A

30. Lunch
