1. Lecture 7 Methods of imaging the respiratory system . .

2. Methods of imaging the respiratory system 1. Plain films 2. Radionuclide imaging 3. CT 4. US (for pleural disease) 5. MRI 6. Bronchography.

3. The normal anatomy necessary to the respiratory system angiography

4. The normal anatomy necessary to the respiratory system angiography

5. The normal anatomy necessary to the respiratory system angiography

6. The normal anatomy necessary to the respiratory system angiography

7. The normal anatomy necessary to the respiratory system angiography

8. The normal anatomy necessary to the respiratory system angiography

9. The normal anatomy necessary to the respiratory system angiography

10. The normal anatomy necessary to the respiratory system angiography

11. The normal anatomy necessary to the respiratory system angiography

12. The normal anatomy necessary to the respiratory system angiography

13. The normal anatomy necessary to the respiratory system angiography

14. The normal anatomy necessary to the respiratory system angiography

15. The normal anatomy necessary to the respiratory system angiography

16. The normal anatomy necessary to the respiratory system angiography

17. Abnormal Pulmonary angiography pulmonary embolism (PE)

18. Abnormal Pulmonary angiography pulmonary embolism (PE)

19. Abnormal Pulmonary angiography pulmonary embolism (PE)

20. Pulmonary arteriography is the gold standard and will detect most pulmonary emboli. Technique 1. Unenhanced scan of thorax - to detect any other clinical abnormality which might account for symptoms. 2. Enhanced scan of pulmonary arterial system

21. Patient preparation Prepare The D-dimer blood test (norm<500) Blood urea + serum creatinine patient position supine with their arms above their head scan extent lunge apices to diaphragm Remove metals attached to the clothes Blue canula or pink , test the canula ,

22. During exam Use manual method (look at the superior vena cava) Respiration phase inspiration monitoring slice (region of interest) below the carina ( Trachea bifurcation ) at the level of the pulmonary trunk. Use bolus method A-IF ROI on the SVC the HU would be approx:175 HU B- IF the ROI on the pulmonary trunk ,The HU would be 100 HU Contrast injection (1or 2 ml per kg ), (usually 75-85 ml) **In the perfect scan, the contrast should not appear in the descending aorta. ** Before the radiation starts make sure the CT scan room door is closed **During IV administration Look at the patient and your CT screen to make sure that the cannula and the connection line is working properly during the exam

23. The normal anatomy necessary to the respiratory system angiography Topogram

24. A GUIDE TO CT pulmonary angiogram (CTPA) procedure (manual method) Volume of contrast medium - 80 ml Contrast (and 20 ml of normal saline). Delay usually around 15 s (Manual look at the pulmonary trunk or the SVC when the contrast reach press start scanning) Rate of injection - 4 ml/s Collimation - 3 mm Pitch - 1.8 Start point - just above the aortic arch End point - the lowest hemidiaphragm.

25. A GUIDE TO CT pulmonary angiogram (CTPA) procedure (Auto method ) Volume of contrast medium 80 ml Contrast +20 ml Normal saline ROI circle - If on the pulmonary trunk HU = 100 - If on the SVC HU = 175 Rate of injection 4 - 6 ml/s Start point - just above the aortic arch End point - the lowest hemidiaphragm.

26. Practical test of the exam Practical CTPA , Toshipa (Canon) 64 slice CT scan Please Watch carefully !!

27. References Further reading Klein, J.S. (ed) (2000) Interventional Chest Radiology. Radiol. Clin. N. Am. 38 (2). Macklem P.T. (1998) New methods of imaging the respiratory system. Respirology 3, 101-102. PIOPED Investigators. (1990) Value of ventilation/perfusion scanning in acute pulmonary embolism. JAMA 263 , 2753-2759. Robinson, P.J. (1989) Lung scintigraphy. Clin. Radiol. 4 0 , 557-560. Further reading Remy-Jardin, M., Artaud, D., Fribourg, M. & Beragi, J.P. (i 998) Spiral CT of pulmonary emboli: diagnostic approach, interpretative pitfalls and current indications. Eur. Radiol. 8, 1376-1390.
