1. MAX-PLANCK-INSTITUT FR CHEMISCHE ENERGIE KONVERSION METHANOL SYNTHESIS ON COPPER-BASED CATALYSTS M.V. Bukhtiyarova

2. Introduction 1. Methanol production is a large industrial process. MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 2. Methanol is produced using synthesis gas at 250 C and 50 100 bars CO + 2H2 = CH3OH Catalyst: Cu/ZnO/Al2O3 3. High emission of CO2resulted in studying methanol synthesis through CO2 hydrogenation. 4. Methanol can be viewed as a way of hydrogen storage

3. Methanol synthesis CO2 + 3H2 CH3OH +H2O MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION Methanol synthesis setup Gas mixture: H2:CO2= 3:1 Pressure: 30 and 50 bars Temperature: 190, 210, 230, 250 and 260 C GHSV: 4800 and 7200 h-1 S d-Chemie catalyst : Cu/ZnO/Al2O3 (old generation)

4. Gas chromatography of liquid sample Sample obtained at 250 C, 30 bar, 7200 h-1 MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION Reference methylformate solution contains 5% of methanol Samples are dissolved in acetone to have reproducible results 400Wasser #87 [modified by gschmitz] pA TCD 1 - 68 [modified by gschmitz] 2 - 62 pA RSG-MS-017-13 Methylformiat 100 300 3 75 air 1 50 200 1 2 Reference methylformate acetone 2 2 25 100 1 2 Sample 1 min min -5 -10 0,00 1,00 2,00 3,00 4,00 5,00 0,00 1,00 2,00 3,00 4,00 5,00 6,00 7,00 No. Ret.Time Peak Name min 1 1.69 2 2.02 3 2.98 Rel.Area % 0.014 0.015 99.970 No. Ret.Time Peak Name min 1 2.50Methanol 2 3.31Wasser Rel.Area % 48.277 51.723 Methyl formate n.a. Methanol Traces of methylformate are observed during methanol synthesis

5. Methanol synthesis 1.4 50 CH3OH H2O GHSV = 4800 h p = 30 bar Ratio CH3OH/H2O, ml/ml 190 C MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 40 210 C -1 1.2 260 C 30 Volume, ml 250 C 230 C -1 GHSV = 4800 h 1.0 20 p = 30 bar 230 C 250 C 210 C 10 260 C 0.8 190 C 0 6 9 12 15 18 21 24 6 9 12 15 18 21 24 27 30 Time, h Time, h Methanol synthesis: Reverse water gas shift: CO2 + 3H2 CH3OH +H2O CO2 + H2 CO +H2O H = 49.7 kJ/mol H = 41.2 kJ/mol Ratio of CH3OH/H2O (ml/ml) = 2.24 Increasing temperature promotes water-gas shift reaction

6. Methanol synthesis Dependence on pressure MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 50 50 CH3OH H2O GHSV = 4800 h p = 50 bar CH3OH H2O GHSV = 4800 h p = 30 bar 40 40 -1 -1 260 C 250 C 260 C Volume, ml 30 30 Volume, ml 250 C 230 C 20 20 230 C 210 C 210 C 10 10 190 C 190 C 0 0 6 9 12 15 18 21 24 27 30 6 9 12 15 18 21 24 27 30 Time, h Time, h MS: CO2 + 3H2 CH3OH +H2O CO2 + H2 CO +H2O RWGS: According to Chatelier s principle increase of pressure results in higher methanol formation

7. Methanol synthesis Dependence on space velocity MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 50 50 CH3OH H2O GHSV = 7200 h CH3OH H2O GHSV = 4800 h p = 30 bar 260 C 40 40 -1 -1 260 C 250 C p = 30 bar 30 Volume, ml Volume, ml 30 250 C 230 C 20 20 230 C 210 C 210 C 10 10 190 C 190 C 0 0 6 9 12 15 18 21 24 27 30 6 9 12 15 18 21 24 27 30 Time, h Time, h Volume of formed methanol and water depends on reaction conditions

8. Methanol synthesis Dependence on space velocity at high pressure MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 50 50 CH3OH H2O GHSV = 7200 h p = 50 bar 260 C 250 C CH3OH H2O GHSV = 4800 h p = 50 bar 40 40 -1 -1 260 C 250 C Volume, ml Volume, ml 30 30 230 C 230 C 20 20 210 C 210 C 10 10 190 C 190 C 0 0 6 9 12 15 18 21 24 27 30 6 9 12 15 18 21 24 27 30 Time, h Time, h Volume of methanol and water does not practically change at temperature higher than 250 C

9. CO2conversion Dependence on pressure GHSV = 4800 h-1 Dependence on space velocity p = 30 bar MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 20 16 18 30 bar 50 bar 14 -1 4800 h 6000 h 7200 h 16 CO2 conversion, % CO2 conversion, % -1 12 14 -1 10 12 10 8 8 6 6 4 4 2 2 0 0 453 463 473 483 493 503 513 523 533 543 453 463 473 483 493 503 513 523 533 543 Temperature, C Temperature, K Conversion of CO2increase with temperature and decrease with space velocity

