1. MI8 line to RR Lattice Measurement and Matching Ming-Jen Yang, MI Dept. Nov. 28, 2018 1

2. Lattice study on Oct 18, 2018 Horizontal plane data HT800, HT804, and HT806 Vertical plane data VT803, VT805, VT807 Dispersion data Frequency from -1800 Hz to +1800Hz MI meeting, Nov 28, 2018

3. MI8 line orbit, HT800 MI meeting, Nov 28, 2018

4. 1st order orbit response in mm/amp, HT800 MI meeting, Nov 28, 2018

5. MI8 line orbit, HT804 MI meeting, Nov 28, 2018

6. 1st order orbit response in mm/amp, HT804 MI meeting, Nov 28, 2018

7. MI8 line orbit, HT806 MI meeting, Nov 28, 2018

8. 1st order orbit response in mm/amp, HT806 MI meeting, Nov 28, 2018

9. MI8 line orbit, VT803 MI meeting, Nov 28, 2018

10. 1st order orbit response in mm/amp, VT803 MI meeting, Nov 28, 2018

11. MI8 line orbit, VT805 MI meeting, Nov 28, 2018

12. 1st order orbit response in mm/amp, VT805 MI meeting, Nov 28, 2018

13. MI8 line orbit, VT807 MI meeting, Nov 28, 2018

14. 1st order orbit response in mm/amp, VT807 MI meeting, Nov 28, 2018

15. MI8 line to RR, dispersion function MI meeting, Nov 28, 2018

16. MI8 line to RR, beam width sigma match MI meeting, Nov 28, 2018

17. MI8 line beta function, as matched smoothed MI meeting, Nov 28, 2018

18. MI8 line to RR, quad current changes MI meeting, Nov 28, 2018

19. Compare profile sigma, with old lattice with new lattice MI meeting, Nov 28, 2018

20. MI8 Line lattice status Matched Appeared to be more consistent. Smoothed Match to RR will be done later Restore MI8 line FODO region Setting the stage for implementing lattice monitor. Impact to other beamlines MI injection Estimate changes can be done. MicorBoone Appeared minimum. MI meeting, Nov 28, 2018
