1. Proprietary + Confidential google_logo Open Source Knative Eventing Bryan Zimmerman | Google Nicolas Lopez | Google

2. Proprietary + Confidential The Rise of MicroServices Event-driven Architecture Agenda Knative Eventing Demo: Image Processing Knative Community

3. Proprietary + Confidential The Rise of Microservices google_logo Open Source

4. Proprietary + Confidential E-Commerce Store Monolith Application Layer Scales Verticallynot Horizontally. Overwhelming to build, deploy and maintain as teams and application grow. Payment Reporting Shop Nightmare to change something. Server Newsletter Inventory Custome r DB google_logo Open Source

5. Proprietary + Confidential E-Commerce Store Monolith Application Server Microservices Shop Payment Reporting Inventory Newsletter Custome r DB google_logo Open Source

6. Proprietary + Confidential E-Commerce Store Monolith Application Server Microservices Shop Payment Reporting Inventory Newsletter Custome r DB google_logo Open Source

7. Proprietary + Confidential Monolith E-Commerce Store Microservices Separation of concerns Inventory Reporting Shop Promotes Agile development. Easy to build, maintain, and deploy. Flexibility to build in the language of your choice. Payment Newsletter Custome r DB Services can be scaled independently to meet demand. google_logo Open Source

8. Proprietary + Confidential Monolith E-Commerce Store Microservices Services can be scaled independently to meet demand. Separation of concerns Promotes Agile development. Easy to build, maintain, and deploy. Flexibility to build in the language of your choice. Inventory Reporting Shop Spider web of point-to-point integrations. Payment Newsletter Custome r DB Coupling with p2p inter-service communication. Adding/Removing services requires changing other services. google_logo Open Source

9. Proprietary + Confidential Event-Driven Microservices google_logo Open Source

10. Proprietary + Confidential An event is a record expressing an occurrence and its context Events represent facts and therefore do not include a destination The producer has no expectation of how the event is handled What is an Event? Occurrence Event Action google_logo Open Source

11. Proprietary + Confidential Event Producers Service Service Service Event-driven Microservices Event Intermediary Service Service Service Event Consumers google_logo Open Source

12. Proprietary + Confidential Event-driven Microservices Event Producers Fully decoupled with no point-to-point communication. Service Service Service Highly Scalable. Extend organically -Add/Remove services without modifying existing application. Event Intermediary Service Service Service Event Consumers google_logo Open Source

13. Proprietary + Confidential Knative Eventing google_logo Open Source

14. Proprietary + Confidential Knative Eventing Event Producers Composable primitives to enable late-binding event producers and event consumers. Github Source Knative Svc Kafka Source Cloud Events to standardize event data Event Producers (Sources) produce Cloud Events Broker Event Consumer is any Addressable such as Knative Service, K8s Service Trigger Trigger Trigger Broker and Trigger as intermediary Knative Svc K8s Service Addressable Events and Source Registry for discovery. Event Consumers More primitives -Channels, Sequence, Parallel etc google_logo Open Source

15. Proprietary + Confidential Knative Eventing in Action google_logo Open Source

16. Proprietary + Confidential Image Processing Pipeline application Image Processing Pipeline GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service https://github.com/meteatamel/cloudrun-tutorial/blob/master/docs/image-processing-pipeline-gke.md

17. Proprietary + Confidential Image Processing Pipeline application We will setup 1 source + 4 triggers to connect the services via events Image Processing Pipeline GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service

18. Proprietary + Confidential CloudStorageSource + trigger When an object gets stored in GCS, an event will be sent to the cluster GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service

19. Proprietary + Confidential CloudStorageSource + trigger Trigger allows Storage Source events to be routed to the Filter service GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service

20. Proprietary + Confidential Custom Triggers Custom events are sent by the services with a trigger configurd to route the events to other services GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service

21. Proprietary + Confidential Ready! Image Processing Pipeline GKE Google Kubernetes Engine Resizer Knative service Images input Cloud Storage Images output Cloud Storage End Users End Users Filter Knative service Watermarker Knative service Labeler Knative service