10. Methanol selectivity Dependence on pressure GHSV = 4800 h-1 Dependence on space velocity p = 30 bar MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 80 80 70 70 Selectivity CH3OH, % Selectivity CH3OH, % 60 60 50 50 40 40 30 bar 50 bar -1 4800 h 6000 h 7200 h 30 30 -1 -1 20 20 10 10 0 0 453 463 473 483 Temperature, K 493 503 513 523 533 543 453 463 473 483 Temperature, K 493 503 513 523 533 543 At high pressure selectivity practically does not change with temperature

11. Methanol yield Dependence on space velocity p = 30 bar Dependence on pressure GHSV = 4800 h-1 MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 8 8 30 bar 50 bar 7 7 -1 4800 h 6000 h 7200 h -1 6 6 Yield CH3OH, % Yield CH3OH, % -1 5 5 4 4 3 3 2 2 1 1 0 0 453 463 473 483 Temperature, K 493 503 513 523 533 543 453 463 473 483 Temperature, C 493 503 513 523 533 543 Methanol yield increases with temperature, pressure and decreases with space velocity

12. Activation energy Comparison with literature data MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 50 0,5 Activation energy, kJ/mol -1 4800 h 6000 h 7200 h 48 a -1 0,0 Ea = 48.7 kJ/mol -1 Ln(Rate(CH3OH)) 46 Cu/ZnO/Al2O3 Cu/ZnO -0,5 Ea = 48.2 kJ/mol 44 d a Ea = 44.9 kJ/mol -1,0 42 Cu/ZrO2 Cu/ZnO/Al2O3/Cr2O3 c 40 -1,5 b (a) Our data (b) H. Arakawa, Energy Conv. Mgmt: 33 (1992) 521 (c) X. Guo, J. Mol. Catal. A: 345 (2011) 60 (d) A. Karelovic, Catal. Today: 197 (2012) 109 38 -2,0 1,85 1,90 1,95 2,00 2,05 2,10 2,15 2,20 36 1/T, 1/K Obtained activation energy is in the agreement with activation energy presented in literature

13. Methanol synthesis Conditions for stability test: H2:CO2= 3:1; 30 bar, 230 C; 4800 h-1 MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 10 8 Yield CH3OH, % 6 4 2 0 0 50 100 150 200 Time, h 250 300 350 400 450 Productivity of methanol decreases during first 100 after that the catalyst works stable for another 300 hours

14. Methanol synthesis CO2 + 3H2 CH3OH +H2O Methanol synthesis: MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION Gas mixture: H2:CO2= 3:1 Pressure: 30 bar Temperature: 190, 210, 230, 250 and 260 C GHSV: 4800 h-1 Clariant (S d-Chemie) catalysts 18 18 65 Old Catalyst New Catalyst Old Catalyst New Catalyst 16 16 60 Selectivity CH3OH, % 14 14 55 Conversion CO2, % Yield CH3OH, % 12 12 50 10 10 45 8 8 40 6 6 35 4 4 30 2 2 0 0 25 453 463 473 483 493 503 513 523 533 543 Temperature, K 453 463 473 483 Temperature, K 493 503 513 523 533 543 The old generation catalyst works better for CO2hydrogenation at low pressure

15. Conclusions MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION 1. Methanol yield depends on reaction conditions: high pressure results in formation of higher amount of methanol 2. Practically pure methanol with trace amount of methylformate is produced 3. Clariant (S d-Chemie) catalyst for methanol synthesis is stable during long- term experiment for 400 hours 4. Clariant (S d-Chemie) catalyst of old generation is more suitable for production methanol by CO2hydrogenation

16. MAX-PLANCK-INSTITUT FR CHEMISCHE ENERGIE KONVERSION THANK YOU FOR YOUR KIND ATTENTION

18. Methanol yield MAX-PLANCK-INSTITUT F R CHEMISCHE ENERGIE KONVERSION Productivity CH3OH, kgMet/(kgcat*h) Productivity CH3OH, kgMet/(kgcat*h) 30 bar 50 bar -1 4800 h 6000 h 7200 h -1 -1 453 463 473 483 493 503 513 523 533 543 453 463 473 483 493 503 513 523 533 543 Temperature, C Temperature, C

19. Gas chromatography of liquid samples FID300 C 240 C 50 C H2 0,86 bar 2,3 ml 1:20 Instrument Column: Programm Method Report Agilent 6890 Stabilwax 30 m S-1 TCD 60 Wasser Rep Wasser Detektor Injector Tem.Programm Gas Split Injection Volume TCD250 C 250 C 80 C He 0,93 bar 1 ml 1:20 0.5 l Instrument 6890 Column: Programm Method Report Detektor Injector Tem.Programm: Gas: Split Stabilwax 30m S-69 Stabilwax Pyrrol Rep normal Injection Volume: 0.5 l The measurement using FID was done for determination organic impurities in methanol. FID does not detect water
