CARNET Loomen CARNET Loomen
CARNET as an organization TLD registry operator Broad pallet of infrastructure/network services for education sector and other organizations Servicing over 3000 other member institutions Primarily open source based organization (Debian)
Moodle system - Loomen (before) Architecture of the Loomen system before COVID-19 One big server with web, database and caching (HaProxy, Apache, PHP, Memcached) The system worked well and it was stable up to some 800 simultaneous users (depending on the activities that took place on the system) Users often complained about the slowness of the system, as well as system outages that started somewhere in the 2nd month of 2020, when the system started to be used more and more
Loomen - today Architecture of the Loomen today Separation started in the middle of the February of 2020 Six web servers (NGINX, PHP-fpm) MariaDB Galera cluster with 3 nodes (sql1 as writer, sql2 and sql3 as read) Separated external logging for logs NFS data server Cache KeyDB and Memcached Off-site Backup NFS, Veeam & BareOS (Tape) F5 Load Balancer
Loomen - today New architecture
Insights Promethus/Grafana Node Exporter
Insights - Promethus/Grafana PHP-fpm Exporter
Insights - Promethus/Grafana KeyDB Exporter
Insights - Promethus/Grafana NGINX Exporter
Insights - Promethus/Grafana MYSQL Exporter
Loomen comparison (before - after) - Google Analytics comparison Number of users in the period before March 2020 it averaged about 12k per day In the period from the 3rd month to the end of the school year, the average was 60k per day while the maximum number of users was 83k Uptime Check The SLA from the 3rd to 9th month was 99.459% daily 7m 47s weekly 54m 31s monthly 3h 57m 6s yearly 1d 23h 25m 23s
Next steps - Infrastructure migration on Openstack and Ceph - Container based Moodle?
Thank you Q&A
