Market Coordination and Model Overview
Providing technical guidance on customer-requested changes that impact the commercial model, the Market Coordination team facilitates asset registrations, tie-line changes, and more. Additionally, they publish monthly modeling reports to aid stakeholders in understanding the complex relationships within the Southwest Power Pool market.
Download Presentation
Please find below an Image/Link to download the presentation.
The content on the website is provided AS IS for your information and personal use only. It may not be sold, licensed, or shared on other websites without obtaining consent from the author. Download presentation by click this link. If you encounter any issues during the download, it is possible that the publisher has removed the file from their server.
E N D
Presentation Transcript
WEIS REGISTRATION & ONBOARDING OVERVIEW MARKET REGISTRATION EDUCATION SESSION Helping our members work together to keep the lights on... today and in the future. SPPorg southwest-power-pool SouthwestPowerPool
MODEL COORDINATION OVERVIEW What do we do? Provide technical guidance on customer requested changes that impact the commercial model New Market Participants and Asset Owners Asset registration or modification Source/Sink registration Tie-line changes Etc. Publish publically available Monthly Modeling Reports 2
MODELING HIERARCHY WHAT ARE THE RELATIONSHIPS? 3
MARKET PARTICIPANT ASSET OUTLINE Settlement Location Market Participant Meter Data Submittal Location Asset Owner Meter Settlement Location Load/Resource Asset 4
MP/ASSET OWNER RELATIONSHIP Market Participants may have one or more Asset Owners Asset Owner may have multiple Asset types 5
RESOURCE ASSET Resource Assets are represented as a single Settlement Location Resource Asset Resource Asset Settlement Locations have a one-to-one relationship to a Meter Data Submittal Location Settlement Location Meter Data Submittal Location 6
LOAD ASSET Load Assets are represented as a single Settlement Location Load Asset Settlement Location Load Asset Settlement Locations may have a mapping to more than one Meter Data Submittal Location Meter Data Submittal Location Meter Data Submittal Location 7
PRICE NODE (PNODE) A PNode has a one- to-one relationship to an ENode where Locational Marginal Prices are calculated. An ENode is a physical node represented in the Network Model where electrical equipment and components are connected. Commercial Model Network Model 8
RESOURCE AND LOAD SETTLEMENT LOCATIONS 9
SETTLEMENT AREA Comprised of multiple Meter Data Submittal Locations and Tie Interfaces MP responsible for residual load is required to report net tie-line flows for its Settlement Area 10
ASSET REGISTRATION WHAT DOES THE CUSTOMER NEED TO SUBMIT? 11
ASSET REGISTRATION Submission to SPP Oneline diagram detailing point of interconnect RMS submittal of the registration packet ICCP connection information New or modified Attachment AM External Submission Source/Sink must be registered with applicable Purchasing Selling Entity (PSE) in WebRegistry. 12
REGISTRATION PACKET Spreadsheet tabs include: Resources Loads Wind Resource Data Solar Resource Data *Asterisks denote required fields* Please complete all required fields 13
METER AGENT AGREEMENT Types Resource Load Tie Line Required information Meter Data Submittal Location (MDSL) Meter Physical Location Voltage Level Losses Operand (+ or -) 15
NAMING CONVENTIONS FOR MARKET ASSETS Purpose Consistent Identifiable General Requirements UPPERCASE LETTERS/ALPHANUMERIC CHARACTERS No more than twenty-five (25) characters in length Source/Sink limited to fourteen (14) characters in length 17
RESOURCE NAMING CONVENTION Combination of Resource Settlement Area MP/Asset Owner Acronym Resource Name Separated by a period (.) 18
RESOURCE EXAMPLE Combination of Resource Settlement Area = OKGE MP/Asset Owner Acronym = DREW Resource Name = BIGAIR Registered resource name should be OKGE.DREW.BIGAIR 19
LOAD NAMING CONVENTION Combination of Load Settlement Area MP/Asset Owner Acronym Load Name Separated by an underscore (_) 20
LOAD EXAMPLE Combination of Load Settlement Area = OKGE MP/Asset Owner Acronym = DREW Load Name = BIGCITY Registered load name should be OKGE_DREW_BIGCITY 21
REGISTRATION PACKET SUBMISSIONS TIMEFRAME & SUBMITTAL 22
REGISTRATION SUBMITTALS Submit via RMS tkt Choose the WEIS registration quick pick Due back on December 1, 2019 If you have additional questions or need more education, we can set up additional calls. 23
FUTURE UPDATES AND CHANGES MODELING TIMELINES AFTER GO-LIVE 24
NETWORK & COMMERCIAL MODEL UPDATES Network and Commercial Model changes are implemented on a monthly basis. Example: Today is 10/21 missed the 10/15 deadline for 12/1. Next available update date is 1/1 with a 11/15 deadline 25
TIMING REQUIREMENTS FOR REGISTRATION CHANGES APPENDIX E Outlines Type of Change New Resource Asset Updated Settlement Location Update Duration Defines the minimum duration Listed in Days, Weeks or Months Starts when completed documentation and technical information is received 26
QUESTIONS? Send us an RMS ticket WEIS Registration quick pick 28
ONBOARDING, READINESS, AND OUTREACH OVERVIEW What do we do? Ensure all timelines are communicated and met Contractual documents, testing timelines, information submission, system access provisioning assistance, questions Serve as the point of contact for SPP staff We navigate the organization for you, find the answers you need, schedule discussions 29
ONBOARDING, READINESS, AND OUTREACH OVERVIEW Primary efforts Contractual documents Credit Market participant agreement Meter agent agreements Local Security Administrator (LSA) forms Test scripts Connectivity testing Structured testing Unstructured testing 30
QUESTIONS? Send us an RMS ticket WEIS Registration quick pick 31
