Memory Resource Management in VMware ESX Server Overview
Memory Resource
Management in VMware ESX
Server
By Carl A. Waldspurger
Presented by Clyde Byrd III
(some slides adapted from C. Waldspurger)
EECS 582 – W16
1
Overview
•
Background
•
Memory Reclamation
•
Page Sharing
•
Memory Allocation Policies
•
Related Work
•
Conclusion
EECS 582 – W16
2
Background
•
Server consolidation needed
•
Many physical servers underutilized
•
Consolidate multiple workloads per machine
•
Using Virtual Machines
•
VMware ESX Server: a thin software layer designed to multiplex
hardware resources efficiently among virtual machines
•
Virtualizes the Intel IA-32 architecture
•
Runs existing operating systems without modification
EECS 582 – W16
3
ESX Server
EECS 582 – W16
4
Memory Abstractions in ESX
•
Terminology
•
Machine address: actual hardware memory
•
“Physical” address: a software abstraction used to provide the illusion of hard
ware memory to a virtual machine
•
Pmap: for each VM to translate “physical” page numbers (PPN) to
machine page numbers (MPN)
•
Shadow page tables: contain virtual-to-machine page mappings
EECS 582 – W16
5
Memory Abstractions in ESX (cont.)
EECS 582 – W16
6
Memory Reclamation
•
Traditional approach
•
Introduce another level of paging, moving some VM “physical” pages to a swap
area on disk
•
Disadvantages:
•
Requires a meta-level page replacement policy
•
Introduces performance
•
Double paging problem
EECS 582 – W16
7
Memory Reclamation (cont.)
•
The hip approach: Implicit cooperation
•
Coax guest into doing the page replacement
•
Avoid meta-level policy decisions
EECS 582 – W16
8
Ballooning
EECS 582 – W16
9
Ballooning (cont.)
EECS 582 – W16
10
•
The black bars plot the
performance when the VM is
configured with main memory
sizes ranging from 128 MB to
256 MB
•
The gray bars plot the
performance of the same VM
configured with 256 MB,
ballooned down to the
specified size
Throughput of a Linux VM running dbench with 40 clients
Ballooning (cont.)
•
Ballooning is not available all the time: OS boot time, driver
explicitly disabled
•
Ballooning does not respond fast enough for certain situations
•
Guest OS might have limitations to upper bound on balloon size
EECS 582 – W16
11
Page Sharing
•
ESX Server exploits redundancy of data across VMs
•
Multiple instances of the same guest OS can and do share some of the same data
and applications
•
Sharing across VMs can reduce total memory usage
•
The system allows tries to share a page before swapping out pages
EECS 582 – W16
12
Page Sharing (cont.)
•
Content-Based Page Sharing
•
Identify page copies by their contents. Pages with identical contents can be shared
regardless of when, where or how those contents were generated
•
Background activity saves memory over time
•
Advantages:
•
Eliminates the need to modify, hook or even understanding guest OS code
•
Able to identify more opportunities for sharing
EECS 582 – W16
13
Page Sharing (cont.)
EECS 582 – W16
14
Scan Candidate PPN
Page Sharing (cont.)
EECS 582 – W16
15
Successful Match
Page Sharing (cont.)
EECS 582 – W16
16
Memory Allocation policies
•
ESX allows proportional memory allocation for VMs
•
With maintained memory performance
•
With VM isolation
•
Admin configurable { min, max, shares }EECS 582 – W16
17
Proportional allocation
•
Resource rights are distributed to clients through TICKETS
•
Clients with more tickets get more resources relative to the total resources in the
system
•
In overloaded situations client allocation degrades gracefully
•
Proportional-share can be unfair,
•
ESX uses an “idle memory tax” to be more reasonable
EECS 582 – W16
18
Idle Memory Tax
•
Tax on idle memory
•
Charge more for idle page than active page
•
Idle-adjusted shares-per-page ratio
•
Tax rate
•
Explicit administrative parameter
•
0% is too unfair, 100% is too aggressive, 75% is the default
•
High default rate
•
Reclaim most idle memory
•
Some buffer against rapid working-set increases
EECS 582 – W16
19
Idle Memory Tax (cont.)
•
The tax rate specifies the max number of idle pages that can be
reallocated to active clients
•
When an idle paging client starts increasing its activity the pages can be
reallocated back to full share
•
ESX statistically samples pages in each VM to estimate active memory
usage
•
ESX by default samples 100 pages every 30 seconds
EECS 582 – W16
20
Idle Memory Tax (cont.)
EECS 582 – W16
21
Experiment:
2 VMs, 256 MB, same shares.
VM1
: Windows boot+idle.
VM2
:Linux boot+dbench.
Solid: usage, Dotted:active.
Change tax rate 0%
75%
After: high tax.
Redistribute
VM1
→
VM2
.
VM1
reduced to min size.
VM2
throughput improves 30%
Dynamic Reallocation
•
ESX uses thresholds to dynamically allocate memory to VMs
•
ESX has 4 levels from high, soft, hard and low
•
The default levels are 6%, 4%, 2% and 1%
•
ESX can block a VM above target allocations when levels are at low
•
Rapid state fluctuations are prevented by changing back to higher
level only after higher threshold is significantly exceeded
EECS 582 – W16
22
Dynamic Reallocation
EECS 582 – W16
23
I/O Page Remapping
•
IA-32 supports PAE to address up to 64GB of memory over a 36bit
address space
•
ESX can remap
“
hot
”
pages in high
“
physical
”
memory addresses to
lower machine addresses
EECS 582 – W16
24
Related Work
•
Disco and Cellular Disco
•
Virtualized servers to run multiple instances of IRIX
•
Vmware Workstation
•
Type 2 hypervisor; ESX is type 1
•
Self-paging of the Nemesis system
•
Similar to Ballooning
•
Requires applications to handle their own virtual memory operations
•
Transparent page sharing work in Disco
•
IBM’s MXT memory compression technology
•
Hardware approach; but can be achieved through page sharing
EECS 582 – W16
25
Conclusion
•
Key features
•
Flexible dynamic partitioning
•
Efficient support for overcommitted workloads
•
Novel mechanisms
•
Ballooning leverages guest OS algorithms
•
Content-based page sharing
•
Integrated policies
•
Proportional-sharing with idle memory tax
•
Dynamic reallocation
EECS 582 – W16
26
ESX is short for Elastic Sky X.
A marketing firm hired by VMware to create the product name believed Elastic Sky would be a good name.
VMware engineers did not like that and wanted to add a X to sound it more technical and cool.
VMware employees later started a band named Elastic Sky with John Arrasjid being the most well known member.