22. Proprietary + Confidential Knative Eventing Core Concepts google_logo Open Source

23. Proprietary + Confidential Knative Eventing Source An event Source (https://knative.dev/docs/eventing/sources/) generates events or imports events from external producers Existing Sources Community owned -Kafka, Github, etc. Vendor owned Google: CloudStorage, CloudAuditLog, etc. TriggerMesh: AWS SQS, AWS Kinesis, etc. Custom sources google_logo Open Source

24. Proprietary + Confidential How are Knative Sources implemented? Use standard way of extending Kubernetes: Custom Resource Definitions (CRDs) CRDs define new resource types Class in a programming language Instances of CRDs are called Custom Objects (COs) Object in a programming language CRD COs definition https://kubernetes.io/docs/tasks/extend-kubernetes/custom-resources/custom-resource-definitions/ google_logo Open Source

25. Proprietary + Confidential Types of Knative Sources Push Must be exposed to the sender E.g. a publicly exposed URL for GitHub to make requests against Easier to scale Can use Knative Services, scaling down to zero Pull Something must always be running Needs network access to the producer, but does not need to expose an endpoint Harder to scale google_logo Open Source

26. Proprietary + Confidential Broker & Trigger Broker (https://knative.dev/docs/eventing/broker/) Triggers (https://knative.dev/docs/eventing/triggers/) are the way to subscribe events from a specific Broker Filtering based on CloudEvents attributes Event sink could be any addressable Broker implementations Default Alternative Broker implementations, e.g. GCP, Kafka google_logo Open Source

27. Proprietary + Confidential consumer group Topic consumer group consumer group Kafka MT Dispatcher Filter T1 MT Ingress Publisher Kafka Topic B1 Consumer google_logo Open Source

28. PubSub Topic T1 PubSub Topic B1 Filter T1 Pubsub Pull Failure MT Retry Publisher Filter T1 Consumer MT Fanout MT Ingress google_logo Open Source

29. Proprietary + Confidential Primitives - Messaging Channel (https://knative.dev/docs/eventing/channels/) Subscription Svc Channel Svc Svc Subscriptions google_logo Open Source

30. Proprietary + Confidential Primitives - Flows Sequence (https://knative.dev/docs/eventing/flows/sequence/) Parallel (https://knative.dev/docs/eventing/flows/parallel/) Svc Svc Svc Svc Svc Svc google_logo Open Source

31. Proprietary + Confidential Sources Targets Knative-based Broker Trigger 60+ Cloud Sources (via Cloud Audit Logs) Events for Cloud Run for Anthos Cloud Storage, Cloud Scheduler Cloud Run for Anthos Events for Cloud Run for Anthos Custom Applications (publishing to Cloud Pub/Sub) Custom Events ?

32. Proprietary + Confidential Knative Community google_logo Open Source

33. Proprietary + Confidential Vibrant community Two core components - Serving and Eventing 10 active Working Groups with 450+ contributors 15+ active repositories 7 knative-based offerings from vendors such as Google, IBM, Red Hat, TriggerMesh, and VMWare. google_logo Open Source

34. Proprietary + Confidential Knative Partners google_logo Open Source

35. Proprietary + Confidential What next? Learn About Knative Try our GCP implementation View us on Github https://knative.dev/docs/ https://cloud.google.com/run/d ocs/events/anthos/quickstart https://github.com/knative google_logo Open Source

36. Proprietary + Confidential Next events on Google Open Source Live Kubernetes Day Go Day Nov 5, 9-11am PT Dec 3, 9-11 am PT https://goo.gle/GoDayNov5 http://goo.gle/k8sDay Golang experts will share updates on everything from Go basics to Package Discovery and Editor Tooling. Our partner, Khan Academy will also walk through an interesting use case about how the organization is using Go to save time and money. At this event, Kubernetes experts at Google will cover the life of a Kubernetes API, admission webhooks, how apply works, and the distributed value store etcd. google_logo Open Source

37. Proprietary + Confidential Thank you! We want to hear from you! To discuss needs, use cases, or feedback reach out to bryanzimmerman@google.com google_logo Open Source
